Performance index

Vanadium Oxide Uncooled Infrared
Infrared detector type
Focal Plane
Infrared resolution 256x192
Infrared response band 8 to14μm
Cell size 12μm
NETD ≤50mK @25℃,@F/1.1
Lens focal length 3.2mm
3.75mrad
IFOV
Field angle 56°×42°
Focus mode Free focus
Temperature
-20℃ to +550℃(-4℉ to 1022℉)
measurement range
-15℃ to 550℃ ±2℃or ±2%;
Measurement accuracy
-20℃ to -15℃ ±4℃
Temperature measurement
0.1℃
resolution
Temperature measurement
Center point/hot and cold spot tracking
mode
Rainbow, iron oxide red, cold color,
Color palette
black & white, white & black
Emissivity setting Adjustable from 0.01 to 1.00
Thermal imaging frame rate ≤25Hz
Visible light resolution 640×480
Display size 3.2-inch(240×320)
www.xintest.com.cn
Image display mode
Device storage
Storage Image/Video Format
Image/video export method
Image analysis function
Menu language
Battery Type
Battery capacity
Working time
Power interface
Power configuration
Work temperature
Storage temperature
Relative humidity
Product weight
Product size
13
Infrared/visible light/dual light fusion
Built-in 4G eMMC (user available
storage space is about 3G)
JPG/MP4
USB connection to computer export
Support offline analysis on PC
English、Chinese、Italian、German
Dedicated removable rechargeable
lithium battery
2200mAh
2 to 3 hours
Micro USB
5 minutes / 20 minutes / no automatic
shutdown
-10℃ to +50℃
-20℃ to +60℃
10% to 85%RH (non-condensing)
389g
90mm×105mm×223mm
