TOOLS REQUIRED

4

HARDWARE PROVIDED

5
1 (1x) 2 (1x)
7 (1x)
6 (1x)

COMPLETED INSTALLATION

6
As you proceed with the assembly, installation and adjustment procedures in this manual, you may find it helpful to refer back to
this illustration of a completed installation.
2
1
13
1. Header bracket
2. Belt
3. Rail
4. Trolley
5. Rail connecting piece
6. Rail bracket
7. Hanging bracket
8. Power cord
INTRODUCTION
Drill Bits
3 (4x)
4 (4x)
8 (4x)
9 (8x)
3
5
4
11
10
12
1.
2.
3.
4.
5 (4x)
5.
6.
10 (4x)
7.
8.
9.
10. Wallplug 8mm (Section 15)
7
15
6
9. Opener
10. Manual release rope & handle
11. Straight door arm
12. Curved door arm
13. Door bracket
14. C-Rail brackets
15. Centre rail bracket
5
Clevis pin 80 mm (Section 13)
R clip (Section 13)
Hexagonal head screw (Sections 15 & 17)
Nut M8 (Sections 15 & 17)
Flat washer M8 (Sections 15 & 17)
Clevis Pin (Section 17)
R clip (Section 17)
Screw ST6 x 50 mm (Section 12)
Screw ST6,3 x 18 mm (Sections 10 & 16)
14
8
9
