Wall-Mounted Installation
1. Use the mounting holes to mark the location of any holes that need to be drilled.
2. Drill the holes.
3. Clean the surface and mount the controller using the appropriate screw types.
Figure 3:
Wall-mounted controller
Device Dimensions
132 (5.2)
Figure 4:
Front view and side view of the enclosure
4 / 24
132 (5.2)
44 (1.7)
mm (inches)
