PCIE-9450
Intel Processor
PICMG1.3 Full-Size CPU Card with PCIE-GbE, SATA II RAID, and
Quick Installation Guide
Version 1.0
Mar. 30, 2006
©2006 Copyright by IEI Technology corp.
All rights reserved.
®
LGA775 Pentium
D
USB2.0
Package Contents
PCIE-9450 package includes the following items:
1 x PCIE-9450 single board computer
1 x RS-232 cable for 2 ports P/N: 19800-000051-RS
1 x ATA 66/100 flat cable P/N: 32200-000052-RS
4 x SATA cable P/N: 32000-062800-RS
2 x SATA power cable P/N: 32100-088600-RS
1 x USB cable for 2 ports P/N: CB-USB02-RS
1 x Keyboard/ PS2 mouse Y cable P/N: 32000-000138-RS
1 x mini jumper pack P/N: 33100-000033-RS
1 x Utility CD
1 x QIG (quick installation guide)
Ordering Information
Standard
PCIE-9450
PICMG 1.3 LGA775 Intel Pentium D CPU Card with VGA,Dual PCI-Express
GbE,SATA,USB2.0 and Audio
Optional:
1. Audio cable P/N: AC-KIT08R-R10
2. CPU Cooler P/N: CF-520-RS
3. FDD cable P/N: 32200-000017-RS
4. LPT cable P/N: 19800-000049-RS
If any of these items is missing or damaged, contact the dealer from whom you
purchased this product. Save the shipping materials and carton in case you want
to ship or store the product in the future.
