Distech Controls ECB-PTU Series Installation Manual page 12

Commissioning ECB-PTU Series Controllers
When using an Allure EC-Smart-Vue sensor for commissioning ECB-PTU Series controllers (the DIP switch located on the faceplate is set to 0 (all off)
and before code is downloaded to the controller from EC-gfxProgram), connect an Allure EC-Smart-Vue sensor to the controller with its Subnet ID set to
1. During commissioning, the sensor is used to set the controller's BACnet® MAC Address.
Set the connected controller's MAC Address as follows:
1. Connect an Allure EC-Smart-Vue sensor to the controller with a Cat 5e patch cable. Wait for the display to show the room temperature.
2. Press and hold the Menu button
3. Use the down button to set the number to 9995 (this is the default password).
4. Press the Menu button
5. Press the down button
dress.
6. Use the up and down
7. Press the Menu button
8. Press and hold the Menu button
Once the BACnet MS/TP network is operational, the controller can be programmed with EC-gfxProgram. For each Allure EC-Smart-Vue sensor, set its
Subnet ID number to the block number of its associated CommSensor block in EC-gfxProgram. This is done in the sensor's GEN CFG menu under SUB-
NET ID.
12 / 24
for 5 seconds to enter the password menu. 10000 is shown on the display.
to submit the password. Upon submitting the password, the GEN CFG menu appears on the display.
once to enter the GEN CFG submenu. The MAC ADDRESS menu is shown with the current controller's BACnet MAC Ad-
buttons to set the controller's MAC Address. Only addresses from 1 to 127 are recommended to be used.
once to apply the value.
for 5 seconds to exit the configuration menu.
Screen Timeout: 15 seconds
OR
Screen Timeout: 15 seconds
OR
Screen Timeout: 30 seconds
OR
