PCIe CPU Card Inter® Pentium® M/ Celeron® M FSB400/533 MHz
with VGA/ LVDS, Dual GbE, USB2.0, SATA and Audio
PICOe-6612
Quick Installation Guide
Version 1.0
Oct. 13, 2006
Package List
PICOe-6612 package includes the following items:
1 x PICOe-6612 single board computer
1 x mini jumper pack
1 x ATA66/100 flat cable
2 x SATA cable
1 x SATA Power cable
1 x Dual RS232 cable
1 x KB/MS Y cable
1 x Utility CD
1 x QIG (quick installation guide)
©2006 Copyright by IEI Technology corp.
All rights reserved.
1
Advertisement
Related Manuals for IEI Technology PICOe-6612
Summary of Contents for IEI Technology PICOe-6612
- Page 1 PICOe-6612 Quick Installation Guide Version 1.0 Oct. 13, 2006 Package List PICOe-6612 package includes the following items: 1 x PICOe-6612 single board computer 1 x mini jumper pack 1 x ATA66/100 flat cable 2 x SATA cable 1 x SATA Power cable...
-
Page 2: Specifications
Specifications Socket 479 Inter® Pentium® M/Celeron M support 400/533MHz FSB up to 2.26GHz System Chipset: SIS 661CX + SIS 966 BIOS: AMI BIOS System memory 1x 184-pin DDR 400/333MHz up to 1GB Ethernet: Realtek RTL8110C for GbE I/O Interface 2 x RS232 5 x USB 2.0 1 x IDE 1 x FDD... -
Page 3: Ordering Information
Humidity: Operation:5%~95% non-condensing Dimension: 165mm x 115mm Weight: GW: 1.0Kg Ordering Information PICOe-6612-R10 PCIe CPU Card Inter® Pentium® M/ Celeron® M FSB533 MHz with CRT/ LCD, Dual LAN, USB2.0, and SATA PLCOe-6612LVDS-R10 PCIe CPU Card Inter® Pentium® M/ Celeron® M FSB533 MHz with CRT/ LCD, Dual LAN, USB2.0, SATA, and LVDS... - Page 4 LPT1 : Parallel Port Connector DESCRIPTION DESCRIPTION STROBE# AUTO FORM FEED # DATA0 ERROR# DATA1 INITIALIZE# DATA2 PRINTER SELECT LN# DATA3 DATA4 DATA5 DATA6 DATA7 ACKNOWLEDGE# BUSY PAPER EMPTY PRINTER SELECT PIDE1 : IDE Interface Connector DESCRIPTION DESCRIPTION RESET# GROUND DATA 7 DATA 8 DATA 6...
- Page 5 FDD1: FDC Connector DESCRIPTION DESCRIPTION GROUND REDUCE WRITE GROUND GROUND GROUND INDEX# GROUND MOTOR ENABLE A# GROUND DRIVE SELECT B# GROUND DRIVE SELECT A# GROUND MOTOR ENABLE B# GROUND DIRECTION# GROUND STEP# GROUND WRITE DATA# GROUND WRITE GATE# GROUND TRACK 0# GROUND WRITE PROTECT# GROUND...
-
Page 6: Pin Description
USB1、USB2: Internal USB Connector USB1、USB2 DESCRIPTION DESCRIPTION GROUND DATA- DATA+ DATA+ DATA- GROUND CPU_FAN1 : CPU Fan Connector DESCRIPTION Rotation Signal +12V Sense Control DIO1 : Digital Input / Output Connector DESCRIPTION DESCRIPTION Ground Output 3 Output 2 Output 1 Output 0 Input 3 Input 2... - Page 7 IR1: IrDA connector PIN DESCRIPTION LVDS1 : LVDS 2 Channel Connector IR-RX Pin number : Pin number : Pin name Pin name IR-TX Pin-2 : Pin-1 : CIR-RX Pin-4 : Pin-3 : LVDSA_Y0- LVDSA_Y0+ ATXCTL1 : Backplane to Pin-6 : Pin-5 : Mainboard Connector LVDSA_Y1-...
- Page 8 Board Layout: Jumper and Connector Locations...
