lntroduction

The Zone Terminal is a hand-held or wall-mounted person/machine
interface for the Metasys  Application Specific Controllers. It has the
versatility to connect to a controller in several ways, and allows the user to
monitor or adjust set points and time scheduling within a specific zone.
The Zone Terminal is used to monitor or adjust set points and for time

Application Details

scheduling of occupied, warmup/cooldown, or shutdown zone conditions.
It connects to:
G
G
G
G
The Zone Terminal is designed as an easy-to-use hands-on device with
Theory of
which you can:
Operation
G
G
G
G
G
For specific Theory of Operation details, refer to the Zone Terminal
section of the HVAC PRO User's Manual.
Displays
The ZT uses a liquid crystal display (LCD) divided into three sections
from top to bottom. Each display includes:
G
G
G
To the left of the display are 18 cursors (G) and triangles (L), 6 per
display. The cursors indicate current position in the respective display.
When flashing, the triangles indicate an alarm condition in the
corresponding analog points.
All manuals and user guides at all-guides.com
a VAV/UNT through a TE-6100 Zone Sensor
an AHU directly
an AHU through a Function Module Kit or a Relay Kit
an AHU or UNT through an M100C Actuator
quickly identify an alarm and its location
monitor and adjust up to 18 analog points
monitor 18 binary points
extend a daily time schedule using Occupied Extend
add or modify daily, holiday, and temporary time schedules
five, seven-segment digits
decimal points
colon
