PICMG 1.3 Full Size CPU Card with AMD Socket S1g1 Processor, AMD 690G & ATI SB600
Chipsets, Multi-display Interfaces, 4 x SATA II with RAID Functions, PCIe Mini Card
Slot, Dual PCIe GbE
Quick Installation Guide
Package Contents
PCIE-690S1 package includes the following items:
1 x PCIE-690S1 single board computer
1 x Dual RS-232 cable
1 x ATA 66/100 flat cable
1 x D-Sub VGA cable with bracket
4 x SATA cable
2 x SATA power cable
1 x USB cable for 2 ports
1 x Keyboard/ PS2 mouse Y cable
1 x mini jumper pack
1 x Utility CD
1 x QIG (quick installation guide)
PCIE-690S1
Version 1.0
JUL.18, 2007
©2006 Copyright by IEI Technology corp.
All rights reserved.
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for IEI Technology PCIE-690S1
Summary of Contents for IEI Technology PCIE-690S1
- Page 1 PCIE-690S1 Quick Installation Guide Version 1.0 JUL.18, 2007 Package Contents PCIE-690S1 package includes the following items: 1 x PCIE-690S1 single board computer 1 x Dual RS-232 cable 1 x ATA 66/100 flat cable 1 x D-Sub VGA cable with bracket...
-
Page 2: Specifications
Specifications CPU: AMD Turion™ 64 X2 and Mobile Sempron™ Socket S1 Processor and Hyper Transport Technology BIOS: AMI 4MB Flash Memory System Chipset: AMD 690G + ATI SB600 Chipsets BIOS : AMI BIOS Label System memory: 2 x 240-pin Dual channel DDR2 400/533/667MHz up to Ethernet: Dual Broadcom BCM5787M PCIe GbE Chipsets I/O Interface: 10 x USB2.0 (6 on CPU card by pin header, 4 on backplane by pin... -
Page 3: Ordering Information
Humidity: Operation: 5% ~ 95% non-condensing Dimension: 338mm x 126mm Weight: GW:1.Kg Ordering Information PCIE-690S1-R10 PICMG1.3 Full Size CPU Card with AMD Socket S1 Processors, AMD 690G & SB600 chipset ,TV-out, DVI-I,VGA AC-KIT883HD-R10: 7.1 Channel HD Audio Kit with Realtek ALC883 supports dual... - Page 4 IDE1 : IDE1 Connector(2 x 20 pin; 2.54mm pitch) Description Description RESET# DATA 7 DATA 8 DATA 6 DATA 9 DATA 5 DATA 10 DATA 4 DATA 11 DATA 3 DATA 12 DATA 2 DATA 13 DATA 1 DATA 14 DATA 0 DATA 15 (KEY)
- Page 5 FDD1 : Floppy Connector(2 x 17 pin; 2.54mm pitch) Description Description EWC0 KB1: Keyboard Connector Pin No. Description INDEX- L_KCLK MO-A L_KDAT DS-B DS-A GROUND MO-B DIR- STEP- USB1,2,3: 2 port s US onnec WGATE- Pin No. De scripti in N escriptio TRK0- ATA#...
- Page 6 AUDIO1: Connector for HD Audio Module (2x5 pin;2.0mm pitch) Pin No Description Pin No Description HD_SYNC HD_CLK HD_SDOUT PC_BEEP HD_SDIN HD_RST# PWR (+5V) PWR (+12V) (N/C) TPM1: TMP Connector (2x10 pin;2.54mm pitch) Pin No Description Pin No Description TPM_CLOCK LPC_FRAME# RESET LAD3 LAD2...
- Page 7 TV1: TV OUT Connector (2 x 3 pin; 2.54mm pitch) Pin No Description Pin No Description COMPONENT: LUMINACE (Y) GROUND S-VIDEO: LUMINACE COMPONENT:CHROMINANCE(Pr) GROUND S-VIDEO : CHROMINANCE COMPONENT: CHROMINANCE (Pb) GROUND AV: COMPOSITE VEDIO OUT VGA1: VGA Connector (2x5 pin;2.54mm pitch) Pin No Description Pin No Description DDC_DATA...
- Page 8 Board Layout: Jumper and Connector Locations...
