- Page 1 chamberlaindiy.com.au chamberlaindiy.co.nz CS105MYQ Sectional Garage Door Opener Installation and Operating Instructions Owners Copy: SAVE THESE INSTRUCTIONS for future reference This manual contains IMPORTANT SAFETY information DO NOT PROCEED WITH THE INSTALLATION BEFORE READING THOROUGHLY...
-
Page 2: Table Of Contents
SAFETY INSTRUCTIONS WARNING Failure to comply with the following instructions may result in serious injury or property damage. • • Read and follow all instructions carefully. • The garage door opener is designed and tested to offer safe service provided it is installed and operated in strict accordance with the instructions in this manual. -
Page 3: Before You Begin
INTRODUCTION BEFORE YOU BEGIN: Look at the wall and ceiling above the garage door. (The opener and header bracket must be securely fastened to structural supports). Do you have a finished ceiling in your garage? If so, a support bracket and additional fastening hardware (not supplied) may be required. -
Page 4: Carton Inventory
INTRODUCTION CARTON INVENTORY Your garage door opener and rail are packed in a single carton. The SectionalLift Plus CS105MYQ opener cartons contain the opener, the rail, its fitting hardware and accessories. Opener Hardware bag E950C hand held transmitter (2) 10. Rail assembly E940C car visor transmitter (1) 11. -
Page 5: Tools Required
INTRODUCTION TOOLS REQUIRED Drill Bits HARDWARE PROVIDED Clevis pin 80 mm (Section 13) R clip (Section 13) Hexagonal head screw (Sections 15 & 17) Nut M8 (Sections 15 & 17) 1 (1x) 2 (1x) 3 (4x) 4 (4x) 5 (4x) Flat washer M8 (Sections 15 &... -
Page 6: Control Panel
White Common tterminal push button Ground White Common terminal for The Protector System (IR Beams) IR Sensor Grey Chamberlain IR Beam The Protector System (pulsing type only) Door-in-door Green For Door-in-door dry contact sensor: (see note below) Door-in-door Green Common terminal for Door-in-door dry sensor (4 & 5 are... -
Page 7: Assembly
ASSEMBLY SECTION ASSEMBLING THE 4 PIECE SEGMENTED RAIL The segmented rail is largely preassembled and consists of 4 parts. The carriage, push rod, release handle, the guide pulley and the lintel bracket with belt tensioner are in the front part (A). The seating for the drive shaft and the sprocket are in the rear part (B). -
Page 8: Installation
INSTALLATION Wear protective goggles when working overhead to protect your eyes from injury. Disengage all existing garage door locks to avoid damage to the garage door. To avoid serious personal injury from entanglement, remove all ropes connected to the garage door before installing the opener. - Page 9 INSTALLATION POSITION THE OPENER Disengage the trolley mechanism (see section “Operating the manual release”) and slide it back towards the powerhead. Secure the hanging push arm up into the rail assembly temporarily using tape or rope, to avoid a hazard. SECTIONAL DOOR You will need a 50 mm piece of timber or similar spacer to gauge the distance between door and rail.
- Page 10 INSTALLATION HANG THE OPENER fig.1 The opener must be securely fastened to a sound structural support above the opener. Postion the opener as in the previous step. Check the rail is centred over the door. Ensure the rail brackets (fig.1) is on the Powerhead end of the rail in a position as close to the opener as possible (X).
-
Page 11: Operate Manual Release
INSTALLATION ATTACH DOOR ARM TO TROLLEY Make sure the garage door is fully closed. Pull the manual Fig. 1 Fig. 2 release cord to disengage the trolley. Slide the trolley to around 300 mm from the header bracket. The straight door arm is already preassembled to the trolley. -
Page 12: Adjustment
ADJUSTMENT SECTION PROGRAM THE TRAVEL LIMITS AND FORCE SETTINGS Without a properly installed safety Travel limits regulate the points at which the door will stop when reversal system, persons (particularly moving UP or DOWN. The travel limit buttons are located under the small children) could be SERIOUSLY access cover on the rear panel (figure 1). - Page 13 ADJUSTMENT SECTION TEST THE SAFETY REVERSE SYSTEM The safety reverse system test is important. Garage door must reverse on contact with a 40 mm obstacle laid flat on the floor. Failure to properly adjust opener may result in serious personal injury from a closing garage door.
-
Page 14: Install The Protector System (Optional)
4 of the troubleshooting section). SAFETY FIRST! Whilst Chamberlain have engineered safety features into your garage door opener, we urge you to consider fitting The Protector System™ (IR Beams) to your new garage door opener. In many countries these devices are compulsory to assist in preventing serious injury or property damage. -
Page 15: Timer To Close
PROGRAMMING TIMER TO CLOSE FEATURE (TTC) Door may operate unexpectedly, therefore do not allow anything to stay in the path figure 1 of the door. Indicator LED The Timer to Close feature requires The Protector SystemTM (IR Beams) to be installed. Door Fully Closed Operation: This feature allows the door to automatically close from a fully... -
Page 16: Install Warning Labelss
PROGRAMMING INSTALL WARNING LABELS Keep children away when the door is moving. RISK OF ENTRAPMENT: Repeat Safety Reverse Test monthly. Door must reverse on contact with a 40mm chamberlaindiy.com.au obstacle placed on the floor. Keep children away when the door is moving. chamberlaindiy.co.nz Make necessary adjustments. -
Page 17: Wireless Programming
PROGRAMMING WIRELESS PROGRAMMING (OPTIONAL ACCESSORIES) Activate the opener only when door is in full view, free of obstruction and properly adjusted. No one should enter or leave garage while door is in motion. Do not allow children to operate push button(s) or transmitter(s). -
Page 18: Using Your Opener
MAINTAINENCE AND CARE OF YOUR OPENER REPLACE BATTERIES IN TRANSMITTERS USING YOUR OPENER Battery of the transmitter: Your opener can be activated by any of the following devices: The batteries in the transmitter have an extremely long life. If the •... -
Page 19: Accessories
ACCESSORIES Make life easier with these handy accessories. Convenient access Slimline visor Easily attaches to Smart lighting without using a remote works with the wall to control to brighten the remote control or key. any Security+ and both Security+ and whole garage. -
Page 20: Troubleshooting
ACCESSORIES ACCESSORIES Model E964M Car visor remote Model 1702AML Outside quick release Model E148M Wireless wall button Model 774AML Obstruction beams Model E950C Keyring remote Model M-BBU24V Model E840C/E840M Wireless keypad TROUBLE SHOOTING Opener doesn't operate from either door control or Door opens but won't close: transmitter: •... - Page 21 DIAGNOSTICS TROUBLE SHOOTING Your garage door opener is programmed with self-diagnostic capabilities. The UP and DOWN arrows on the garage opener flash the diagnostic codes. DIAGNOSTIC CODE SYMPTOM POSSIBLE RESOLUTION UP Arrow DOWN Arrow Flash(es) Flash(es) The garage door opener will not The Protector System™...
-
Page 22: Specifications
Operating Frequency......433.30/433.92/434.54 MHz Trademark of The Chamberlain Group LLC ® Registered Trademark of The Chamberlain Group LLC © 2022 The Chamberlain Group LLC... -
Page 23: Warranty
WARRANTY Warranty Registration Register your warranty at: chamberlaindiy.com.au/warranty chamberlaindiy.co.nz/warranty Get Connected with Additional purchase of the myQ Connectivity Kit is required to enable myQ functionality. Visit www.chamberlaindiy.com.au or www.chamberlaindiy.co.nz for more details. - Page 24 Unit is required; parts for “do it yourself” repairs. If our technical team need to see the Unit to determine the nature of the fault, Chamberlain may direct you to return the Unit to •...
