Page 19: Safety Requirement
Do Not Insert Objects Into the Air Outlet. Do not insert anything into the holes of the fan to avoid damaging the instrument. • Use Proper Fuse. Please use the specified fuses. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 20 • Do Not Operate With Suspected Failures. If you suspect damage occurs to the instrument, have it inspected by RIGOL authorized personnel before further operations. Any maintenance, adjustment or replacement especially to circuits or accessories must be performed by RIGOL authorized personnel.
Page 21: Safety Notices And Symbols
Voltage Terminal Measurement Category Measurement Category This instrument can make measurements in Measurement Category I. WARNING This instrument can only be used for measurements within its specified measurement categories. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 22: Ventilation Requirement
Working Environment Temperature Operating: -10℃ to +50℃ Non-operating: -30℃ to +60℃ Humidity • Operating: Below +30℃: ≤90%RH (without condensation) +30℃ to +40℃: ≤75% RH (without condensation) MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 23 The pollution has no effect. For example, a clean room or air-conditioned office environment. • Pollution Degree 2: Normally only nonconductive pollution occurs. Temporary conductivity caused by condensation is to be expected. For example, indoor environment. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 24: Care And Cleaning
The equipment may contain substances that could be harmful to the environment or human health. To avoid the release of such substances into the environment and avoid harm to human health, we recommend you to recycle this product MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 25 Please contact your local authorities for disposal or recycling information. https://int.rigol.com/services/services/declaration You can click on the following link to download the latest version of the RoHS&WEEE certification file. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 26: Product Features
The MHO/DHO5000 series is a 8-CH high-resolution digital oscilloscope designed for the vast mainstream digital oscilloscope market to meet the design, debugging, and test demands. It is developed based on RIGOL's brand new self-developed Centaurus technical platform. Its 1,000,000 wfms/s waveform capture rate (in fast recording mode), 500 Mpts memory depth, 12-bit resolution, excellent noise floor and vertical measurement accuracy can meet the test demands for higher accuracy.
Page 27 [2]: Only MHO5054 and MHO5104 models support configuring the AFG option. [3]: Digital signal analysis is only available for the MHO series. [4]: The Bode plot function is only available for MHO5054 and MHO5104 models. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 28: Document Overview
This manual gives you a quick overview of the front and rear panel, user interface as well as basic operation methods of MHO/DHO5000 series. http:// For the latest version of this manual, download it from the official website of RIGOL ( www.rigol.com Publication Number...
Page 29 Analog channels supported by each model: DHO5058/DHO5108: CH1 to CH8 DHO5054/DHO5104: CH1 to CH4 MHO5056/MHO5106: CH1 to CH6 MHO5054/MHO5104: CH1 to CH4 • Only MHO series models support digital channels: D0 to D15 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 30 Unless otherwise specified, this manual takes DHO5108 as an example to illustrate the operation methods of MHO/DHO5000 series. The digital analysis, function/ arbitrary waveform generator and Bode plot are illustrated by the MHO5104 model. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 31: Quick Start
The consigner or carrier shall be liable for the damage to the instrument resulting from shipment. RIGOL would not be responsible for free maintenance/rework or replacement of the instrument. 2. Inspect the instrument In case of any mechanical damage, missing parts, or failure in passing the electrical and mechanical tests, contact your RIGOL sales representative.
Page 33: Appearance And Dimensions
To Adjust the Supporting Legs Adjust the supporting legs properly to use them as stands to tilt the oscilloscope upwards for stable placement of the oscilloscope to better operate and observe. You Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 34: To Connect To Ac Power
AC power source, as shown in the figure below. Power Cord Connector Figure 4.7 Connect to AC Power WARNING To avoid electric shock, ensure that the instrument is correctly grounded. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 35: Turn-On Checkout
2. Insert a small straight screwdriver into the slot at the power socket and pry out the fuse holder gently. 3. Remove the fuse. 4. Insert the proper fuse into the fuse holder. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 36: To Set The System Language
Setup > Language to select the system language. 4.4.6 To Connect the Probe RIGOL provides the passive probe, active probe, and logic probe for MHO/DHO5000 MHO/DHO5000 Data Sheet . For series. For specific probe models, please refer to detailed technical information of the probes, please refer to the corresponding Probe User Guide.
Page 37: Figure 4.9 Connect The Passive Probe
2. Connect the other end of the preamp to an analog channel input terminal of the oscilloscope on the front panel, as shown in the figure below. Note that you need to push the probe to the due position to lock it firmly. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 38: Figure 4.11 Connect The Active Probe
2. Connect the other terminal of the logic probe to the signal terminal under test. MHO/DHO5000 provides the optional PLA3204 active logic probe. For details, User Guide for PLA3204 Logic Probe . refer to MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 39: Function Inspection
2. Connect the ground alligator clip of the probe to the "Ground Terminal" as shown Figure 4.13 3. Use the probe to connect the input terminal of CH1 and the "Compensation Signal Output Terminal" of the probe, as shown in Figure 4.13 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 40: Figure 4.13 Use The Compensation Signal
To avoid electric shock when using the probe, please make sure that the insulated wire of the probe is in good condition. Do not touch the metallic part of the probe when the probe is connected to high voltage source. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 41: Probe Compensation
RIGOL MHO/DHO5000 series is a high-resolution digital oscilloscope designed for the vast mainstream digital oscilloscope market to meet the design, debugging, and test demands. It is developed based on RIGOL's brand new self-developed Centaurus technical platform. Its 4 GSa/s sample rate, 1 GHz real-time bandwidth, 1,000,000...
Page 42: Figure 4.16 Mho5104 Front Panel
Vertical Control Area Probe Compensation Signal Output Multifunction Knobs Terminal/Ground Terminal Measure Key Horizontal Control Area Cursor Key Analog Channel Input Terminals Analyse Key Digital Channel Input (Type-C Interface) MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 43: Front Panel Function Overview
(knob 2) of the math/reference waveform. You can click or tap Flex Knob on the Toolbar at the upper-right of the screen to set the priority. - Automatic: Cursor > (Math/Ref/Decode) > Intensity (default priority). Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 44: Menu Operation
6. Touch Lock Key : press this key to disable the touch screen. Once disabled, press this key again to enable the touch screen. 7. Common Operation Keys MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 45 : force trigger key. Press this key to generate a trigger signal forcibly. LEVEL: used to modify the trigger level/threshold level. Rotate it clockwise to increase the level, and rotate it counterclockwise to decrease the level. Press Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 46 You can enable or disable any channel or channel group, modify the waveform size of the digial channels, modify the threshold, group the 16 digital channels, etc. Besides, you can set the label for each digital channel. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 47 Press down this knob, then you can rotate it to switch between the coarse and fine adjustment of the horizontal scale. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 48 Supports FAT32 format Flash type USB storage device and the USB-GPIB module. - USB storage device: imports or exports data (software update, waveform, setup, or captured image). - USB-GPIB module: extends the GPIB interface for RIGOL instruments that integrates the USB HOST interface but not the GPIB interface. 17. Power Key Powers on or off the instrument.
Page 49: Rear Panel Overview
Connect the instrument to the PC via this interface. Then you can use the PC software to send the SCPI commands or use the user-defined programming to control the instrument. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 50: Trigger Output
[AUX OUT] connector when a passed or failed waveform is detected during the pass/fail test. 14. EXT TRIG BNC connector. The external trigger signal is input to the oscilloscope via this connector. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 51: User Interface Overview
This chapter takes the MHO5104 model with digital channels and arbitrary waveform generator (AFG) features, and the eight-channel DHO5108 model as examples to introduce the user Interface. Figure 4.19 DHO5108 User Interface Figure 4.20 MHO5104 User Interface Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 52 You can click or tap this area to open the "Utility" menu. - USB storage device icon: When a USB storage device is detected, will be displayed. - LAN icon: When the LAN interface is successfully connected, is displayed. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 53 NOTE [1]: Digital channels are only available for MHO5054, MHO5104, MHO5056, and MHO5106 models. [2]: Function/Arbitrary Waveform Generator (AFG) is the optional configuration only for MHO5054 and MHO5104 models. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 54: Touch Screen Gestures
To zoom in the waveform, first pinch the two fingers and then stretch the fingers; to zoom out the waveform, first stretch the two fingers, and then pinch the MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 55: Drag
Drag the cursor to move the cursor. • Drag the trigger cursor to change the trigger level. • In multi-window display, drag one of the displayed windows to change its position on the display. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 56: Rectangle Drawing
At this time, you can tap to select "Trigger zone A", "Trigger zone B", "Histogram", "Horizontal zoom out", "Vertical zoom out", or "Waveform zoom out". Figure 4.24 Rectangle Drawing Gesture (a) MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 57: Figure 4.25 Rectangle Drawing Gesture (B)
Waveform zoom out: compresses the waveforms both in the horizontal and vertical direction. • Click or tap the "DrawRect" icon to switch between the rectangle drawing and waveform operation. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 58: Parameter Setting Method
Uppercase/Lowercase Switchover Name Input Area Virtual Keypad Backspace Key Confirm Input Input Method Switch to Numbers Clear Key Space Key Switchover And Symbols Figure 4.26 English Input Interface 1. Select English input method MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 60: Figure 4.27 Chinese Input Interface
Backspace key in the virtual keypad to delete the characters. To modify the characters that have been input, delete the unwanted characters first and then input the new characters. 5. Confirm the input MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 61: Figure 4.28 Numeric Keypad
Set the parameter to a maximum or minimum value (sometimes, the maximum or minimum value are the specified one for the current state); • Set the parameter to a default value; • Clear the parameter input field. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 62: To Use The Security Lock
This series oscilloscope provides multiple options to fulfill your measurement requirements. If you need any of these options, order them according to the Order No. available in "Appendix A: Options and Accessories", and then install the options MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 63 Then, you can install the option according to the following steps. 1. Obtain an option license http://www.rigol.com a. Log in to the RIGOL official website ( ), click SERVICE CENTRE > License Activation to enter the license activation interface. b. Input the correct key, serial number (click or tap the function navigation icon >...
Page 64: Vertical System
CH1 on, and select OFF to turn CH1 off. When CH1 is activated, its status label at the bottom of the screen is as shown in the figure below. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 65 In addition, you can click or drag to slide down the channel label to disable the channel. If CH1 is disabled, its status label is as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 66: To Adjust The Vertical Scale
In the Vertical menu, click or tap the ON/OFF tab for Fine to toggle between ON (fine adjustment) and OFF (coarse adjustment). The default setting is OFF. You can also press down the Vertical SCALE knob to toggle between "coarse adjustment" and "fine adjustment". MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 67: To Adjust The Vertical Offset
Offset to increase or decrease the offset value or use the specified multifunction knob to set the value. You can also click or tap the input field of Offset to input a specific value with the pop-up numeric keypad. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 68: Channel Coupling
This oscilloscope supports the bandwidth limit function. Setting the bandwidth limit can reduce the noises in the displayed waveforms. For example, the signal under test is a pulse with high frequency oscillation. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 69: Input Impedance
50 Ω: makes the oscilloscope match the device whose output impedance is 50 Ω. After the oscilloscope switches to the 50 Ω mode, the circuit diagram in the Vertical menu will also be changed, as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 70: Waveform Invert
Enabling the waveform invert will change the result of math function and waveform measurement. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 71: Probe
Enable the touch screen operation and tap the channel status label at the bottom of the screen. Then the Vertical system interface is displayed. Then tap Probe to enter the Probe setting menu. Figure 5.4 Probe Setting Menu Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 72: Figure 5.5 Active Probe Setting Menu
By default, the probe ratio is 1X. The following table lists the preset probe ratio of the oscilloscope. You can also set a user-defined probe ratio according to your needs. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 73: Table 5.1 Probe Ratio
0.1:1 0.2X 0.2:1 0.3X 0.3:1 0.5X 0.5:1 1X (default) 10:1 20:1 30:1 50:1 100X 100:1 200X 200:1 300X 300:1 500X 500:1 1000X 1000:1 2000X 2000:1 3000X 3000:1 5000X 5000:1 Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 74: Table 5.2 Range Of The External Attenuation
After the oscilloscope recognizes the probe automatically, In the probe menu, you can view information about the currently connected probe, such as the vendor, model, serial number, and the last calibration time. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 75: Amplitude Unit
If the zero-cross voltage of the channel has a larger amplitude offset that exceeds the adjustable null range, please perform self-calibration for the instrument to ensure the SelfCal measurement accuracy. For details, refer to descriptions in Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 76: Channel Delay
You can can also click or tap the channel label input field to input a specific name for the channel label with the pop-up numeric keypad. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 77: Horizontal System
200 ps/div to 500 s/div. While you change the horizontal time base, the displayed waveforms of all channels are expanded or compressed horizontally relative to the selected time reference Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 78: To Adjust The Horizontal Position
While you change the horizontal position, the waveform trigger points and the displayed waveforms of all channels are moved left and right. The horizontal position at the top of the screen changes accordingly, as shown in the figure below. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 79: Zoom Mode (Delayed Sweep)
• Zoomed Position: Rotate the corresponding multifunction knob or use the icons at the right of the Position input field to increase or decrease the position for Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 80: Figure 6.2 Zoom Mode
Compared with the main time base, the zoomed time base has higher horizontal resolution. The zoomed time base should be smaller than or equal to the main time base. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 81: Acquisition System
In this mode, the oscilloscope averages the waveforms from multiple acquisitions to reduce the random noise of the input signal and increase the vertical resolution. A greater number of averages lowers the noise and increases the vertical resolution. On Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 82: Sampling Mode
The maximum real-time sample rate of this series is 4 GSa/s. The current sample rate is displayed in the acquisition label at the top of the screen. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 83: Sample Rate
Waveform Aliasing: when the sample rate is twice lower than the actual signal frequency (Nyquist Frequency), the frequency of the waveform rebuilt from the sample data is smaller than the actual signal frequency. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 84: Memory Depth
Delayed Sample Memory Depth Figure 7.2 Memory Depth MDepth ≥ SRate x TSCale x HDivs The following formula shows the relations among memory depth, sample rate, and horizontal time base: MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 85: Horizontal Expansion
In the Horizontal system menu, click or tap the drop-down button of Expand to select the horizontal reference baseline. The available choices include Center, Left, Right, Trigger, and User. The default is "Center". Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 86: Roll Mode
(available when the operating status of the oscilloscope Zoom Mode (Delayed Sweep) To Trigger the Oscilloscope Zoom Mode is STOP), (Delayed Sweep) Pass/Fail Test Waveform Recording and Playing Persistence Time Average XY Mode MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 87: Xy Mode
In the "Horizontal" menu, check the checkbox of XY to enable the XY mode. Configure the XY Mode Click or tap at the upper-right corner of the XY display window to enter the XY configuration menu. Figure 7.3 XY Menu Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 88: Figure 7.4 Measurement Schematic Diagram Of Phase Deviation
In this mode, you can use the Lissajous method to measure the phase deviation of the two input signals whose frequencies are the same. The following figure shows the measurement schematic diagram of phase deviation. Figure 7.4 Measurement Schematic Diagram of Phase Deviation MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 89 The XY mode can be used to measure the phase deviation occurred when the signal under test passes through a circuit network. Connect the oscilloscope to the circuit to monitor the input and output signals of the circuit. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 90: To Trigger The Oscilloscope
• Click or tap the trigger label (as shown in the figure below) at the top of the screen to enter the trigger menu. Figure 8.1 Trigger System Menu MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 91: Trigger Source
Level to set the value with the pop-up numeric keypad. When the trigger source is D0-D15, you can set the threshold level for digital Figure channels in the basic settings tab of the logic analyzer interface shown in Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 92: Trigger Mode
Trigger Mode The following is the schematic diagram of the acquisition memory. To easily understand the trigger event, we classify the acquisition memory into the pre-trigger buffer and post-trigger buffer. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 93: Figure 8.2 Schematic Diagram Of The Acquisition Memory
Normal: In this trigger mode, triggers and acquisitions only occur when the specified trigger conditions are found. This trigger mode should be used when the signal is with low repetition rate or only the event specified by the trigger Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 94: Trigger Coupling
Trigger holdoff can be used to stably trigger on complex repetitive waveforms that have multiple edges or other events between waveform repetitions (such as pulse series). Holdoff time indicates the time that the oscilloscope waits for re-arming the MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 95: Noise Rejection
This function is only valid when the trigger source is an analog channel, digital channel, or EXT. Trigger Type This series oscilloscope provides the following trigger types. 8.7.1 Edge Trigger Identifies a trigger on the trigger level of the specified edge on the input signal. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 96: Pulse Trigger
In this oscilloscope, positive pulse width is defined as the time difference between the two crossing points of the trigger level and positive pulse; negative pulse width is MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 98 Lower or Upper to set the lower limit value or the upper limit value with the pop-up numeric keypad. You can also use the specified multifunction knob to set the value. The pulse width available is from 1 ns to 10 s. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 99: Slope Trigger
A and B with the falling edge. See the figure below. Trigger Type Click or tap the drop-down button of Type to select "Slope". Then set the parameters for Slope trigger. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 100: Figure 8.7 Slope Trigger Setting Menu
Rising: triggers on the rising edge of the input signal. • Falling: triggers on the falling edge of the input signal. Trigger Condition Sets the trigger condition in the When item. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 101 Level A and Level B. The Level A and Level B will be adjusted synchronously. The upper limit and lower limit values change at the same time. The difference between Trigger upper and lower limit remains unchanged. For details, refer to descriptions in Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 103: Table 8.1 Video Standard
Interlaced Scan 1125 Sync In the Sync item, select the desired sync type. • All Lines: triggers on the first line found. • Line: triggers on the specified line. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 104: Pattern Trigger
• As RIGOL's digital oscilloscope provides the intensity graded color display function, the frequency in different parts of the signal can be indicated in different brightness levels. In this way, the experienced users can quickly judge the signal quality and discover abnormalities during the debugging process.
Page 105: Figure 8.10 Pattern Trigger Setting Menu Of Mho Series 4-Ch Model
Select the Source Click or tap the drop-down button of Source to select the analog channel or the digital channel as the trigger source. For available channels, refer to descriptions in Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 106: Duration Trigger
This pattern is a logical "AND" combination of the channels. Each channel can be set to 1 (high), 0 (low), or X (don't care). The MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 107: Figure 8.12 Duration Trigger
Pattern:HLHL Figure 8.12 Duration Trigger Trigger Type Click or tap the drop-down button of Type to select "Duration". Figure 8.13 Duration Trigger Setting Menu of MHO Series 4-CH Model Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 108: Figure 8.14 Duration Trigger Setting Menu Of Dho Series 8-Ch Model
"All" indicates all bits. Select a pattern for a channel, then click or tap All. The patterns of all the other channels will be set to the currently selected pattern. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 109: Timeout Trigger
(or rising edge) passes through the trigger level) is greater than the preset timeout value, as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 110: Figure 8.15 Timeout Trigger
Select the Source Click or tap the drop-down button of Source to select the analog channel or the digital channel as the trigger source. For available channels, refer to descriptions in MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 111: Runt Trigger
Upper Limit of the Trigger Level Lower Limit of the Trigger Level Negative Runt Pulse Figure 8.17 Runt Trigger Trigger Type Click or tap the drop-down button of Type to select "Runt". Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 112: Figure 8.18 Runt Trigger Setting Menu
: indicates that the instrument triggers on the positive runt pulse. • Negative : triggers on the negative runt pulse. Trigger Condition Set the Runt trigger condition in the When item. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 113: Window Trigger
Trigger Type Selects the "Window" trigger type, and then set the parameters for Window trigger. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 114: Figure 8.19 Window Trigger Setting Menu
• Falling: triggers on the falling edge of the input signal when the voltage level is lower than the preset low trigger level. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 115: Delay Trigger
(∆T) between the specified edges (Edge A and Edge B) of Source A and Source B meets the preset time limit, as shown in the figure below. See the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 116: Figure 8.20 Delay Trigger
The information will change based on the trigger settings. Source Setting • Source A MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 117 Delay trigger with the pop-up numeric keypad. You can also use the specified multifunction knob to set the upper and lower limit. The lower time limit must be smaller than the upper time limit. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 118: Setup/Hold Trigger
T2 is the hold time Data Source Edge Clock Source The data type is H Figure 8.22 Setup/Hold Trigger Trigger Type Click or tap the drop-down button of Type to select "Setup/Hold". MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 119: Figure 8.23 Setup/Hold Trigger Setting Menu
Only when you select the channel that has signal inputs as the trigger source, can you obtain a stable trigger. Trigger Condition Set the Setup/Hold trigger condition in the When item. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 120: Nth Edge Trigger
Time < M). Wherein, M is the time between the first rising edge and its previous rising edge; P is the maximum time between the rising edges that participate in counting. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 122: Rs232 Trigger
RS232 signal is detected. 1 bit 5~8 bits 1 bit 1~2 bits Start Bit Data Bit Check Bit Stop Bit Figure 8.26 Schematic Diagram of RS232 Protocol MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 123: Figure 8.27 Rs232 Trigger Setting Menu
Select the polarity of data transmission in the Polarity item. It can be set to "Positive" or "Negative" Trigger Condition Set the desired trigger condition in the When item. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 124: I2C Trigger
The I2C serial bus consists of SCL and SDA. Its transmission rate is determined by SCL, and its transmission data is determined by SDA, as shown in the figure below. The instrument triggers on the start condition, restart, stop, missing acknowledgment, MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 126 Its range is from 1 to 5. Click or tap the input field of Data, and then the "Format" interface is displayed. You can select "Bin" or "Hex" format to set the data format. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 127: Figure 8.30 Binary Format Setting
"Address" and "Data" conditions. Level Selection and Setting After the trigger condition setting is completed, you need to adjust the trigger level to correctly trigger the signal and obtain a stable waveform. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 128: Spi Trigger
The figure below shows the sequential chart of SPI bus. Figure 8.32 Sequential Chart of SPI Bus Trigger Type Click or tap the drop-down button of Type to select "SPI". MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 129: Figure 8.33 Spi Trigger Setting Menu
Rising: samples the MISO data on the rising edge of the clock. • Falling: samples the MISO data on the falling edge of the clock. Trigger Condition Select the desired trigger condition in When. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 130 CS. Trigger Level For details, refer to descriptions in . The current CLK trigger level A is displayed in the trigger information label at the top of the screen. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 132: Figure 8.36 Sample Position
The sample position is represented by the proportion of "the time from the start of the bit to the sample position" to the "bit time", as shown in the figure below. One Bit Figure 8.36 Sample Position MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 133 Check Error: triggers on the check error frame. • Format Error: triggers on the format error frame. • Random Error: triggers on the random error frame, such as the format error frame, answer error frame, etc. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 134: Flexray Trigger (Option)
Trigger Type Click or tap the drop-down button of Type to select "FlexRay" from the drop-down list. Then set the parameters for FlexRay trigger. Figure 8.38 FlexRay Trigger Setting Menu MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 135 When you select "ID", set the following parameters: ID Comp, ID Min, and ID Max. Click or tap the drop-down button of ID Comp to select the comparison conditions. The available choices include =, ≠, >, <, > <, and < Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 136: Lin Trigger (Option)
Figure 8.40 LIN Trigger Setting Menu After a trigger type is selected, the current trigger setting information (including the trigger type, source, and level) is displayed in the trigger information label at the top MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 137: Figure 8.41 Sample Position
The sample position is represented by the proportion of "the time from the start of the bit to the sample position" to the "bit time", as shown in the figure below. One Bit Figure 8.41 Sample Position Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 138: I2S Trigger (Option)
(WS, used for switch the audio channel data), and serial data line (SDA, used for transmit audio data represented in binary (2's complement)). The figure below shows the sequential chart of I2S bus. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 140 Data Max and Data Min, and then the "Format" interface is displayed. You can set the upper limit and lower limit of the data bit. For details, I2C Trigger refer to descriptions in MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 141 Trigger Level For details, refer to descriptions in . The current trigger level is displayed in the trigger information label at the top of the screen. • Level C Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 142: Mil-Std-1553 Trigger (Option)
Figure 8.44 Formats of the Command Word, Data Word, and Status Word of the 1553B Bus Trigger Type Click or tap the drop-down button of Type to select "1553B" from the drop-down list. Then set the parameters for MIL-STD-1553 trigger. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 143: Figure 8.45 Mil-Std-1553 Trigger Setting Menu
( Level Selection and Setting After the trigger condition setting is completed, you need to adjust the trigger level to correctly trigger the signal and obtain a stable waveform. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 144 Max and Min, and then the "Format" interface is displayed. You can set the upper limit and lower limit of the data word. For I2C Trigger details, refer to descriptions in MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 145: Zone Trigger
In the trigger zone interface, you can set "Center X" and "Center Y" to adjust the position of the trigger zone. Set "Width" and "Height" to adjust the area of the trigger zone. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 146 If you enable Zone A, select CH1 as the source for Zone A, select "Not intersect" as the condition, the following figure is displayed. If both trigger zone A and trigger zone B are enabled, the the logic "And" operation is the final trigger condition. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 147: Trigger Output Connector
If "PassFail" is selected for the AUX Out menu, the instrument can output a pulse from the [AUX OUT] connector when a pass/failed event is detected during the pass/ fail test. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 148: Math Operation
. Click or tap the specified math label again or click/tap at the upper-right corner of the math operation window to enter the math operation setting menu. • Press the front-panel key to enter the math operation menu. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 149: Figure 9.1 Math Operation Menu
By default, the math operation is disabled. When the specified math operation is enabled respectively, the corresponding math operation is displayed on the screen, as shown in the figure below. Figure 9.2 Math Operation Result Display Window Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 150: Arithmetic Operation
The source and the vertical scale parameters are displayed at the top of the window, as shown in the figure below. Label Source Vertical Scale Sample Rate Figure 9.3 Arithmetic Operation Result Display Window MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 151: Function Operation
Click or tap the ON/OFF tab forOperation to enable or disable the display of the operation result window. The parameters such as source and the vertical scale are displayed at the top of the window, as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 152: Figure 9.5 Function Operation Result Display Window
When the operator is "Diff", click or tap the input field of Smooth and use the pop-up numeric keypad to set the number of smooth times for the differential operation. You can also use the specified multifunction knob to set the value. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 153: Fft Operation
FFT resolution is the quotient of the sample rate and the number of FFT points. If the number of FFT points is a fixed value (65535 at most), then the higher the sample rate, the higher the resolution. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 154: Figure 9.7 Fft Operation Result Display Window
10 Hz). Stop frequency specifies the frequency at the right side of the window. Click or tap the input field of End Freq to set the stop frequency with the pop- MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 155: Table 9.1 Window Function
Hanning multiplication are rather different Measure the signal that has no Flat Top Measure the signals accurately accurate reference and requires an accurate measurement Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 156: Figure 9.8 Peak Search
• Threshold: click or tap the input field of Threshold to set the threshold of the peak with the pop-up numeric keypad. You can also use the multifunction menu MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 157: Logic Operation
A&&B, A||B, A-B, A^B, and !A. After selecting the desired logic operation from the drop-down button of Operator, you can configure its settings for the selected logic operation type. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 159: Figure 9.10 Logic Operation Result Display Window
For the channel sources supported by different models, refer to Content Conventions in this Manual Waveform Size You can select "Small", "Medium", or "Large" as the waveform display mode. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 160: Digital Filter
BandStop only allows the signals whose frequencies are lower than the current lower limit frequency or higher than the current upper limit frequency to pass. Figure 9.11 Digital Filter Menu MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 161: Figure 9.12 Digital Filter Operation Result Display Window
Click or tap the input field of ωc2 and use the pop-up numeric keypad to set the upper frequency limit. You can also Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 162: Parameter Settings Of The Math Operation Result
Offset or click/tap the icon at the right side of the input field of Offset to increase or decrease the vertical offset. You can also click MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 163 FFT does not support Center expansion. Label Sets whether to enable or disable the display of the math operation label of the Channel Label waveform. For setting methods, refer to descriptions in Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 164 Math Operation Grid When the Display Area is set to "Math", you can set the screen grid. For setting To Set the Screen Grid methods, refer to MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 165: Measurements
• -Width: indicates the time between the threshold middle value of a falling edge to the threshold middle value of the next rising edge. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 166: Count Values
Threshold Lower Limit Negative Pulse Count It is specified as the number of negative pulses that fall from above the threshold upper limit to below the threshold lower limit. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 167 It is specified as the number of falling edges that fall from above the threshold upper limit to below the threshold lower limit. Falling Edge Count = n Threshold Upper Limit Threshold Lower Limit Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 168: Delay And Phase Parameters
6. Phase(f-f): indicates the phase deviation between the threshold middle values of the falling edge of Source A and that of Source B. The phase formula is as follows: DelayA PhaseA × ° Period sourceA MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 169: Voltage Parameters
Source A and Source B can be any analog channels and Math1~Math4. • The default threshold middle value is 50%. 10.1.4 Voltage Parameters Overshoot Vmax Vupper Vtop Vmid Vamp Vbase Vlower Vmin Preshoot Figure 10.3 Voltage Parameters Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 170 14. Preshoot: indicates the ratio of the difference between the minimum value and the base value of the waveform to the amplitude value. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 171: Other Parameters
You can also refer to to enable all measurements. • Vertical: Vmax, Vmin, Vpp, Vtop, Vbase, Vamp, Vupper, Vmid, Vlower, Vavg, VRMS, Per. VRMS, Overshoot, Preshoot, Area, Per.Area, and AC.RMS. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 172: Measurement Settings
Click or tap the measurement results labels on the "Result" sidebar on the right side of the screen and then select Setting in the pop-up window. Figure 10.4 Measurement Settings Menu MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 173 When no measurement parameter is selected or there is no source input, the indicator is not available. The indicator changes when the waveform is expanded or compressed horizontally. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 174 Click or tap the drop-down button of the Region to select "Main" or "Zoom". • Main: indicates that the measurement range is within the main time base region. • Zoom: indicates that the measurement range is within the zoomed time base region. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 175: Statistical Measurement Results
"Histogram" and "Max-Min" are the internal measurement algorithm for the oscilloscope. 10.4 Statistical Measurement Results The measurement results of all current measurement items are displayed in the Result sidebar. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 176: To Remove The Measurement Results
• Click or tap the specified measurement item result list. Then the sub-menu is displayed. Click or Remove to remove the current measurement item. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 177: Auto Measurement
"Result" list. By default, it is intended for the fast edge signal. • Click or tap the fifth icon to cancel the auto setting and recovers to the parameter settings prior to pressing the Auto key. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 178: Cursor Measurements
Cursor B is a vertical dotted line ( is displayed at the bottom of the screen). In the XY cursor mode, X cursor is used to measure the waveform amplitude of Source X. • Y Cursor MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 179 1/∆X: indicates the reciprocal of the horizontal spacing between Cursor A and Cursor B. Click or tap the result bar and then select Remove or Setting in the pop-up window. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 180: Manual Mode
• X: It is a pair of vertical solid (Cursor A)/dotted (Cursor B) lines, used for measuring time parameters. The measurement results include AX, BX, ∆X, and 1/ ∆X. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 181 Measurement Example Measure the period of a sine wave by using the manual cursor measurement and auto measurement respectively. The measurement results are both 8 μs. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 182: Track Mode
In the Cursors menu, click or tap Track for the Mode item to enable the Track cursor measurement function. The measurement results are displayed in the "Result" bar at the right section of the screen. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 183: Figure 10.8 Track Mode Setting Menu
Click or tap the ON/OFF tab for AX BX to turn on/off adjusting the horizontal position of Cursor A and Cursor B (X cursors) simultaneously. The Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 184: Figure 10.9 Track Measurement (Before Horizontal Expansion)
. Then, expand the waveforms horizontally, and you will find that the cursor will track the point that has been marked, as shown in Figure 10.10 Figure 10.9 Track Measurement (before Horizontal Expansion) MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 185: Xy Mode
Click or tap to select the "X" tab under the Select menu item to set the X value for the specified cursor. Click or tap the input field of AX and use the pop-up numeric keypad to set the X value at Cursor A. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 186 Click or tap the ON/OFF tab for AY BY to turn on/off adjusting the Y value at Cursor A and the Y value at Cursor B simultaneously. You can also use the front-panel multifunction knob to adjust the cursor position. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 187: Digital Voltmeter (Dvm) And Frequency Counter
After the DVM measurement is enabled, the DVM result list is displayed at the right section of the screen. Click or tap the result list, the sub-menus are displayed. Click or tap Setting to enter the DVM setting menu. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 188: Figure 11.1 Dvm Setting Menu
Click or tap to select "In Limits" or "Out Limits" under When. In Limits: when the voltage value is inside the limited range, you can enable or disable the beeper to sound an alarm. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 189: To Remove The Measurement
After the counter is enabled, the "Counter" label displaying the counter measurement results appears in the "Result" bar at the right section of the screen, as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 190: Measurement Settings
Analog channels, digital channels, and EXT can all be selected as the source of the frequency counter. NOTE Content Conventions in this For the channel sources supported by different models, refer to Manual MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 191: To Reset Statistics
You can also click or tap the Counter result list first. Then the sub-menus are displayed. Click or tap Reset Stat. to reset the statistics of the counter measurement results. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 192: Digital Channels (Available Only For Mho Series)
In the Basic Settings tab, you can enable or disable the specified digital channel, set the channel label, and set the threshold for the channel. Figure 12.1 Basic Settings Tab of Logic Analyzer Interface MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 193: To Enable Or Disable The Digital Channel
Use Preset Labels This oscilloscope presets the common signal type names for the channel label, including ACK, ADO, ADDR, BIT, CAS, CLK, and DATA. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 194: To Select The Digital Channel
-15 V to 15 V. 12.2 Other Settings In the Other settings tab, you can set the waveform size of the digital channels, the channel sequence, probe delay, and probe calibration. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 196: To Set The Probe Delay
You can also use the Up/Down arrow to adjust the probe delay. Also, if no probe delay is required, you can directly click or tap 0 to reset it to zero. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 197: Histogram Analysis
Here takes the horizontal histogram as an example. When enabled, the histogram is displayed on the screen as shown in the figure below. The histogram result is displayed in the "Result" list at the right section of the screen. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 198: To Select The Histogram Type
All the analog channels can be selected to be the Histogram source. Content Conventions For the channel sources supported by different models, refer to in this Manual MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 199: To Set The Histogram Height
µ±σ: indicates the proportion of the number of frequencies or counts of the histogram hits that lie within one standard deviation of the mean to the total number of histogram hits. μ indicates the mean value in normal distribution. It is Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 200: To Remove The Measurement
13.8 To Clear Statistics Click or tap the histogram result list, then the sub-menus of the histogram function are displayed. Click or tap Clear to clear the statistics. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 201: Function/Arbitrary Waveform Generator
GII. You can also click or tap the enabled GI or GII label at the bottom of the screen to exit the specified AFG interface. Also, you can drag the label downward to disable the enabled AFG channel and exit the specified AFG interface. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 202: To Output Basic Waveforms
Sine signal with the pop-up numeric keypad. You can also use the specified knob indicated in the field to set it. Different waveforms have different frequency or period (reciprocal of the frequency) ranges. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 203 Use the oscilloscope to acquire the waveforms of the two channels and stably display the waveforms. After switching the channel status, the phase deviation between the Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 204: Square
Symmetry is defined as the percentage of the amount of time Ramp wave is rising in the period, as shown in the figure below. This parameter is only available when Ramp is selected. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 205: Pulse
2 mV to 2 V. Click or tap Offset to set the offset of the Noise waveform. The range of the offset is related to its amplitude value. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 206: Exp.rise
In the Basic Waveforms tab, click or tap the drop-down button of Type to select "Exp.Rise". Then set the Exp.Rise parameters. For setting methods, refer to Sine descriptions in " ". 14.1.8 Exp.Fall The Exp.Fall waveform is as shown in the figure below. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 207: Ecg1
In the Basic Waveforms tab, click or tap the drop-down button of Type to select "ECG1". Then set the ECG1 parameters. For setting methods, refer to descriptions in Sine 14.1.10 Gauss The Gauss waveform is as shown in the figure below: Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 208: Lorentz
In the Basic Waveforms tab, click or tap the drop-down button of Type to select "Lorentz". Then set the Lorentz parameters. For detailed setting methods, refer to Sine descriptions in MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 209: Haversine
In the Basic Waveforms tab, click or tap the drop-down button of Type to select "Sinc". Then set the Sinc parameters. For setting methods, refer to descriptions in Sine Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 210: Modulation
Figure 14.9 Modulation Setting Interface Please configure the modulation settings according to the following procedures. 1. In the Basic Waveforms tab, click or tap ON to enable the output for the specified channel. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 211: Figure 14.10 Am
Modulating Signal Carrier Signal Modulated Waveform Figure 14.10 AM Select the Modulation Type Click or tap the drop-down button of Mod. Type to select "AM". Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 212 14.2.2 FM (Frequency Modulation), namely the frequency of the carrier waveform changes with the voltage of the modulating waveform. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 213: Figure 14.11 Fm
You can also use the specified knob indicated in the field to set it. The settable FM frequency deviation range is from 2 mHz to the current frequency of the carrier waveform. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 214: Figure 14.12 Pm
Figure 14.12 PM Modulating Signal Carrier Signal Modulated Waveform Select the Modulation Type Click or tap the drop-down button of Mod. Type to select "PM". MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 215 Waveforms interface, click or tap ON for Output to enable the waveform output. Then the modulated waveforms will be output from the specified AFG terminal based on the settings. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 216: Bode Plot (Available Only For Mho5054/5104)
Bode Plots to enter the Bode Plots setting menu. Figure 15.1 Bode Plots Setting Menu Click or tap to minimize the Bode Plots menu for a simplified interface. Figure 15.2 Bode Plots Setting Menu-Simplified Mode MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 217: Basic Setting
Enabling the bode plot test automatically disables the bode plot setting menu. You can click or at the upper-right side to open the setting menu. 15.1.3 To Set the Input/Output Source • Input Source: Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 218: To Set The Sweep Signal
Bode plot represents the frequency and the Y-axis value represents the gain (red) and phase (green). The magnitude-frequency curve (red) represents the gain between system input and output. The phase-frequency curve (green) represents the phase deviation between system input and output. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 219: Figure 15.3 Bode Plot Waveform Display
Measurement Value. 5. Operation button: click or tap to open the Bode plot setting menu. Click or to close the Bode plot waveform display and disable the Bode function. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 220: To View The Connection Diagram
You can also use the multifunction knob to set the value. The setting range is from 10 Hz to 24.99 MHz. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 221: To Store And Load
3. Click or tap Load to load the file. The saved test data will be displayed on the screen in a wave/chart format (depending on the display type setting). Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 222: Power Analysis (Option)
The sources include CH1 to CH8. • Click or tap the drop-down button of Current to select the desired current source from the drop-down list. The sources include CH1 to CH8. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 223 When enabled, the statistical results of the power quality analysis will be displayed on the screen. Click or tap the close icon at the upper-right corner of the power analysis result interface to close the window. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 224: Figure 16.2 Power Quality Analysis Result Display
To close the connection diagram window, click or tap the close icon at the upper-right corner of the connection diagram window. Figure 16.3 Connection Diagram of Power Quality Analysis MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 225: Ripple
Please connect the cables according to the connection method as shown in the diagram. To close the connection diagram window, click or tap the close icon at the upper-right corner of the connection diagram window. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 226: Figure 16.5 Connection Diagram Of Ripple Analysis
Power Analysis (Option) Figure 16.5 Connection Diagram of Ripple Analysis MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 227: Reference Waveform
To Select the Reference Channel Click or tap the drop-down button of Current to select the reference waveform channel (Ref1-Ref10). By default, Ref1 is enabled. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 228: To Set The Ref Waveform Display
Vscale to increase or decrease the vertical scale. Also, you can use the specified multifunction knob indicated in the input field to set the value. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 229: Export And Import Operation
You can save the current reference waveform to the internal memory or external USB storage device. The file format of the reference waveform is "*.ref*. bin",*.csv". Click or tap Export to enter the reference waveform file saving interface. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 230 Then click or tap Load to complete the load operation. For details about the disk management operation, refer to the Disk Management section in Store and Load MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 231: Pass/Fail Test
During the test process, the oscilloscope will test the waveforms, display the test information, and output the test information based on the current of settings. The Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 232: To Select The Source
Up/Down arrow at the right side of the input field of Y Mask to adjust the value of Y Mask; use the Left/Right arrow at the right side of the input field MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 233: To Set The Output Form Of The Test Results
Click or tap to select "Pass" or "Fail" for the Output Event menu. Then when the specified output event is detected, a pulse will be output from the [AUX OUT] connector. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 234: To Start Or Stop The Pass/Fail Test Operation
The "Pass/Fail" measurement results are displayed at the right side of the screen under the "Result" list. The test Interface is as shown in the figure below. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 235: To Display The Statistics Information Of The Test Results
Click or tap the test results under the result list, then the sub-menus are displayed. You can perform the following operations: • Click or tap Reset Stat. to reset the test results to zero. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 236 Pass/Fail Test • Click or tap Setting to enter the pass/fail setting interface. • Click or tap Remove to disable the pass/fail function and exit the current interface. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 237: Protocol Decoding
(logic "1" or logic "0") according to the preset threshold level. Bit0 Bit1 Parallel[BIN] Figure 19.1 Schematic Diagram of Parallel Decoding Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 238: Clock Setting (Clk)
The range of the threshold is related to the current vertical scale and offset. CLK Edge You can select "Rising", "Falling", or "Both" in CLK Edge when configuring the clock channel. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 239: Bus Setting
Width, Bit X, and CH are set automatically, and you cannot modify them. Width, Bit X, and CH are set automatically, and you cannot modify them. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 240: Table 19.2 Bus Setting Of Mho Series 4-Ch Model
D15- 0 (Default) D0 (Default) automatically, and you cannot modify them. Bit0 to Bit7 are set to D0 to D0-D7 0 (Default) D7 (Default) D7 respectively. Width is set MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 241: Display-Related Setting
In Endian, select "Invert" or "Normal" as the endian of the bus. Polarity In Polarity, select "Positive" or "Negative" as the data polarity. 19.1.3 Display-related Setting In the Decode menu, set the following display-related parameters. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 242: Event Table
When you adjust the horizontal time base, the waveform displayed on the screen will also change, and the total number of lines containing the decoding information in the event table will also be changed. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 243: Rs232 Decoding
Start Bit: indicates when to output data. • Data Bit: indicates the number of data bits actually contained in each frame of data. • Check Bit: used to check whether the data are properly transmitted. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 244: Source Setting
When you modify the threshold of the Tx source channel, a dotted line displaying the current threshold level is displayed on the screen. It disappears in about 2 s after you stop modifying the threshold. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 245: To Set Data Package
Odd: indicates that the total number of "1" in the data bit and check bit is an odd number. For example, when 0x55 (01010101) is sent, "1" should be added to the check bit. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 246: Display-Related Setting
When enabled, the event table is displayed as shown in the figure below. You can also click or tap the icon at the upper-right corner of the table to close the event table. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 247: I2C Decoding
I2C serial bus consists of the clock line (SCL) and the data line (SDA). SCL: samples SDA on the rising or falling edge of the clock. SDA: indicates the data channel. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 248: Source Setting
When you modify the threshold of the clock channel, a dotted line displaying the current threshold level is displayed on the screen. It disappears in about 2 s after you stop modifying the threshold. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 249: Display-Related Setting
Address Indicator to indicate the current 10-bit address that is transferring. 10-bit Address Indicator Slave Address START 19.3.2 Display-related Setting In the Decode menu, set the following display-related parameters. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 250: Event Table
The displayed decoded data information in the bus is related to the value of the horizontal time base. Reducing the horizontal time base can help you view the detailed information. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 251: Spi Decoding
(logic "1" or logic "0") according to the preset threshold level. MOSI Slave Master MISO (MISO/MOSI) Figure 19.10 SPI Serial Bus Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 252: Source Setting
• Click or tap "Rising" or "Falling" under Slope to set the instrument to sample MISO and MOSI on the CLK. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 253: To Set The Mode And Data
Click or tap the drop-down button of CS to select the desired source. You can select analog channels or digital channels. NOTE Content Conventions in this For the supported channels of each model, refer to Manual Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 254: Display-Related Setting
Click or tap the drop-down button of Format to select the display format of the bus data and the event table. The available formats include "Hex", "Dec", "Bin", and "ASCII". MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 255: Event Table
In the Decode menu, click or tap the drop-down button of Format to select the display format of the event table. The available options include "Hex", "Dec", "Bin", and "ASCII". Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 256: Can Decoding (Option)
Quickly Apply Trigger Settings to Decoding Copy trig indicates applying the trigger settings to the specified decoding setting. Click or tap Copy Trig to apply the trigger settings to the specified decoding setting. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 257: Signal Configuration
The sample position is represented by the proportion of "the time from the start of the bit to the sample point" to the "bit time", as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 258: Display-Related Setting
When enabled, the bus label will be displayed at the upper-left side of the bus (when the bus display is enabled). The label shows the current bus type. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 259: Event Table
In the Decode menu, click or tap the drop-down button of Format to select the display format of the event table. The available options include "Hex", "Dec", "Bin", and "ASCII". Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 260: Lin Decoding (Option)
LIN signal protocol version. In the Decode menu, click or tap the drop-down button of Bus Type to select LIN, then configure the parameters for LIN decoding. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 261: Signal Configuration
Click or tap the drop-down button of Baud Rate to select the baud rate. The available baud rates include 2.4 kbps, 4.8 kbps, 9.6 kbps, 10.0 kbps, 19.2 kbps, and etc. You can also self-define the baud rate. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 262: Display-Related Setting
When enabled, the event table is displayed as shown in the figure below. You can also click or tap the icon at the upper-right corner of the table to close the event table. Figure 19.17 LIN Decoding Event Table MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 263: I2S Decoding (Option)
Alignment, WS Low, and other parameters. In the Decode menu, click or tap the drop-down button of Bus Type to select I2S, then configure the parameters for I2S decoding. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 264: Source Setting
Set the WS Source and Threshold • Click or tap the drop-down button of WS to select the analog channels or digital channels as the WS source. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 265: Bus Setting
Click or tap the drop-down button of WS Low to select "Left" or "Right". Set the Data Polarity In Data Polarity menu, click or tap to select "Positive" or "Negative". Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 266: Display-Related Setting
The displayed decoded data information in the bus is related to the value of the horizontal time base. Reducing the horizontal time base can help you view the detailed information. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 267: Flexray Decoding (Option)
Click or tap the ON/OFF tab for Bus Status to enable/disable the bus decoding. Quickly Apply Trigger Settings to Decoding Copy trig indicates applying the trigger settings to the specified decoding setting. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 268: Signal Configuration
The sample position is represented by the proportion of "the time from the start of the bit to the sample point" to the "bit time", as shown in the figure below. One Bit Figure 19.21 Sample Position MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 269: Display-Related Setting
FlexRay Bus Cyclic Redundancy Payload Head CRC Decoded Data Frame CRC Frame ID Check Figure 19.22 FlexRay Decoding Event Table Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 270 Data: Its display format is the same as that of the bus data (Hex, Dec, Bin, or ASCII), identified as "Data:". • TCRC (Tail Cyclic Redundancy Check): expressed in Hex, identified as "TCRC:". When error occurs, it is displayed as a red patch. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 271: 1553B Decoding (Option)
When the analog channel is set as the data channel source, you can configure the Threshold with the pop-up numeric keypad. You can also use the corresponding multifunction knob to set the threshold. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 272: Event Table
In the Decode menu, click or tap the drop-down button of Format to select the display format of the event table. The available options include "Hex", "Dec", "Bin", and "ASCII". MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 273 • Data word data: data of the data word. Its display format is the same as that of the bus data (Hex, Dec, Bin, or ASCII), identified as "Data:". Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 274: Multi-Pane Windowing
2. You can set parameters such as Source according to your needs. For details, refer to descriptions of relevant chapters. 3. Click or tap Add and then the selected diagram is displayed on the screen. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 275 Clip or tap Measure, Measure All, or Decode in the Result List menu to preview the corresponding measurement result list and parameter settings above the menu. Click or tap Add, the corresponding measurement results will be displayed on the screen. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 276: Waveform Recording And Playing
• Click or tap the Record icon to start recording the waveforms. Then the record icon turns from MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 277: Record Options
You can also rotate the specified multifunction knob indicated in the field to set the value. The available range is from 10 ns to 1 s. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 278: Play Options
ON/OFF tab for the Minimize menu to select whether to minimize the Play operation window. If you select ON, the play operation window is minimized, making the interface simple, distinctive, and easy to use, as shown in the figure below. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 279: Figure 21.2 Play Operation Interface
You can also rotate the specified multifunction knob indicated in the field to set the value. The available range is from 1 ms to 1 s. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 280 You can also rotate the specified multifunction knob indicated in the field to set the value. The max. value for the current frame is the max. number of frames that have been recorded. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 281: Search And Navigation Function
Figure 22.1 Search Menu 1. Enable or disable the search function Click or tap the ON/OFF tab for the Search menu to enable or disable the search function. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 282 Click or tap the ON/OFF tab for MarkTable to enable or disable the marker table. When enabled, the marker table is shown in the following figure. The marker table lists the marker events of the displayed waveforms in the current waveform view. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 283: Figure 22.2 Marker Table
NOTE This series oscilloscope only supports the flash memory USB storage device of FAT32 format. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 284: Navigation Function
The navigation function is only available when the operating status is STOP. Time Navigation After stopping data acquisition, use the navigation control buttons in the Navigation interface to play forward and backward the captured waveforms. You can also use the MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 285: Figure 22.5 Search Event Navigation Interface
Figure 22.5 Search Event Navigation Interface After selecting the "Search Event" navigation, click or tap Search to set the search conditions. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 286 (the serial number in the mark table increases); click or tap to go to the first event; click or tap to go the last event. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 287: Display Control
In the Display setting menu, click or tap the drop-down button of Persistence Time to select the persistence time. The available values are Min, specific values (100 ms, 200 ms, 500 ms, 1 s, 2 s, 5 s, 10 s), and Infinite. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 288: Waveform Intensity
In the Display setting menu, drag the slider of Grid Brightness to set the grid brightness. The default is 50%, and the range available is from 0% to 100%. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 289: Show Scale
STOP/RUN icon on the quick operation toolbar or press on the front panel. If disabled, the last triggered waveform is displayed. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 290: To Store And Load
In the Storage interface, click or tap the Save tab to enter the Save interface. Click or tap the drop-down button of Choose to select Save Image. The screen image will be saved to the internal or external memory based on the settings. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 291: Figure 24.1 Image Saving Setting Menu
Set the File Saving Parameters • Set the filename Click or tap the input field of File Name to input the file name to be saved with the pop-up virtual keypad. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 292: To Save Wave
"Save Wave" setting menu. The main setting information (e.g. "On/Off" state of the channel, vertical scale, and horizontal time base) and waveform data of all enabled channel will be save to the internal or external memory. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 293: Figure 24.2 Waveform Saving Setting Menu
Set the file path Click or tap the input field of File Path, then the disk management interface is displayed. In the disk management interface, select the destination storage path, Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 294: Save Setup
"Save Setup" “setting menu. Save the settings of the oscilloscope to the internal or external memory in "*.stp" format. When loading, the stored settings can be recalled. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 295: Figure 24.3 Setup Saving Setting Menu
Click or tap Save to save the setup file based on the current settings and the storage menu is closed. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 296: Binary Data Format (.Bin)
1. File Header There is only one file header in a binary file. The file header contains the following information. Table 24.2 File Header Two-byte characters, RG, indicating that the file is the RIGOL Cookie binary data file format. Version Two-byte, indicating the file version.
Page 297: Table 24.3 Waveform Header
The value is treated as a double precision 64-bit float point number. If the value is zero, then no data has been acquired. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 298: Table 24.4 Waveform Data Header
The header is stored before the data set. Table 24.4 Waveform Data Header A 4-byte integer, indicating the number of bytes in the Header Size waveform data header. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 299: To Load A File
Click or tap the drop-down button of Choose to select "Load Setup". Then, click or tap File Path to load the setups from the internal memory or the external USB disk. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 300: Firmware Upgrade
2. Click or tap the function navigation icon at the lower-left corner of the screen to enter the function navigation. 3. Then click or tap the Upgrade icon to perform the upgrade operation. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 301: Disk Management
Click or tap New Folder, then a folder name input keyboard is displayed. Parameter Setting Method For the name input method, refer to descriptions in . Click or tap any place on the Storage interface to exit the keyboard interface. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 302 Select a specified file or folder, then click or tap Rename to input a new filename or folder name with the pop-up virtual keypad. Then, the rename operation is completed. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 303: System Utility Function Setting
The MAC address of each oscilloscope is unique. When assigning the IP address for the oscilloscope, the system uses the MAC address to identify the instrument. VISA Address Displays the VISA address currently used by the the instrument. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 304 You can set this parameter in Static IP mode. The format of the gateway is nnn.nnn.nnn.nnn. The range of the first segment (nnn) is from 0 to 223 (except 127), and the range for the other three segments is from 0 to 255. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 305: Basic Settings
In the Utility menu, click or tap Setup to enter the basic setting menu. Language This product supports menus in multiple languages. The help information, prompt messages, and interface can be displayed in multiple languages. Click or tap the Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 306 When the AUX Out menu is set to "TrigOut", then in the pass/fail test menu (click or tap > Pass/Fail to enter the pass/fail test menu), the Aux Output menu item is automatically disabled. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 307: Ch1
You can also click or tap any place other than the date setting interface to exit the date modification menu. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 308: About This Oscilloscope
Indicates the version number of browser remote control module. 25.4 Other Settings EXT 10M IN Indicates the rear-panel [10MHz REF IN] reference clock input interface. When ON, the interface is enabled; when OFF, the interface is disabled. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 309: Auto Config
Make sure that the oscilloscope has been warmed up or operating for more than 30 minutes before the self-calibration. In "Utility" menu, click or tap SelfCal, the self-calibration menu is as shown below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 310: Option List
Click or tap the ON/OFF tab for Invert to enable or disable the invert function. • Click or tap "Color" or "Gray" for Color to select the desired storage color. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 311 Under Stat Reset, click or tap "Measure" or "Pass/Fail" to reset the statistics of the specified function. After configuring the settings, press on the front panel to reset the result list of the specified function. Then the instrument restarts to make statistics. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 312: Self-Check
You can test the following self-check items for the device. Key Test Click or tap Key Test to enter the key test interface (virtual front panel key), as shown in the figure below. Figure 25.2 Key Test Interface MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 313: Figure 25.3 Touch Screen Test Interface
There are 15 colors of test screens. Click on the screen to go to the next screen test interface. Click or tap Exit at the upper-left corner of the touch screen test interface to Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 314 Board Test Click or tap Board Test, then the board test interface is displayed. Check whether the status of each module is in good condition. MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 315: Remote Control
SCPI (Standard Commands for Programmable Instruments) commands. This chapter will illustrate how to use the RIGOL Ultra Sigma software to remotely control the instrument via various interfaces. Note: When communicating with the PC via GPIB, the instrument does not support large data transmission operation such as screen shot and waveform reading.
Page 316: Remote Control Via Usb
PC via the USB interface. You can also click USB-TMC to search for the resource. 3. View the device resource The resources found will appear under the "RIGOL Online Resource" directory, and the model number and USB interface information of the instrument will also be displayed.
Page 317: Remote Control Via Gpib
4. View the device resource The resources found will appear under the "RIGOL Online Resource" directory. 5. Control the instrument remotely Right-click the device resource name and select "SCPI Panel Control" to open the remotely command control panel.
Page 318: Figure 26.1 Search For The Available Device
5. View the device resource Click OK to go back to the main interface of Ultra Sigma. The searched instrument resource will be displayed under the directory of "RIGOL Online Resource". 6. Control the instrument remotely Right-click the device resource name. In the displayed menu, select "SCPI Panel Control"...
Page 319: Troubleshooting
After restarting the instrument, insert the USB storage device again to check whether it can work normally. d. If the USB storage device still cannot work normally, please contact RIGOL. 4. The touch-enabled operation does not work. a. Check whether you have locked the touch screen. If yes, unlock the touch screen.
Page 321: Appendix
DHO5058/DHO5108: Passive HighZ Probe (500 MHz) x8 Recommended Accessory 4 sets of 4-Channel Logic Analyzer Probe for MHO PLA3204 Series Bandwidth Upgrade Option DHO5004-BWU05T10 (4-channel 500 MHz-1 GHz Upgrade Option model) Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 322: Appendix B: Warranty
Function and Application Bundle Option, including AUTOA/AEROA/FLEXA/AUDIOA/PWRA. MHO5000-BND Note: For all the mainframes, accessories, and options, please contact the local office of RIGOL. 28.2 Appendix B: Warranty RIGOL TECHNOLOGIES CO., LTD. (hereinafter referred to as RIGOL) warrants that the product mainframe and product accessories will be free from defects in materials and workmanship within the warranty period.
Page 323: Appendix C: Factory Settings
Appendix To get repair service, please contact your nearest RIGOL sales or service office. There is no other warranty, expressed or implied, except such as is expressly set forth herein or other applicable warranty card. There is no implied warranty of merchantability or fitness for a particular purpose.
Page 324 Grid FULL Grid Brightness Window Transparency Cursor Brightness Show Scale Color Grade Waveform Freeze Dual-channel Function/Arbitrary Waveform Generator (AFG) Channel Output GI Waveform Type Sine Freq 1 GHz Amplitude MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 325 Display Type Waveform Start Freq 10 Hz Stop Freq 1 MHz Points/Decade Output Amplitude 200 mV Var. Amplitude Measure Threshold Histogram Indicator Statistics Count 1,000 Display Type Source Upper Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 326 -6 μs 6 μs Select AX BX -150mV 150mV Frequency Counter Source Statistics Measure Frequency Resolution Source Mode AC RMS Beeper When In Limits Upper Lower Save Image Format *.png MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 327 Operation Save Image Format *.png Invert Color Color Pass/Fail Test Enable Source Y Mask 480 mdiv X Mask 240 mdiv Format of the Mask File to *.pf be Loaded Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 328 Waveform Recording Enable Record Interval 10 ns Frames 1,000 Beeper Play Minimize Play Mode Play Sequence Interval 100 ms Math Operation Invert Vertical Expansion Display Label Grid FULL Operation MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 329 Vertical Scale 20 dB Offset 0 dBV Window Function Hanning Color Grade Peak Search Peak Number Threshold 5.5 dBV Excursion 1.8 dB Table Order Amp Order A&&B Operation SourceA Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 330: Table 28.2 Factory Settings
300 mdiv Thre.CH1 Thre.CH2 Thre.CH3 Thre.CH4 Thre.CH5 Thre.CH6 Thre.CH7 Thre.CH8 Operation SourceA SourceB Wave Size Medium Offset 0 div Sensitivity 300 mdiv Thre.CH1 Thre.CH2 Thre.CH3 Thre.CH4 Thre.CH5 Thre.CH6 Thre.CH7 MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 331 Bias Diff Operation Source Scale 500 mV/s Offset 0 V/s Smooth Sqrt Operation Source Scale 500 mU Offset Operation Source Scale 500 mU Offset Operation Source Scale 500 mU Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 332 500 mV Offset ωc1 4 kHz ωc2 8 kHz Band Stop Operation Source Scale 500 mV Offset ωc1 4 kHz ωc2 8 kHz AX+B Operation Source Scale 500 mV MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 333: Bit
Invert Polarity Positive RS232 Threshold Polarity Negative Baud 9.6 kbps Data Bits 8 bits Endian Parity None Stop Bit 1 bit SCL Thre Data SDA Thre Exchange SCL/SDA Without Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...
Page 334 CAN-FD Baud 1 Mbps FD Sample Position FlexRay Source Threshold Channel Selection Baud 10 Mbps Signal Type Sample Position SCLK SCLK Threshold SCLK Edge Rising WS Threshold Data Threshold MHO/DHO5000 User Guide Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
Page 335 [1]: The AFG function is the optional configuration for MHO5054 and MHO5104 models. [2]: Digital channels are only supported by MHO5054, MHO5104, MHO5056, and MHO5106. [3]: The Bode plot function is the standard configuration only for MHO5054 and MHO5104 models. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved. MHO/DHO5000 User Guide...

This manual is also suitable for:

Dho5000 series Dho5054 Dho5104 Mho5054 Mho5104 Mho5056 ... Show all

Rigol MHO5000 Series User Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Rigol MHO5000 Series

Summary of Contents for Rigol MHO5000 Series
