Rigol DHO4204 Quick Manual

Digital oscilloscope

Hide thumbs Also See for DHO4204:

Performance verification manual (50 pages)

Table Of Contents

Table of Contents

Quick Links

Download this manual

Table of Contents

Summary of Contents for Rigol DHO4204

Page 2 • RIGOL products are covered by P.R.C. and foreign patents, issued and pending. • RIGOL reserves the right to modify or change parts of or all the specifications and pricing policies at the company's sole decision. • Information in this publication replaces all previously released materials.
Page 3: Safety Requirement
Indicates a potentially hazardous situation or practice which, if not avoided, will result in serious injury or death. CAUTION Indicates a potentially hazardous situation or practice which, if not avoided, could result in damage to the product or loss of important data. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 4: Measurement Category
Measurement category III is for measurements performed in the building installation. Examples are measurements on distribution boards, circuit-breakers, wiring (including cables, bus-bars, junction boxes, switches and socket-outlets) in the fixed installation, and equipment for industrial use and some other Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 5: Ventilation Requirement
Below +60℃: ≤90% RH (without condensation) WARNING To avoid short circuit inside the instrument or electric shock, never operate the instrument in a humid environment. Altitude • Operating: below 3 km • Non-operating: below 15 km Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 6: Care And Cleaning
For example, outdoor areas. Safety Class Class 1 – Grounded Product Care and Cleaning Care Do not store or leave the instrument where it may be exposed to direct sunlight for long periods of time. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 7: Environmental Considerations
Please contact your local authorities for disposal or recycling information. https://int.rigol.com/services/services/declaration You can click on the following link to download the latest version of the RoHS&WEEE certification file. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 8: Document Overview
This manual gives you a quick overview of the front and rear panel, user interface as well as basic operation methods of DHO4000 series. http:// For the newest version of this manual, download it from RIGOL official website ( www.rigol.com Publication Number...
Page 10: General Inspection
The consigner or carrier shall be liable for the damage to the instrument resulting from shipment. RIGOL would not be responsible for free maintenance/rework or replacement of the instrument. 2. Inspect the instrument In case of any mechanical damage, missing parts, or failure in passing the electrical and mechanical tests, contact your RIGOL sales representative.
Page 11: Product Overview
DHO4000 series digital oscilloscope is designed to meet the requirements for the design, debug, and test of the mainstream oscilloscope market. Adopting the brand- new chipset "Centaurus" developed by RIGOL, this series achieves a fast waveform capture rate of 1,500,000 wfms/s with the UltraAcquire mode, 500 Mpts memory depth, 12-bit resolution, all combined with excellent noise floor performance and vertical accuracy to meet your requirements for more accurate measurements.
Page 12: Rear Panel Overview
10 MHz Reference Clock Output Connector Snap-fit Grooves for Battery Pack HDMI Connector USB DEVICE Port LAN Port AC Power Cord Connector Fuse Battery Pack Connector Security Lock Hole Snap-in Slots for Battery Pack Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 13: User Interface Overview
Result Sidebar Run State Label Notification Area Horizontal Timebase Label Split-screen Display Sample Rate & Memory Depth Math Labels Label Horizontal Delay Label Channel Labels Trigger Label Function Navigation Icon Function Toolbar Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 14: To Prepare For Use
The power requirements of the oscilloscope are 100-240 V, 50-60 Hz. Please use the power cord provided in the accessories to connect the oscilloscope to the AC power source, as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 15: Turn-On Checkout
Press the power switch and a prompt message "Are you sure to shutdown?" is displayed. Click or tap OK to shut down the instrument. Press twice to directly shut down the instrument. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 16: Setting The System Language
> Utility > Setup > Language to select the system language. Connecting Probes RIGOL provides passive and active probes for DHO4000 series. For specific probe DHO4000 series Data Sheet . For detailed technical information models, please refer to of the probes, please refer to the corresponding Probe User Guide.
Page 18: Function Inspection
4. Set the probe ratio based on the attenuation of the probe, and then click or tap > Auto. 5. Observe the waveform on the display. In normal condition, you should see a square waveform similar to the waveform shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 19: Probe Compensation
2. Check the displayed waveforms and compare them with waveforms shown in the figure below. Figure 5.8 Probe Compensation 3. Use the probe compensation adjustment tool provided in the accessories to adjust the low-frequency compensation adjustment hole on the probe until the displayed Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 21: Touchscreen Gestures
Use one finger to select the object, and then drag the object to a destination place, as shown in the figure below. With the drag gesture, you can perform the following operation: Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 22 • Pinching&stretching in the horizontal direction can adjust the horizontal time base of the waveform. • Pinching&stretching in the vertical direction can adjust the vertical scale of the waveform. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 24 Click or tap > Help to access the "Help" menu. After that, you can get its help information by clicking on or tapping the link for the desired item. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 25: Parameter Setting Method
At this time, the unit of the parameter is the default unit. In the numeric keypad, you can perform the following operations: • Delete the parameter value that has been input; Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 26 Parameter Setting Method • Set the parameter value to a maximum or minimum value; • Set the parameter to a default value. • Clear the parameter input field. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 27: Replacing The Fuse
To avoid electric shock, please make sure that the instrument is powered off and disconnected from the power before replacing the fuse. Also, please make sure the fuse is consistent with the required fuse rating. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 28: Remote Control
When you first log in to the Web Control, the user name is "admin" and password is "rigol". This instrument can be connected to the PC via the USB, LAN, or GPIB interface to set up communication and realize remote control through the PC.
Page 29: More Product Information
For details, refer to descriptions in this series User Guide. For more information about the instrument, refer to the relevant manuals by logging in to the official website of RIGOL ( http://www.rigol.com ) to download them.

This manual is also suitable for:

Dho4000 series Dho4404 Dho4804
