CARTON INVENTORY

2
Your garage door opener and rail are packed in a single carton. The SectionalLift Plus CS105MYQ opener cartons contain the
opener, the rail, its fitting hardware and accessories.
1. Opener
2. E950C hand held transmitter (2)
3. E940C car visor transmitter (1)
4. Curved door arm
5. Hanging bracket (2)
6. Rail bracket
7. Header bracket
8. Door bracket
1
6
14
RAIL DIMENSIONS
3
DOOR HEIGHT:
Sectional Doors
Up to 2.2 m
NOTE: The Ceiling Fixing Point is measured back from the lintel (see item 1 to 7 of "completed installation"). Also allow 400 mm
back from the fixing point for installation of the powerhead (item 7 to 9 of "completed installation").
INTRODUCTION
2
7
chamberlaindiy.com.au
chamberlaindiy.co.nz
Keep children away when the door is moving.
RISK OF ENTRAPMENT:
Repeat Safety Reverse Test
monthly. Door must reverse
on contact with a 40mm
obstacle placed on the floor.
Make necessary adjustments.
AUTOMATIC DRIVE:
Keep away from the area
of the door since it may
operate unexpectedly.
EMERGENCY RELEASE:
To release, pull down
firmly on the red handle.
BELT & RAIL PART
NUMBER:
8422 CR5
9. Hardware bag
10. Rail assembly
11. C-Rail bracket (2)
12. Centre Rail Bracket
13. Manual
14. Warning labels
3
8
13
Manual
Owners Copy: SAVE THESE INSTRUCTIONS for future reference
