C. Insert a guide rod through each hole of the template.
fi ts through the weight stack hole, such as a weight stack selector pin.
D. Carefully align and rub decal onto weight plates.
E. Carefully remove front side, leaving numbers adhering to weight plates.
Front
Back
Figure 11

Final Assembly

1. Visual Inspection (see step 1A).
A. Visually inspect the entire FT-360S. Be sure cables are properly installed, hardware is secure and
the weight stack is properly assembled.
B. Verify Caution Decal, part number 9100-348-4 is present and not damaged. See Figure 1 to
identify what the decal looks like and see Figure 2 for location.
Figure 1
Cybex FT-360S Functional Trainer Owner's Manual
NOTE: A guide rod can be anything that
Assembly
Page 6-13
