Installation Procedures

Flat-head Screwdriver

Tools Needed

Needle-nose Pliers
Drill
The ZT unit measures 6.88 x 7.31 x 1.52 in. (175 x 186 x 39 mm), and
Physical
weighs 1.25 lb (.57 kg). A coiled, 6-pin telephone-type cord is included.
Dimensions
The cord is 17 inches long and stretches to 5 feet. The ZT contains a five-
year lithium battery.
The Wall Mount Base with ZT measures 6.94 x 7.44 x 2.00 (176 x189 x
51 mm).
The Utility Mount Base with ZT measures 6.94 x 7.44 x 6.00 (176 x 189 x
152) when mounted on the AS-ENC100.
Installation of the Zone Terminal must meet the following standards:
Environmental
Information
G
G
G
Notes:
Cleaning of ZT
G
Surfaces
G
G
All manuals and user guides at all-guides.com
Ambient operating conditions: 32 to 122°F (0 to 50°C)
10 to 90% non-condensing relative humidity
86°F (30°C) maximum dew point
Do not mount the Zone Terminal in a vibration area.
The atmosphere must be free of corrosive chemical vapors which
may damage electronic equipment.
Use mild soap and water with a soft cloth to wipe surfaces of the ZT
clean.
DO NOT immerse the ZT unit in water.
Wipe clean with pure isopropyl alcohol, if surface becomes
excessively dirty.
Zone Terminal 13
