- Page 1 Installation Guides Date: Sept 2019 Page: 1 of 4 Section: SCREENS AND GABLES HABN_225a Rev. Navigate Single-Sided End Cover – Metal (HNBCCEMS), Navigate Single-Sided Mid Cover – Metal (HNBCCMMS)
- Page 2 height-adjustable bench Installation Guides Date: Sept 2019 Page: 2 of 4 Section: SCREENS AND GABLES HABN_225a Part & Product Identification ITEM ITEM PREVIEW DESCRIPTION PART NUMBER QTY. PREVIEW DESCRIPTION PART NUMBER QTY. 1. NAVIGATE END COVER, SINGLE SIDED, HAB (HNBCCEMS30L) 3.
- Page 3 height-adjustable bench Installation Guides Date: Sept 2019 Page: 3 of 4 Section: SCREENS AND GABLES HABN_225a PLACE GABLE COVER (RIGHT) PLACE GABLE COVER (LEFT) STEP 1a: Place the End Gable Cover - Right as shown above. STEP 1b: Place the End Gable Cover - Left as shown above.
- Page 4 height-adjustable bench Installation Guides Date: Sept 2019 Page: 4 of 4 Section: SCREENS AND GABLES HABN_225a PLACE THE MID GABLE COVER STEP 3: Place Mid-Gable Cover as shown above.
