Summary of Contents for Rigol DHO4000 Series
- Page 2 • RIGOL products are covered by P.R.C. and foreign patents, issued and pending. • RIGOL reserves the right to modify or change parts of or all the specifications and pricing policies at the company's sole decision. • Information in this publication replaces all previously released materials.
-
Page 3: Table Of Contents
Test Procedures......................5.3.4 Test Record From....................... DC Gain Accuracy Test......................18 5.4.1 Specification........................ 5.4.2 Test Connection Diagram..................5.4.3 Test Procedures......................5.4.4 Test Record From....................... DC Offset Accuracy Test....................5.5.1 Specification........................ Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... - Page 4 Test Connection Diagram..................5.6.3 Test Procedures......................5.6.4 Test Record From....................... Time Base Accuracy Test....................32 5.7.1 Specification........................ 5.7.2 Test Connection Diagram..................5.7.3 Test Procedures......................5.7.4 Test Record From....................... Appendix: Test Record Form....................35 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
- Page 5 Figure 5.3 DC Gain Accuracy Test Connection Diagram ..........Figure 5.4 DC Offset Accuracy Test Connection Diagram ......... Figure 5.5 Bandwidth Test Connection Diagram ............Figure 5.6 Time Base Accuracy Test Connection Diagram ........Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
- Page 6 List of Tables Table 2.1 Specifications ......................Table 5.1 Test Devices ......................11 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
-
Page 7: Safety Requirement
Do Not Insert Objects Into the Air Outlet. Do not insert objects into the air outlet, as doing so may cause damage to the instrument. • Use Proper Fuse. Please use the specified fuses. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 8: Safety Notices And Symbols
Do Not Operate With Suspected Failures. If you suspect that any damage may occur to the instrument, have it inspected by RIGOL authorized personnel before further operations. Any maintenance, adjustment or replacement especially to circuits or accessories must be performed by RIGOL authorized personnel. - Page 9 It calls attention to an operation, if not correctly performed, could result in damage to the product or other devices connected to the product. Safety Symbols on the Product: Hazardous Safety Warning Protective Earth Chassis Ground Test Ground Voltage Terminal Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
-
Page 10: Specifications
Specifications This chapter lists the technical specifications of the DHO4000 series oscilloscope. DHO4000 series digital oscilloscope achieves 4 GSa/s sample rate, a fast waveform capture rate of 1,500,000 wfms/s with the UltraAcquire mode, 500 Mpts memory depth, 12-bit vertical resolution, all combined with excellent noise floor performance and vertical accuracy to meet your requirements for more accurate measurements, bringing extraordinary T&M experience for you. - Page 11 Specifications Overview of the DHO4000 Series Technical Specifications 4 GSa/s (single channel ), 2 GSa/s (half channels ), 1 GSa/s (all channels Max. Analog Channel Note: The sample rate reaches 1 GSa/s when all channels Sample Rate are enabled. For DHO4804, the maximum analog bandwidth is only 400 MHz.
-
Page 12: Document Overview
RIGOL DHO4000 series digital oscilloscope. For the operation methods mentioned in the test procedures, refer to User Guide of this product. http:// For the latest version of this manual, download it from the official website of RIGOL ( www.rigol.com Publication Number... - Page 13 Document Overview Model Max. Analog Bandwidth No. of Analog Channels DHO4204 200 MHz DHO4404 400 MHz DHO4804 800 MHz Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
-
Page 14: Overview
Make sure that the oscilloscope has been warmed up or operating for more than 30 minutes before the self-calibration. 1. Disconnect all the input channels. 2. In "Utility" menu, click or tap SelfCal. The self-calibration interface will be displayed as shown below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 15: Test Result Record
It is recommended that users photocopy the test record form before each test and record the test results in the copy so that the form can be used repeatedly. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 16: Specifications
Overview Specifications The specification of each test item is provided in this manual. For other technical DHO4000 Data Sheet (download it from RIGOL website: parameters, refer to www.rigol.com All the specifications are valid only when the oscilloscope has been warmed up for more than 30 minutes. -
Page 17: Performance Verification Test
Performance Verification Test This chapter takes DHO4804 as an example to illustrate the performance verification test methods and procedures of DHO4000 series digital oscilloscope. This manual recommends the following test devices. You can also use other devices that fulfill the Table 5.1 Test Devices... -
Page 18: Test Procedures
Before test, disconnect the instrument from all the signal generators and keep the noise sources away from the instrument. 1. Press the front-panel key to restore the oscilloscope to the default settings. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 19: Test Record From
2.8 mV 4.3 mV 200 mV/div Full BW 2.6 mV 3.9 mV 7 mV 500 mV/div Full BW 4 mV 7 mV 10 mV 1 V/div Full BW 1 MΩ Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 20: Impedance Test
[1]: Test DHO4204 with full bandwidth 200 MHz; test DHO4404/DHO4804 with 250 MHz bandwidth limit. Impedance Test 5.2.1 Specification Input Impedance 1 MΩ: 0.99 MΩ to 1.01 MΩ Analog Channel 50 Ω: 49.5 Ω to 50.5 Ω Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 21: Test Connection Diagram
3. Turn on Fluke 9500B; set its impedance to 1 MΩ and select the resistance measurement function. Read and record the resistance measured. 4. Adjust the vertical scale of CH1 to 500 mV/div; read and record the resistance measured. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 22: Test Record From
Pass/Fail 50 mV/div 49.5 Ω to 50.5 Ω 500 mV/div 49.5 Ω to 50.5 Ω 50 mV/div 49.5 Ω to 50.5 Ω 500 mV/div 49.5 Ω to 50.5 Ω Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 23: Input Capacitance Test
To enable CH1, perform any of the following operations: - Click or tap the channel status label at the bottom of the screen to enable CH1. - Press the front-panel key to enable the channel. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 24: Test Record From
19 pF ± 3 pF 50 mV/div 19 pF ± 3 pF 500 mV/div 19 pF ± 3 pF DC Gain Accuracy Test 5.4.1 Specification DC Gain Accuracy Specification ±2% x Full Scale Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 25: Test Connection Diagram
Set the probe attenuation ratio to "1X". c. In the Vertical menu, click or tap 1 MΩ under Impedance to set the input impedance of CH1 to 1 MΩ. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... - Page 26 2. Turn on Fluke 9500B and set its impedance to 50 Ω. 3. Output a DC signal with +3 mV voltage (Vout1) via Fluke 9500B. 4. Configure the oscilloscope: Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
-
Page 27: Test Record From
100 mV/div ≤2% 200 mV/div ≤2% 500 mV/div ≤2% 1 V/div ≤2% 2 V/div ≤2% 5 V/div ≤2% 10 V/div ≤2% 1 mV/div ≤2% 2 mV/div ≤2% 5 mV/div ≤2% Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... - Page 28 50 mV/div ≤2% 100 mV/div ≤2% 200 mV/div ≤2% 500 mV/div ≤2% 1 V/div ≤2% 2 V/div ≤2% 5 V/div ≤2% 1 mV/div ≤2% 5 mV/div ≤2% 10 V/div ≤2% Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
- Page 29 500 mV/div ≤2% 1 V/div ≤2% 1 mV/div ≤2% 2 mV/div ≤2% 5 mV/div ≤2% 10 mV/div ≤2% 20 mV/div ≤2% 50 mV/div ≤2% 100 mV/div ≤2% 200 mV/div ≤2% Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
-
Page 30: Dc Offset Accuracy Test
1. Connect the active head of Fluke 9500B to CH1 of the oscilloscope, as shown in Figure 5.4 2. Set the impedance of Fluke 9500B to 1 MΩ. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 31: Test Record From
-509.51 mV -490.49 mV 100 μV/div -2.01 mV 2.01 mV CH1, 1 MΩ, 20 MHz BW 100 μV/div -500 mV 490.49 mV 509.51 mV 10 mV/div -1.01 V -982.00 mV Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... - Page 32 4.08 V 100 μV/div 500 mV -509.51 mV -490.49 mV CH3, 1 MΩ, 100 μV/div -2.01 mV 2.01 mV 20 MHz BW 100 μV/div -500 mV 490.49 mV 509.51 mV Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
- Page 33 982.99 mV 1.01 V CH4, 50 Ω, 20 MHz BW 200 mV/div -4.08 V -3.91 V 200 mV/div -22.00 mV 22.00 mV 200 mV/div -4 V 3.91 V 4.08 V Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
-
Page 34: Bandwidth Test
1. Connect the active head of Fluke 9500B to CH1 of the oscilloscope, as shown in Figure 5.5 2. Turn on Fluke 9500B and set its impedance to 1 MΩ. 3. Configure the oscilloscope: Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... - Page 35 9. Repeat Step 2-7. Measure Vrms1 and Vrms2, and calculate the amplitude loss of 500 mV/div vertical scale. 10. Turn off CH1. Measure CH2, CH3, and CH4 respectively using the method above and record the measurement results. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
- Page 36 7. Check the AC.RMS "Result" sidebar at the right section of the screen. Read and record the data as Vrms2. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
-
Page 37: Test Record From
-3 dB to 3 100 mV/div -3 dB to 3 50 mV/div -3 dB to 3 100 mV/div -3 dB to 3 500 mV/div -3 dB to 3 100 mV/div Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 38: Time Base Accuracy Test
Figure 5.6 Time Base Accuracy Test Connection Diagram 5.7.3 Test Procedures WARNING Before connecting, disconnecting, or moving the test hookup, disable the output of the signal generator to avoid causing the dangerous voltage. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... - Page 39 Then measure the offset (ΔT) of the middle point of the signal (namely the crossing point of the rising edge of the current signal and the trigger level line) relative to the screen center and record the measurement result. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
-
Page 40: Test Record From
[2]: For the number of years that the instrument has been used, please calculate it according to the date in the verification certificate provided when the instrument leaves factory. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification... -
Page 41: Appendix: Test Record Form
Appendix: Test Record Form Appendix: Test Record Form RIGOL DHO4000 Series Digital Oscilloscope Performance Verification Test Record Form Model: ________________ Tested by: ________________ Test Date: ________________ Random Noise Test Record Form Maximum Vertical Test Pass/ Bandwidth Scale Result Fail DHO4204 DHO4404 DHO4804 50 Ω... - Page 42 Input Capacitance Test Record Form Channel Vertical Scale Test Result Limit Pass/Fail 50 mV/div 19 pF ± 3 pF 500 mV/div 19 pF ± 3 pF 50 mV/div 19 pF ± 3 pF Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
- Page 43 500 mV/div ≤2% 1 V/div ≤2% 2 V/div ≤2% 5 V/div ≤2% 10 V/div ≤2% 1 mV/div ≤2% 2 mV/div ≤2% 5 mV/div ≤2% 10 mV/div ≤2% 20 mV/div ≤2% Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
- Page 44 Result 1 mV/div ≤2% 2 mV/div ≤2% 5 mV/div ≤2% 10 mV/div ≤2% 20 mV/div ≤2% 50 mV/div ≤2% 100 mV/div ≤2% 200 mV/div ≤2% 500 mV/div ≤2% Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
- Page 45 [1]: The calculation formula is |(Vavg1 - Vavg2) - (Vout1 - Vout2)|/Full Scale x 100%; wherein, Vout1 is 3 x the current vertical scale and Vout2 is -3 x the current vertical scale. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
- Page 46 98.49 V 101.50 V 100 μV/div -1.01 V -982.99 mV CH2, 50 Ω, 100 μV/div -2.01 mV 2.01 mV 20 MHz BW 100 μV/div -1 V 982.99 mV 1.01 V Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
- Page 47 -502.00 mV 502.00 mV 5 V/div -100 V 98.49 V 101.50 V 100 μV/div -1.01 V -982.99 mV CH4, 50 Ω, 20 MHz BW 100 μV/div -2.01 mV 2.01 mV Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
- Page 48 -3 dB to 3 100 mV/div -3 dB to 3 500 mV/div -3 dB to 3 100 mV/div -3 dB to 3 50 mV/div -3 dB to 3 100 mV/div Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
- Page 49 [2]: For the number of years that the instrument has been used, please calculate it according to the date in the verification certificate provided when the instrument leaves factory. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. DHO4000 Performance Verification...
