6 Zone Terminal

All manuals and user guides at all-guides.com

Start HVAC PRO

Select Zone Terminal From Main HVAC PRO Menu

Select Configure ZT Files

Define display files for single or multiple controllers.

Define weekly schedules.

Define holiday schedules.

Define ZT Configuration Load File

Press F2 and select up to three display files.

Press F2 and select Weekly and Holiday Schedules

which must be executed from ZT.

Press F2 and select display file which corresponds to appropriate controller.

Select hardware parameters.

Specify Password Access Numbers.

Print the Insert and photocopy onto an overhead transparency.

Select Download ZT

Attach cable to ZT AS-CBLCON-0 and AS-CABLEPRO-1 connection.

Set switch at AS-CBLCON-0 to Download.

Select the desired load file to download..

Select the communication port.

When Download Complete message is displayed on the screen,

press any key to return to Main ZT PRO Menu. (

at ZT during download; resets when download is complete.)

Unplug cable from ZT AS-CBLCON-0. Reset switch to normal.

Exit HVAC PRO

Figure 2: Overview—Configuring and Downloading the ZT

PC is displayed

DWNLDZT
