Eagle® and its mark are registered trademarks of Cybex International, Inc DISCLAIMER: Cybex International, Inc., makes no representations or warranties regarding the contents of this manual. We reserve the right to revise this document at any time or to make changes to the product described within it without notice or obligation to notify any person of such revisions or changes.
• equipment must be anchored to a solid, level surface, utilizing all anchoring holes provided. Fasteners must have a minimum of 500 lbs. tensile capacity. Cybex • recommends .3/8” grade 2 bolts or better. A minimum pull force of 220 lbs/100 kgs is required for each anchor position.
Use only Cybex components to maintain and repair the equipment. Display the Facility Safety Sign so it is visible and prominent.
Page 5
Cybex Owner’s Manual DO NOT lean or pull on machine • DO NOT use machine for support during stretching. • DO NOT attach resistance straps, ropes or other means to equipment, except those provided by • the manufacturer for intended use on the equipment.
Cybex Owner’s Manual Warnings and Cautions Warning decals indicate a potentially hazardous situation that could result in death or serious injury if the precautions are not observed. Caution decals indicate a potentially hazardous situation, which, if not avoided, could result in minor or moderate injury.
Cybex Owner’s Manual Assembly Machine Specifications Total Weight and Size: Eagle 11100 Back Extension Weight Machine Dimensions at Rest Machine Dimensions at Use 658 lbs 47” W x 54” L x 58” H 47” W x 55” L x 58” H 298.46 kg...
Page 9
Cybex Owner’s Manual Part Number Description Diagram Decal, Weight Plate 12000-560 (30-290) NOTES: 1. RIGHT HAND SIDE - 40 POINT HELVETICA BOLD. HORIZONTAL SCALE 80%. MATERIAL: EXCEPT AS NOTED TRACKING -50. DIMENSIONS REMOVE ALL BURRS OWATONNA IN INCHES BREAK SHARP EDGES 2.
Page 10
Cybex Owner’s Manual 4. Attach each half together using the six BHSCS that were removed. BHSCS (4) Locknut (4) BHSCS (3) Locknut (3) Install rubber feet 1. Remove each (standard) cone-shaped shipping support using a 3/4” socket or wrench. 2. Place rubber feet (supplied with machine) on each foot of the frame.
Page 11
Cybex Owner’s Manual 7. Remove the top two screws securing the back shroud. Screw 8. Slide rear shroud assembly upward and remove. Install the weight stack 1. Note how the increment weights are installed. 2. With an assistant holding the increment weights, move the adjusting knob to 0 lbs and remove all six increment weights (three each side.)
Page 12
Cybex Owner’s Manual 8. Install each weight plate one at a time. When installing weight plates, position plates so wide edges of bushing face upward and narrow edges of bushing face downward. NARROW WIDE bushing bushing edge edge faces upward...
Page 13
Cybex Owner’s Manual 4. Verify belt and insert are installed properly. Correct belt routing Wrong belt routing Insert Insert Belt Belt Stem Stem 5. Pull belt tight and secure belt to clamp with the two set screws. Torque set screws 300-350 in-lbs.
Page 14
Cybex Owner’s Manual Install back shrouds 1. Place shroud back into position on the two bottom screws. Screw 2. Install the top two screws securing the back shroud. Screws 3. Install the three Phillips head screws securing the top (back) shroud.
Page 15
It is important that you perform regular inspection and maintenance activities on your equipment. See the CYBEX Eagle Owner’s Manual for inspection and maintenance activities. If you do not have a CYBEX Eagle Owner’s Manual or if you have any questions or concerns, call CYBEX Customer Relations at 888-462-9239.
Cybex Owner’s Manual Exercise Intended Use The intended commercial use of this machine is to aid exercise and improve general physical fitness. Instructions Read and understand all instructions and warnings prior to using this machine in the Safety section of the Owner’s Manual.
Page 17
Cybex Owner’s Manual CAUTION: Serious injury can result if precautions are not followed. Use equipment only as described in placards located on each machine. Failure to use in the manner depicted can result in injury. BACK EXTENSION START FINISH Motions Developed...
Do Not inhale or swallow any cleaning product. Protect surrounding area/clothing from exposure. Use in well ventilated area. Follow all product manufacturer’s warnings. Cybex and its vendors cannot be held responsible for damage or injuries resulting from the use or misuse of...
Page 19
Cybex Owner’s Manual Clean Upholstery Then Prepare a solution of 10% household liquid soap and warm water. Apply with a soft damp cloth. If necessary, apply a solution of liquid Light Soiling cleanser with a soft bristle brush. Dampen a clean soft cloth in water and wipe residue away.
Cybex Owner’s Manual Guidelines for cleaning front panel: Use clean soft cloths or sponges for application of cleaners and again for washing and rinsing. Follow up each application with warm water rinse. DO NOT use abrasives or high alkaline cleaners.
Page 21
Cybex Owner’s Manual WARNING: Equipment hazard. To avoid serious injury or death replace worn or damaged components immediately and keep the equipment out of use until repair is completed. Inspect cables and belts Inspect all cables and belts for wear or damage and proper tension. When inspecting cables and belts, run fingers on the cable or belt, paying particular attention to bends in cables and attachment points.
Page 22
Cybex Owner’s Manual Belts Condition of Belt 3D View 3D or Side View Peeling of the belt’s skin. Wave in belt Replace belt if any Examine edge of belt (both sides). section is over 1/32” Replace belt if any section is (.03) narrower than the...
Cybex Owner’s Manual CAUTION: Worn handles Do not use handles if less then 1/8” of material remains on edge. • Replace all worn handles immediately. • Inspect bars and handles for wear, paying particular attention to tab area connection points.
Cybex Owner’s Manual Cable Adjustment Tools Required 9/16” Wrench (2) Four types of cable tension adjustment are used on Cybex Strength Systems: Cable Description Diagram Adjustment This type of adjustment uses a jam nut and a tension adjustment nut at...
Cybex Owner’s Manual Belt Adjustment Tools Required 7/32” Wrench • Torque wrench (lbs-in) • Belt Adjustment Action Using a 7/32” Allen wrench loose set screws. Pull belt tight. Secure belt in place with set screws. Torque set screws to 300-350 lb-in.
To speak with a customer service representative, call 888-462-9239 (for customers living within the USA) or 508-533-4300 (for customers outside the USA). The following information located on the serial number decal will assist our Cybex representatives in serving you. Unit Serial Number, Product Name and Model Number •...
Provide the model and serial number of your Cybex equipment. At Cybex’s discretion, the technician may request that you return the problem part(s) to Cybex for evaluation and repair or replacement. The technician will assign you a RMA number and will send you an ARS label.
