2.2.8

FP_AUDIO (Front panel audio header)

8
Front panel audio Connector
9 10
1 2
Pin No.
1
2
3
4
5
6
7 JACKSENCE Detect
8
9
10
GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
Definition
MIC-LEFT
GND
MIC-RIGHT
Detect
LINE-RIGHT
GND
NC
LINE-LEFT
GND
Connector PN
725-81-10TW00
A2004WV-2X05P46
www.gigaipc.com
Pin1
Vendor
PINREX
JOINT-TECH
