This item is used to set the print mode. There are 5 modes as
listed below:
Print mode
Batch Mode
Peeler Mode
Cutter Mode
Cutter Batch
This item is used to fine tune media stop location. Available
Offset
setting value is from "+" to "-" or "0" to "9".
Shift X
This item is used to fine tune print position. Available setting
value is from "+" to "-" or "0" to "9".
Shift Y
Reference
This item is used to set the origin of printer coordinate system,
X
horizontally and vertically. Available setting value is from "0" to
Reference
"9".
Y
Use this item to set the code page of international character
Code page
set.
Country
Use this option to set the country code.
Note:
If printing from enclosed software/driver, it will take precedence and overwrite
the settings entered from the panel.
Printer Description
Mode
None Next label top of form is aligned to the print head
burn line location. (Tear Off Mode)
Once image is printed completely, label gap/black
mark will be fed to the tear plate location for tear
away.
Enable the label peel off mode.
Enable the label cutter mode.
Cut the label once at the end of the print job.
- 34 -
Batch
Mode
+000
+000
+000
000
000
850
001
