Considerations and Safety Maintenance

Please read the user manual carefully in order to use the product
correctly:
Don't use the product in explosive, flammable, damp or
corrosive environment.
The product contains precision electronic and sensitive optical
devices.Don't impact and drop it to avoid damage.
Don't dismantle and remodel the product without permission.
Please use damp cloth or weak soap to clean the enclosure of
the device.
Don't use abradant, isopropanol or solvent to clean. The lens
and screen should be cleaned with use of professional optical
glasses.
When the product works, slight click will be given out every
several seconds. This is the normal phenomenon that the lens
captures the image.
2

Performance index

Detector type Uncooled focal plane
Resolution ratio
384×288 infrared focal plane
LCD resolution ratio 1024×768
Focal length 25mm; 35mm; 54mm; 75mm
Eyepiece Single-eyepiece display
(the refraction is adjustable and calibrated).
Field angle 14.9°x11.2°; 10.7°x8.0°; 6.9°x5.2°; 5.0°x3.7°;
Digital zoom 2x; 4x
Wavelength coverage 8μm to 14μm
Frame rate of thermal images 50Hz
Color palette Rainbow, hot metal, white hot, black hot.
Focal length Adjustable
Battery Built-in chargeable batteries
Storage space 8G
Image type
BMP
USB Type-C
Working time 6 hours
Weight
500g
Product size 180×72 ×62mm (focus length 25mm)
Work temperature 0℃-45℃
Storage temperature -20℃-60℃
Protection level
IP66
Automatic power-off time
40min
