Thermal Imaging Camera
Instruction Manual
MENU
SELECT
ENTER
Dongguan Xintai Instrument Co.,Ltd.
Add: Building F, No. 13-16, Hongye Industrial Zone, Tangxia
community, Tangxia Town, Dongguan City
Postcode:523710
Tel:+86-769-82612006
Fax:+86-769-82612005
Website:www.hti-meter.com
https://hti-instrument.com www.xintest.en.alibaba.com
HT-19+
User Manual Version 1.0. May 12，2021.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HTI HT-19+
Summary of Contents for HTI HT-19+
- Page 1 Thermal Imaging Camera Instruction Manual MENU SELECT ENTER Dongguan Xintai Instrument Co.,Ltd. Add: Building F, No. 13-16, Hongye Industrial Zone, Tangxia community, Tangxia Town, Dongguan City Postcode:523710 Tel:+86-769-82612006 Fax:+86-769-82612005 Website:www.hti-meter.com https://hti-instrument.com www.xintest.en.alibaba.com HT-19+ User Manual Version 1.0. May 12，2021.
-
Page 2: Table Of Contents
Contents Preface 3.2. Delete video Limited warranty and limited responsibility 4. Introduction to “color palette” sub-menu Safety instruction 4.1. Color palette description Preliminary acquaintance with infrared thermal imager 4.2. Application of color palette Overview 5. Introduction to “emissivity” sub-menu Cleaning of the products 5.1. -
Page 3: Preface
Preface When warranty service is repaired, please contact the service center authorized by Xintai Instruments and Apparatus Co., Ltd to obtain the Respected users: authorization information for return. Then post the product together with How are you! Thank you for purchasing our instrument. In order to use it in problem description to the service center with postage and insurance a better manner, we remind you to read the instruction for use carefully expenses prepaid. -
Page 4: Safety Instruction
Safety instruction Warning Please ensure that you have read and understood the safety precautions The warning describes the acts that may cause harm to users. Please described in the following text before using the product so that you can observe the following operation in order to avoid electric shock or personal operate it correctly. - Page 5 Do not touch the electric wire with wet hands. Don’t weld the battery without permission. It is possible to cause electric shock when touching the electric wire Such operation may damage the battery and result in leakage and with wet hands. When pulling out the electric wire, hold the electric wire explosion of the battery.
-
Page 6: Preliminary Acquaintance With Infrared Thermal Imager
Preliminary acquaintance with infrared The product temperature may increase after a long time of thermal imager charging. You may feel scorching heat when the hands touch the sensors. For a long time, infrared thermal imaging detection technology has become an important means to ensure Industrial safety in developed countries. The Problem caused by water condensation application field includes electric power, metallurgy, petro-chemistry, Don’t bring the instrument into low temperature environment from high... -
Page 7: Overview
Overview Cleaning of the products Please use damp cloth or weak soap to clean the enclosure of the device. This product is an infrared camera that integrates surface temperature Don’t use abradant, isopropanol or solvent to clean. The lens and screen measurement and real-time thermal image. -
Page 8: Charging Of The Battery And Description
Charging of the battery and description Performance index Use USB data line to charge: Model HT-19+ The product has built-in chargeable 18650 lithium batteries. 3.2 ″ full angle Display screen TFT display When the battery level is low, the top right of the screen will display screen “... -
Page 9: Product Description
Product description File format 1. Instruction to structure Micro USB 2.0 Power supply Built-in chargeable 18650 battery Working time 2-3 hours Selectable: 5 minutes/20 minutes/ Automatic power-off time Display screen not power off automatically Setting command Unit、 language、date、time、information Language English、Chinese、Italian、German Product size 90mm×105mm×223mm Keypad... - Page 10 Please open the cap in use Micro USB Visible light camera Please open the cap in use Infrared imaging sensor Image capture key Battery www.xintest.com.cn www.xintest.com.cn...
-
Page 11: Display Description
2. Display description The lowest temperature cursor: used to indicate the lowest temperature position in the screen area. It will move with the movement of the lowest Temperature range Current emissivity temperature. The cursor displays red. The temperature value is displayed at the central position of the screen. - Page 12 Record video LCD screen display Long press the image capture button, the screen will prompt After turning on the power, open the lens protection cover, as “record video?”, if you select “Yes” at this time, please press the shown in , the screen shows the thermal imaging status.
-
Page 13: Introduction To The Menu
Introduction to the menu 2. Introduction to “images” sub-menu Press the left of “ MENU ” key and the menu bar appears. They are “Image 2.1. View image registration”, “Images”,“Videos”, “Color palette”, “Emissivity” and “Settings” Press the “ MENU ” button to enter the main menu, and select “ ”... -
Page 14: Video" Sub-Menu
3."Video" sub-menu 4. Introduction to “color palette” sub-menu 3.1. View video 4.1. Color palette description Press the “ MENU ” button to enter the main menu, and select “ ” The palette can be used to change the pseudo-color display of the infrared image on the display. -
Page 15: Application Of Color Palette
5. Introduction to “emissivity” sub-menu 4.2. Application of color palette 5.1. Emissivity description Color palette Spectra The emissivity of the product can be adjusted from 0.01 to 1.00 with the Iron default value of 0.95. Many common objects and materials (such as Cool timber, water, skin and textile fabric) can reflect the heat energy White... -
Page 16: Emissivity Setting
5.2. Emissivity setting If you select "self-defined" emissivity, press the “ SELECT ” button to enter the editing state.Press “ ” / “ ” keys to select the The product is provided with four types of object measurement modes: number to be changed, press “ ”... -
Page 17: Introduction To "Settings" Sub-Menu
6. Introduction to “settings” sub-menu 6.1. Auto shutdown setting After entering the "Settings" sub-menu, select “ ” (auto shutdown), Press “ MENU ” key to select the “ ”(settings) option in the main press navigationThe “ ” button in the button enters the auto power menu. -
Page 18: Time Format Setting
After the time setting is completed, press “ 6.6. Time format setting ” key to return. Press “ MENU ” exit from the menu. After you select “ ”(time format), press the “ ” key in the navigation key to enter the time format setting. Can be set to 24 hours 6.8. -
Page 19: Troubleshooting
Troubleshooting If you encounter with any problem when using the thermal image device, please use the following table for repair.If the problems are not solved, please cut off the power supply and contact with the manufacturer. Failure phenomenon Failure cause Solution The battery is not Install the battery...
