HTI HT-03 Instruction Manual page 11

On/off of LED lighting lamp
Hold down the "image capture" key for about 3 seconds to power
on/off the LED lighting lamp.
Witching between infrared thermal image and visible image
press " " or " " key to switch the degree of fusion between
inferred thermal images and visible images (the degree of fusion is
0%, 25%, 50%, 75% and 100%).
Image capture
press the image capture key. When the capture is successful, the
screen will display "store photo?" prompt. If "yes" is selected,
please press "MENU/ " key to determine to save the image. If
"no" is selected, press " SELECT/ENTER " key to determine not to
save the image.
Video recording
In the normal startup and running interface, long press the capture
button, the screen will display the prompt "record video?", if you
want to select "Yes" at this time, please press the "MENU/
button or the capture button to start recording. If you want to select
"No", press the "SELECT/ENTER" key to cancel the recording.
When the recording is finished, press and hold the capture button
again to end the recording.
17
The function to hide highest/lowest temperature column
at the screen bottom
under the operation after normal start up, press "
screen bottom will display highest/lowest temperature column.
Press "
Image output
The saved images through capture may be checked and output
by connecting with a computer through Micro USB.
Read images
Open the USB protective cover as shown in
connect the USB port and then computer to read the images or
save it into computers.images or save it into computers.
The supported operating system through verification includes:
winxp, win7, win 8, win10, Apple system.
It is suggested to use the attached USB line or USB line with
higher quality.
Note:
" When connecting with a computer, pull off the data line after
selecting "pop out device safely" to avoid causing file system
damage and other problems. If "unable to save" and other
problems occur, you may find the hard disc in the computer and
fix it.
" can also hide it.
" key and the
2
. Use USB line to
18
