The Zone Terminal can be connected directly to a VAV/UNT through a
Zone Sensor without the use of the AS-CBLCON-0 (Figure 16). This is a
portable application.
Zone Terminal
Figure 16: Remote Connect ZT to VAV/UNT Through the Zone Sensor
!
CAUTION: The ZT must be plugged into a 6-pin telephone-type
jack. Plugging the ZT into an 8-pin jack destroys the
8-pin receptacle and prevents the ZT from powering
up.
A NA LO G INP UTS
1
A NA LO G INP UTS
ANA LOG INPU TS
TE-6100
VAV/UNT
O F F
AS -UNT101-0
C
D
V
1 5
+
0- 10V DC
A NA LOG
B INA RY IN B INA RY O UTP UT OUT P UT
CO M
2 3 4 5 6 1 2 3 4 1 2 3 4 5 6 1 2
P W R
IN
24V
B IN A RY CO M 24VA C T O LOA DS
AC A NA LOG
CO M MO N
OUTP UT
COMMON
BINAR Y IN BINA RY OUT PU TS ANA OUT
CONCT3J
Zone Terminal 21
