The right side of the ZT display includes 18 pairs of binary indicators—a
bar ( | ) for On, and a circle (❍) for Off. These symbols flash when the
respective binary point is in alarm.
Five LED's located in the bottom panel include four green Mode
Indicators and one red Alarm Indicator. The Alarm Indicator LED flashes
when any analog or binary point is in alarm.
Keys Refer to Figure 1 to locate each of the seven ZT keys.
4 Zone Terminal
All manuals and user guides at all-guides.com
Display Item List
Display Cursor Dot
OUTDOOR AIR
Display
STATIC STEPT
Key 1
MIXED AIR LL SP
NIGHT HTG STPT
NIGHT CLG STPT
COOL SET PT
HEAT SET PT
2
WARMCOOL ADJ
ACT CLG SP
ACT HTG SP
DISCH TEMP
3
ECON % OPEN
MIN POS % OPN
Mode
Operating Mode Indicator
Selector
MONITOR
Key
ADJUST
Mode
TIME SCHEDULE
PASSWORD
Selector
Panel
E N T E R
Door
Figure 1: The Zone Terminal
Key
Display Key 1, 2, 3
Moves the cursor through insert items
Operating Mode Moves the LED to the desired operating mode:
Selector Monitor, Adjust, Time Schedule, Password
(↑ ↑ ↑ ↑ ) or (↓ ↓ ↓ ↓ ) Adjust Up or Down changes the numbers in the
displays
Enter
Commits adjustments
Alarm Triangle
INSERT 12
ROOFTOP ZTU
Display Area 1 1
ZONE TEMP
Display Area 2
Display Area 3
CLG % ON
HTG % ON
Up/Down Arrow Keys
Description
On/Off Status
ON OFF
FAN
COOL STG #1
COOL STG #2
HEAT STG #1
HEAT STG #2
OCCUPIED
1
A/C LIM OPN
CHECK FAN
CHECK CLG
CHECK HTG
CHECK ECON
DIRTY FILTR
1
FAN STATUS
ECON ENABLE
TEMP OCC
WARMUP MODE
CLG LOCKOUT
HTG LOCKOUT
ALARM
Alarm Light
MAP1RT4
