Advantech ASMB-927 Startup Manual

ASMB-927 Dual LGA4677 4th Gen Intel
EATX Server Board with 16 DDR5, 4 PCIe x16, 9 SATA 3.0,
6 USB 3.2 (Gen1), Dual 10GbE, and IPMI
Startup Manual
Packing List
Before you begin installing your card, please make sure that
the following items have been shipped:
• 1 x ASMB-927 Startup Manual
• 1 x SATA data cable
• 1 x SATA power cable
• 2 x CPU power cables (8P)
• 2 x CPU carriers
• 1 x I/O port bracket
• 1 x M.2 screw
If any of these items are missing or damaged, please
contact your distributor or sales representative immediately.
Note 1: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
https://www.adobe.com/downloads.html
(Acrobat is a trademark of Adobe)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
For technical support and service, please visit our sup-
port website for ASMB-927 at:
https://advt.ch/asmb927
Register your products on our website and get 2
months extra warranty for free at:
http://www.register.advantech.com
This manual is for the ASMB-927 series Rev. A1
Part No. 2042092700
Printed in China
Specifications
Standard M/B Functions
• CPU: Dual LGA4677 4th Gen Intel® Xeon® Scalable
• BIOS: AMI 256 Mbit SPI BIOS
• Chipset: Intel® C741 PCH
• System Memory: 16 x DDR5 3200/3600/4000/4400/4800
• SATA Interface:
• Serial Ports: One onboard header, only supports RS-232
• Keyboard/Mouse Header: Supports the standard PS/2
• Watchdog Timer: 255 /sec or min level timer intervals
• USB Port: 6 x USB 3.2 Gen1 (4 rear and 2 onboard) and
VGA Interface
• Chipset: ASPEED AST2600
• Resolution: Supports VGA up to a resolution of 1920 x
Ethernet Interface
• Interface: 100M/1G/10Gbps
• Controller: LAN1/2: Intel® X710-AT2
Mechanical and Environment
• Dimensions (L x W): 304.8 x 330.2 mm (12" x 13")
• Power Supply Voltage: +3.3 V, +5 V, ±12 V, +5 Vs
• Power Consumption (mainboard only, excluding
• Operating Temperature: 0 ~ 40 °C (depending on CPU)
• Weight: 1.5 kg
1st Edition
January 2023
Xeon
®
processors
MT/s registered ECC DIMM, max. capacity 2 TB
- 8 x SATA 3.0 (6 Gb/s) via Mini SAS HD (SFF-8643),
supports software RAID 0,1,5,10
- 1 x SATA 3.0 (6 Gb/s)
keyboard and mouse via PS/2 cable.
3 x USB 2.0 (2 onboard and 1 Type-A)
1200 @ 60 Hz refresh rate.
I/O devices): Max. load: +3.3V@2.2A, +5V@1.9A,
+12V@0.3A, +5Vsb@0.1A, -12V@0A, 12V_8P@38.53A
ASMB-927 Startup Manual 1
Scalable
®
