Rigol MHO5000 Series Performance Verification Manual

Rigol MHO5000 Series Performance Verification Manual

Digital oscilloscope
Hide thumbs Also See for MHO5000 Series:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MHO5000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rigol MHO5000 Series

Summary of Contents for Rigol MHO5000 Series

  • Page 2 • RIGOL products are covered by P.R.C. and foreign patents, issued and pending. • RIGOL reserves the right to modify or change parts of or all the specifications and pricing policies at the company's sole decision. • Information in this publication replaces all previously released materials.

  • Page 3: Table Of Contents

    ...........................20 5.4.2 Test Connection Diagram ....................20 5.4.3 Test Procedures ........................21 5.4.4 Test Record Form ........................23 5.5 DC Offset Accuracy Test ........................28 5.5.1 Specification ...........................28 5.5.2 Test Connection Diagram ....................28 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 4 5.7 Time Base Accuracy Test .........................38 5.7.1 Specification ...........................38 5.7.2 Test Connection Diagram ....................38 5.7.3 Test Procedures ........................38 5.7.4 Test Record Form ........................40 6 Appendix: Test Record Form ..................41 MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...

  • Page 5: Safety Requirement

    Do Not Insert Objects into the Air Outlet. Do not insert objects into the air outlet, as doing so may cause damage to the instrument. • Use Proper Fuse. Please use the specified fuses. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 6 Do Not Operate With Suspected Failures. If you suspect that any damage may occur to the instrument, have it inspected by RIGOL authorized personnel before further operations. Any maintenance, adjustment or replacement especially to circuits or accessories must be performed by RIGOL authorized personnel.

  • Page 7: Safety Notices And Symbols

    It calls attention to an operation, if not correctly performed, could result in damage to the product or other devices connected to the product. Safety Symbols on the Product: Hazardous Safety Warning Protective Earth Chassis Ground Test Ground Voltage Terminal Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...

  • Page 8: Specifications

    No. of Input Channels DHO5054/DHO5104: 4 analog channels + 1 EXT channel DHO5058/DHO5108: Max. Sample Rate 4 GSa/s (single-channel & half-channel ), 2 GSa/s (full- of Analog channel Channel DHO5054/DHO5104: MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 9 Input Impedance 1 MΩ ± 1%, 50 Ω ± 1% Input Capacitance 19 pF ± 3 pF Bandwidth Limit 20 MHz, 250 MHz, FULL; selectable for each channel (Typical) Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 10 [2]: Half-channel: when CH1, CH3, CH5, and CH7 are all enabled or when CH2, CH4, CH6, and CH8 are all enabled, it is called half-channel mode. [3]: Full-channel mode: If all of the channels are enabled, it is called full-channel mode. MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...

  • Page 11: Document Overview

    Document Overview Document Overview http:// For the latest version of this manual, download it from the official website of RIGOL ( www.rigol.com Publication Number PVA43100-1110 Software Version Software upgrade might change or add product features. Please acquire the latest version of the manual from RIGOL website or contact RIGOL to upgrade the software.
  • Page 12 Unless otherwise specified, this manual takes DHO5108 as an example to illustrate the operation methods of MHO/DHO5000 series. The digital analysis, function/ arbitrary waveform generator and Bode plot are illustrated by the MHO5104 model. MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...

  • Page 13: Overview

    Make sure that the oscilloscope has been warmed up or operating for more than 30 minutes before the self-calibration. 1. Disconnect all the input channels. 2. In "Utility" menu, click or tap SelfCal, the following self-calibration interface is shown below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...

  • Page 14: Test Result Record

    Specifications The specification of each test item is provided in this manual. For other technical parameters, refer to MHO/DHO5000 DataSheet (available to download from RIGOL http://www.rigol.com website: MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 15 Overview All the specifications are only valid when the oscilloscope has been warmed up for more than 30 minutes under the specified operating temperature (18℃ to 28℃). Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...

  • Page 16: Performance Verification Test

    Random noise, typical (input impedance 50 Ω, sample rate 4 GSa/s, memory depth 1 Mpts, timebase 20 μs) Vertical Scale (V/div) 1 GHz Bandwidth 31.2 μV 100 μV/div 66 μV 200 μV/div 74.4 μV 500 μV/div 139.2 μV 1 mV/div MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 17 1 mV/div 127.2 μV 2 mV/div 153.6 μV 5 mV/div 270 μV 10 mV/div 331.2 μV 20 mV/div 614.4 μV 50 mV/div 3 mV 100 mV/div 3.6 mV 200 mV/div Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...

  • Page 18: Test Connection Diagram

    20 MHz. 4. By default, the acquisition mode is Normal; the sample rate is 4 GSa/s. Set the horizontal timebase to 20 μs/div; set the memory depth to 1 Mpts. MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...

  • Page 19: Test Record Form

    130.8 μV 1 mV/div 127.2 μV 2 mV/div 153.6 μV 5 mV/div 270 μV 10 mV/div Full BW 331.2 μV 20 mV/div 614.4 μV 50 mV/div 3 mV 100 mV/div Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...

  • Page 20: Impedance Test

    Impedance test when the input impedance is 1 MΩ 1. Connect the active head of Fluke 9500B to CH1 of the oscilloscope, as shown in Figure 5.1 2. Configure the digital oscilloscope: a. Enable the channel: MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...

  • Page 21: Test Record Form

    Read and record the measurement results. 5.2.4 Test Record Form 1 MΩ Input Impedance Channel Vertical Scale Test Result Limit Pass/Fail 50 mV/div 500 mV/div 0.99 MΩ to 1.01 MΩ 50 mV/div 500 mV/div Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...

  • Page 22: Input Capacitance Test

    50 mV/div 500 mV/div 50 mV/div 500 mV/div 50 mV/div 500 mV/div 50 mV/div 500 mV/div Input Capacitance Test 5.3.1 Specification Input Capacitance Specification 19 pF ± 3 pF MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...

  • Page 23: Test Connection Diagram

    4. Adjust the vertical scale of CH1 to 500 mV/div. Read and record the capacitance measured. 5. Disable CH1. Test the capacitance of CH2, CH3, CH4, CH5, CH6, CH7, and CH8 respectively. Read and record the measurement results. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...

  • Page 24: Test Record Form

    500 mV/div DC Gain Accuracy Test 5.4.1 Specification DC Gain Accuracy ±2% (<5 mV) Specification ±1% (≥5 mV) 5.4.2 Test Connection Diagram DHO5108 Fluke 9500B Figure 5.4 Test Connection Diagram MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...

  • Page 25: Test Procedures

    "result" list and record the measurement result of V 6. Adjust Fluke 9500B to make it output a DC signal whose output voltage (V 2) is -3 mV Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 26 Then click or tap the input field for the Averages menu item to set it to 32 by using the pop-up numeric keypad. h. Adjust the trigger level to avoid mis-triggering. MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...

  • Page 27: Test Record Form

    ≤1% 100 mV/div 200 mV/div 500 mV/div 1 V/div 1 mV/div ≤2% 2 mV/div 5 mV/div 10 mV/div 20 mV/div 50 mV/div ≤1% 100 mV/div 200 mV/div 500 mV/div Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 28 200 mV/div 500 mV/div 1 V/div 1 mV/div ≤2% 2 mV/div 10 mV/div 20 mV/div 50 mV/div 100 mV/div ≤1% 200 mV/div 500 mV/div 1 V/div 1 mV/div ≤2% MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 29 10 V/div 1 mV/div ≤2% 2 mV/div 5 mV/div 10 mV/div 20 mV/div 50 mV/div 100 mV/div 200 mV/div ≤1% 500 mV/div 1 V/div 2 V/div 5 V/div 10 V/div Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 30 ≤2% 2 mV/div 5 mV/div 10 mV/div 20 mV/div 50 mV/div 100 mV/div 200 mV/div ≤1% 500 mV/div 1 V/div 2 V/div 5 V/div 10 V/div 1 mV/div ≤2% MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 31 1 mV/div ≤2% 2 mV/div 5 mV/div 10 mV/div 20 mV/div 50 mV/div 100 mV/div 200 mV/div ≤1% 500 mV/div 1 V/div 2 V/div 5 V/div 10 V/div NOTE Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...

  • Page 32: Dc Offset Accuracy Test

    Click or tap the channel status label at the bottom of the screen. The "Vertical" system menu is displayed. Click or tap to select 1 MΩ for Impedance to set the input impedance of CH1 to 1 MΩ. MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...

  • Page 33: Test Record Form

    1 V/div -20 V 19.70 V 20.30 V 5 V/div 100 V -101.50 V -98.50 V 5 V/div -502.00 mV 502.00 mV 5 V/div -100 V 98.50 V 101.50 V Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 34 -12.00 mV 12.00 mV CH3, 50 Ω, 100 mV/div -1 V 0.97 V 1.03 V 20 MHz BW 200 mV/div -4.08 V -3.92 V 200 mV/div -22.00 mV 22.00 mV MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 35 -0.98 V 10 mV/div -3.00 mV 3.00 mV CH6, 1 MΩ, 20 MHz BW 10 mV/div -1 V 0.98 V 1.02 V 200 mV/div 10 V -10.17 V -9.83 V Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 36 200 mV/div -10 V 9.83 V 10.17 V 1 V/div 20 V -20.30 V -19.70 V 1 V/div -102.00 mV 102.00 mV 1 V/div -20 V 19.70 V 20.30 V MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...

  • Page 37: Bandwidth Test

    1). Wherein, V 1 is the measurement result of amplitude effective value at 1 MHz and V 2 is the measurement result of amplitude effective value value at full bandwidth. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...

  • Page 38: Test Connection Diagram

    CH1 to 1 MΩ. d. Set the vertical scale to 50 mV/div. e. Set the vertical offset to 0 V. Then close the Vertical system menu. MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 39 - Click or tap the CH1 channel status label at the bottom of the screen to enable CH1. - Press the front-panel key to enable CH1. - In the Vertical menu, select the CH1 tab. Select ON for the Display menu to enable CH1. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...

  • Page 40: Test Record Form

    Read and record the measurement results. 5.6.4 Test Record Form 50 Ω Input Impedance Test Result Vertical Channel Limit Pass/Fail Amplitude Scale Loss 100 mV/div -3 dB to 3 dB 500 mV/div MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 41 50 mV/div 500 mV/div 50 mV/div 500 mV/div -3 dB to 3 dB 50 mV/div 500 mV/div 50 mV/div 500 mV/div 50 mV/div 500 mV/div 50 mV/div 500 mV/div NOTE Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...

  • Page 42: Time Base Accuracy Test

    1. Connect the active head of Fluke 9500B to CH1 of the oscilloscope, as shown in Figure 5.1 2. Output a Sine signal with 10 MHz frequency and 1 Vpp amplitude via Fluke 9500B. 3. Configure the digital oscilloscope: MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 43 1 ns/1 ms = 1 ppm. 6. Calculate the timebase accuracy limit according to the formula "±(1.5 ppm + 1 ppm/year × Number of Years that the Instrument Has Been Used)". Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...

  • Page 44: Test Record Form

    [1]: Calculation Result = Test Result ΔT/1 ms. [2]: For the number of years that the instrument has been used, please calculate according to the date in the verification certificate provided when the instrument leaves factory. MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...

  • Page 45: Appendix: Test Record Form

    Appendix: Test Record Form Appendix: Test Record Form RIGOL MHO/DHO5000 Series Digital Oscilloscope Performance Verification Test Record Form Model: ________________ Tested by: ________________ Test Date: ________________ Random Noise Test Record Form Vertical Scale Bandwidth Test Result Max. Value Pass/Fail 50 Ω...
  • Page 46 50 mV/div 500 mV/div 50 mV/div 500 mV/div 49.5 Ω to 50.5 Ω 50 mV/div 500 mV/div 50 mV/div 500 mV/div 50 mV/div 500 mV/div 50 mV/div 500 mV/div MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 47 50 mV/div 100 mV/div 200 mV/div ≤1% 500 mV/div 1 V/div 2 V/div 5 V/div 10 V/div 1 mV/div ≤2% 2 mV/div 5 mV/div 10 mV/div ≤1% 20 mV/div Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 48 100 mV/div 200 mV/div ≤1% 500 mV/div 1 V/div 2 V/div 5 V/div 10 V/div 1 mV/div ≤2% 2 mV/div 5 mV/div 10 mV/div ≤1% 20 mV/div 50 mV/div MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 49 200 mV/div ≤1% 500 mV/div 1 V/div 2 V/div 5 V/div 10 V/div 1 mV/div ≤2% 2 mV/div 5 mV/div 10 mV/div 20 mV/div ≤1% 50 mV/div 100 mV/div Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 50 1 mV/div ≤2% 2 mV/div 5 mV/div 10 mV/div 20 mV/div 50 mV/div ≤1% 100 mV/div 200 mV/div 500 mV/div 1 V/div 1 mV/div ≤2% 2 mV/div 5 mV/div ≤1% MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 51 1 mV/div ≤2% 2 mV/div 10 mV/div 20 mV/div 50 mV/div 100 mV/div ≤1% 200 mV/div 500 mV/div 1 V/div 1 mV/div ≤2% 2 mV/div 10 mV/div ≤1% 20 mV/div Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 52 98.50 V 101.50 V 100 mV/div -1.03 V -0.97 V CH1, 50 Ω, 100 mV/div -12.00 mV 12.00 mV 20 MHz BW 100 mV/div -1 V 0.97 V 1.03 V MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 53 0.97 V 1.03 V CH3, 50 Ω, 20 MHz BW 200 mV/div -4.08 V -3.92 V 200 mV/div -22.00 mV 22.00 mV 200 mV/div -4 V 3.92 V 4.08 V Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 54 3.00 mV CH6, 1 MΩ, 10 mV/div -1 V 0.98 V 1.02 V 20 MHz BW 200 mV/div 10 V -10.17 V -9.83 V 200 mV/div -22.00 mV 22.00 mV MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 55 1 V/div 20 V -20.30 V -19.70 V 1 V/div -102.00 mV 102.00 mV 1 V/div -20 V 19.70 V 20.30 V 5 V/div 100 V -101.50 V -98.50 V Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
  • Page 56 Bandwidth Test Record Form: 50 Ω Input Impedance Test Result Vertical Channel Limit Pass/Fail Amplitude Scale Loss 100 mV/div -3 dB to 3 dB MHO/DHO5000 Performance Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. Verification...
  • Page 57 [1]: Calculation Result = Test Result ΔT/1 ms. [2]: For the number of years that the instrument has been used, please calculate according to the date in the verification certificate provided when the instrument leaves factory. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 Performance Verification...
