Required Hardware
G
for Operation
G
Note: The UNT/VAV inserts match common configurations right out of
Optional Hardware
G
for Operation
G
G
G
G
G
G
Required for
G
Downloading
G
G
G
G
Note: AS-CBLPRO-1 must be used to download the ZT.
Software
ZT configuration and downloading are done with a software program
called ZT PRO which is part of the HVAC PRO software, Rev. 3. This
easy-to-use tool configures, commissions, and downloads the ZT's data
base. The program runs on an IBM® PC/XT/AT, PS/2, or any 100%
compatible computer. Figure 2 is an overview of the ZT configuration and
downloading process. Refer to the HVAC PRO User's Manual for specific
information on configuration and downloading the Zone Terminal.
All manuals and user guides at all-guides.com
AHU, UNT, or VAV controller with 24VAC transformer
AS-ZTU100 Zone Terminal comes with a 6-pin telephone-style coiled
cord. Also included are four inserts: one Time Schedule Overlay
(remove the paper backing), and three clear inserts with set point labels
(remove protective plastic backing).
the box. The ZT matches the most-used AHU configuration:
Mixed Air Single Path.
TE-6100 Zone Sensor
AS-FMK100 Function Module Kit
AS-RLY100 Relay Kit or M100C Actuator
AS-ZTUWMB Wall Mount Base
AS-ENC100 Enclosure
AS-ZTUUMB Utility Mounting Base With Screws
AS-ZTUBAG Carrying Case
AS-CBLPRO-1
IBM compatible computer or laptop
WS-SWHPRO-3 HVAC PRO Release 3
clear overhead transparency film for the customized inserts
AS-CBLCON-0 or AS-AHU101 and AS-FMK100
!
CAUTION: The ZT must be plugged into a 6-pin telephone-type
jack. Plugging the ZT into an 8-pin jack destroys the
8-pin receptacle and prevents the ZT from powering
up.
AS-CBLPRO-0 is not compatible for downloading.
