Thermal Imaging Camera
Instruction Manual
Dongguan Xintai Instrument Co.,Ltd.
Add: Building16, No.3, Yongtai Road, TangxiaTown, Dongguan
City,Guangdong,China
Postal Code: 523710
Tel: +86-769-82612006
Fax: +86-769-82612005
Website: www.hti-meter.com
www.hytechcn.com.cn www.xintest.en.alibaba.com
HT-06
User Manual Version 1.1. March 8，2023.
Advertisement
Table of Contents
Related Manuals for HTI HT-06
Summary of Contents for HTI HT-06
- Page 1 Thermal Imaging Camera Instruction Manual Dongguan Xintai Instrument Co.,Ltd. Add: Building16, No.3, Yongtai Road, TangxiaTown, Dongguan City,Guangdong,China Postal Code: 523710 Tel: +86-769-82612006 Fax: +86-769-82612005 Website: www.hti-meter.com www.hytechcn.com.cn www.xintest.en.alibaba.com HT-06 User Manual Version 1.1. March 8，2023.
-
Page 2: Table Of Contents
Contents 3.2. Delete Video Preface 4. Introduction to “Color Palette” Sub-menu Limited Warranty and Limited Responsibility 4.1. Color Palette Description Safety Instruction 4.2. Application of Color Palette Preliminary Acquaintance with Infrared Thermal Imager 5. Introduction to “Emissivity” Sub-menu Overview 5.1. Emissivity Description Cleaning of the Products 5.2. -
Page 3: Preface
Preface expenses prepaid. Our company will not undertake any responsibility for any damage occurred during the process of transportation. The product will Respected users: be posted to the purchaser after repair with the transportation expenses How are you! Thank you for purchasing our instrument. In order to use it in paid by the purchasers. -
Page 4: Safety Instruction
Safety Instruction Warning Please ensure that you have read and understood the safety precautions The warning describes the acts that may cause harm to users. Please described in the following text before using the product so that you can observe the following operation in order to avoid electric shock or personal operate it correctly. - Page 5 Clean the dust on the adapter plug and the data line. Please pull off the adapter on the power socket when charging is not made. When it is exposed to dusty and dump environment for a long time, the The adapter may get overheated if it is connected with power supply for dirt surrounding the electric equipment will accumulate moisture.
-
Page 6: Preliminary Acquaintance With Infrared Thermal Imager
Avoid that the product is impacted (such as collision and falling, Personnel search and rescue in the fire, and fire command; etc). Analyze the location and heat loss of leak points in heat pipes and heating equipment; Such operation may cause the product to be damaged. Please avoid Determining the location of the heating fault of the operating train;... -
Page 7: Cleaning Of The Products
Charging of the Battery and Description Cleaning of the Products Use USB data line to charge: The shell of this product is cleaned with a damp cloth or diluted soapy water. Do not use abrasives, isopropyl alcohol or solvents to clean the lens The product has built-in chargeable 18650 lithium batteries. -
Page 8: Performance Index
Performance Index Storage Image/Video Format JPG/MP4 Image/video export method USB connection to computer export Vanadium Oxide Uncooled Infrared Infrared detector type Focal Plane Image analysis function Support offline analysis on PC Infrared resolution 256x192 Menu language English、Chinese、Italian、German Infrared response band 8 to14μm Removable Rechargeable Lithium Battery Type... -
Page 9: Product Description
Product Description 1. Instruction to Structure Micro USB Please open the cap in use Infrared imaging sensor Display screen Visible light camera LED lighting lamp Keypad Image capture key Handheld Battery... -
Page 10: Display Description
The lowest temperature cursor: Used to indicate the lowest temperature 2. Display Description position in the screen area. It will move with the movement of the lowest Temperature range Wifi Current emissivity temperature. The cursor displays green. The temperature value is displayed at the central position of the screen. - Page 11 On/off of LED lighting lamp The function to hide highest/lowest temperature column at the screen bottom Hold down the “image capture” key for about 3 seconds to power on/off the LED lighting lamp. under the operation after normal start up, press “ ”...
-
Page 12: Introduction To The Menu
Introduction to the Menu 2. Introduction to “image” Sub-menu Press the left of “ MENU/ ” key and the menu bar appears. They are 2.1. View Image “image overlapping”, “image”, “video”，“color palette”, “emissivity” and Press the “ MENU/ ” button to enter the main menu, and select “setting”... -
Page 13: Introduction To "Video" Submenu
4. Introduction to “Color Palette” Sub-menu 3. Introduction to “Video” Submenu 3.1.View Video 4.1. Color Palette Description The palette can be used to change the pseudo-color display of the Press “ MENU/ ” key to enter the main menu, select “ ”... -
Page 14: Application Of Color Palette
5. Introduction to “Emissivity” Sub-menu 4.2. Application of Color Palette 5.1. Emissivity Description Color palette Spectra The emissivity of the product can be adjusted from 0.01 to 1.00 with the Iron default value of 0.95. Many common objects and materials (such as Cool timber, water, skin and textile fabric) can reflect the heat energy White... -
Page 15: Emissivity Setting
5.2. Emissivity Setting If you select "self-defined" emissivity, press the " SELECT/ENTER " button to enter the editing state.Press “ ” / “ ” keys to select the number The product is provided with four types of object measurement modes: to be changed, press “... -
Page 16: Introduction To "Setting" Sub-Menu
6. Introduction to “Setting” Sub-menu 6.1. Auto Shutdown Setting After entering the "Settings" sub-menu, select "MENU/ " (automatic Press “ MENU/ ” key to select the “ ”(setting) option in the main shutdown), press navigationThe “ ” key in the button enters the auto menu. -
Page 17: Time Format Setting
6.6. Time Format Setting After the time setting is completed, press “ ” key to return. Press “ MENU/ ” exit from the menu. After you select " "(time format), press the “ ” key in the navigation key to enter the time format setting. Can be set to 24 hours 6.8. -
Page 18: Wireless Wifi On And Off
6.9. Wireless WIFI on and off After turning on WIFI, use the mobile device to search for WIFI, the WIFI name can be found in the local menu (as shown above); access the As shown in the figure, after selecting “ ”... -
Page 19: Thermal Imaging Image Analysis Software Operation Guide
Thermal Imaging Image Analysis Software Interface Introduction Operation Guide 1. Select the language in the upper right corner of the interface, you can choose Chinese, English, and switch between the two languages. Software Installation And Operation 2. On the right are shown as: fusion rate, color palette, temperature unit, 1. - Page 20 Icon Introduction 1. " " icon, take the temperature of the thermal image. 2. " "icon, select the maximum temperature and minimum temperature of the thermal image in a straight line. 3. " "icon, select the thermal imaging map to select the maximum temperature and minimum temperature.
