NOTE: when the left print head adjustment knob setting was previously
set to 5 (the highest pressure index) the wrinkle can't be avoided, rotate
both knobs back to setting 1, then rotate the Z-axis mechanism
adjustment Screw clockwise for a few degrees. Print the label again to
check if wrinkle is gone. If not, continue with Z-axis alignment.
Z-axis Alignment:
• Turn the Z-axis mechanism adjustment screw clockwise until you feel
contact with the mechanism. Print the label again to check if wrinkle is
gone.
• If the wrinkle is still there, turn the Z-axis mechanism adjustment
screw clockwise about 1/4 turn. Print the label again to check if
wrinkle is gone. If not, keep repeating this step until the wrinkle is
corrected. If the wrinkle direction changes from "/" to "\" by adjusting
the Z-axis mechanism adjustment screw, turn the Z axis mechanism
adjustment screw counter clockwise to avoid the wrinkle.
3.
If the wrinkle on the printed label starts from the lower right side to upper
left side, following this adjustment procedure:
• Decrease the Left print head pressure adjustment knob setting 1
increment. Print the label again to check if wrinkle is gone. If not,
repeat this process until the ribbon wrinkle is eliminated.
• If the left side print head adjustment knob has been set to index 1 (the
lowest index), increase the right print head pressure knob by one
increment. Print the label again to check if wrinkle is gone.
