ZT
Figure 14: Connecting the Zone Terminal
AS-AHU101
Note: 24 VAC, COM, and Zone Bus
wires of 18 AWG (500 ft. max.)
must be connected between screw
terminal strips.
AS-FMK100
AS-RLY100
M100C
TE-6100
UNT/VAV only
CONECT2
Zone Terminal 19
