  • Page 1 # 404613-8 Square Bale Wrapper 780 SB Operator’s Manual 2017...
  • Page 3 The il lustrations in th is m anual are p resented for yo ur referen ce according to the la test information ava ilable at the mo ment o f printing . ANDERSON GROUP reserve s the righ t t o...

  • Page 4: Table Of Contents

    Table of Contents 1 Anderson limited warranty ..................4 Purpose of Warranty: ....................5 Warranty Exemptions: ....................5 No Dealer Warranty: ....................5 Anderson’s Responsibilities: ..................5 2 Safety ........................7 Safe Operators ......................7 Danger Zone ......................7 Secure Attachment to the Tractor ................7 Dangerous Situations ....................
  • Page 5 - Product model and serial number; - Purchase date and invoice number; - Dealer name, address, and telephone number and salesperson name; - Precise and detailed description of your problem. ANDERSON GROUP Address: 5125 de la Plaisance Chesterville (Québec) CANADA G0P 1J0 Email Service: service@grpanderson.com...

  • Page 6: Anderson Limited Warranty

    In no event w ill Anderson be liable f or any incidental or co nsequential damages o r • injuries, including but not limited to loss of profits, rental of sub stitute equipment, or other comm ercial or p ersonal loss or d amages ar ising as a result of a fundamental breach or breach of a fundamental term.

  • Page 7: Purpose Of Warranty

    The fundamental responsibility of warranty is to correct defects in material and workmanship of the pro ducts s old by Gro up Anders on Inc. (her eafter called ‘’Anderson’’). T his ou tline is intended to assist you in awareness of Anderson’s Warranty Policies and to assure that you obtain the best service possible for your Anderson machine.
  • Page 8 ANDERSON GROUP 5125 de la Plaisance Chesterville (Québec) CANADA G0P 1J0 PH: (819) 382-2952 EMAIL: service@grpanderson.com...

  • Page 9: Safety

    2 Safety Your ANDERSON bale wrapper was designed to reduce to a minimum the risks to the operator. However, it must be used only for the work it was designed for. Additionally, since it includes a powerful hydraulic system, moving metal parts, a nd a gas oline engine and al l these elements can cause se rious injury to hu mans or anima ls, it is strongly recommended to read and to closely adhere to the following guidelines.

  • Page 10: Hydraulic Oil

    tighten the tank cap and wipe away any spilled fuel. Never add gasoline when the engine is hot or operating. Have a working fire extinguisher within arm’s reach near the baling site.. Hydraulic Oil Any leak o f pressurized oil can cause serious injuries. Do no t use your hands to l ocate a leak , but rat her an o bject s uch as a piec e o f c ardboard.

  • Page 11: End Of Operation

    End of Operation At the end o f each day’s work and especially if you will not u se the bale wrapper again for a long period of time, do not forget to close the engine fuel valve (1), located beneath the choke on the right side of the engine (Figure 2.2).

  • Page 12: General Characteristics And Specifications

    3 General Characteristics and Specifications Congratulations! You are now the ow ner o f a n AND ERSON bal e wrapper, a hi gh-quality machine designed for the separate outdoor storage of different types of large square bales of up to 7 2 inc hes (2 m) in leng th. T his ag ricultural m achine i s car efully m anufactured b y our company to give you many years of reliable performance.
  • Page 13 Standard Components Your i ndividual 780SB bal e wrapper i s of the st ationary type, though it c an al so be t owed because it is equipped with a sturdy axle system. The table is rotated by a hydraulic engine and gears.

  • Page 14: Adjustment Procedures

    4 Adjustment Procedures Verifications Before Each Use Check the hydraulic oil level in the tank of your unit. Check the oil level in the Honda engine, if applicable, as w ell as the need for fu el. Open the fuel valve and check the engine air filter. If necessary, lubricate the ma chine well after each day of use .

  • Page 15: Testing The Plastic Film Stretcher

    Follow the diagram (Figure 4.2) to unro ll the start of the film between the rubber ro ller and an aluminium ro ller, t hen arou nd the o ther al uminium ro ller. Open the fi lm cutter wit h the lever and place it at the edge of the film.

  • Page 16: Adjusting The Plastic Film Cutter

    These two conically shaped support rollers are made of rigid plastic and are placed on each end of the table between the feed rollers to hold your bale in place. In the factory, they are placed approximately 6 2 inche s (1 .57 m ) ap art to hold b ales of 6 0 inc hes (1 .2 m ) in l ength, w ith 2 inches of play at each end.

  • Page 17: Operating Procedures

    5 Operating Procedures Computer operator’s manual See the computer operator’s manual for individual bale wrapper.

  • Page 18: Maintenance Procedures

    Grease Gun Lubrication Your ANDERSON bale wrapper must be lubricated with a grease gun in the places indicated by the sticker (Figure 6.1). Figure 6.1 Grease gun lubrication...
  • Page 19 Four central bearings of the rollers (2 grease cups at each end) Optional front and rear stabilizers (2 grease cups each) and Cylinder axles (2 each) Axle of front stabilizer cylinder Plastic film cutter (3 beneath and 1 on the side)
  • Page 20 Barrier of tilting table (1 on top) Pivots of tilting table (2)
  • Page 21 Central axle of turntable (1 on the top) Pivot of plastic film roll support Pivot of unloading platform (2 grease cups on the platform)
  • Page 22 Axle of unloading platform (2) Axle of unloading platform cylinder...

  • Page 23: Other Lubrication Points

    Other Lubrication Points The p ower transmission cha ins and ot her m oving part s o f the mac hine must be o iled or greased regularly or every 50 hours. This also applies to the 2 toothed wheels of the plastic film stretcher.

  • Page 24: Cleaning And Other Maintenance

    Figure 6.4 Chain lubrication Cleaning and Other Maintenance Pay particular attention to the cleanliness of the plastic film cutter system. An accumulation of debris (hay, dust, string, etc.) can reduce its functionality. Regularly check the cutting condition of the blade. Always keep the rollers and the gears of the plastic film stretcher free of a ll residue to p revent these p arts from jam ming, b reaking, or tearing the p lastic film.

  • Page 25: Troubleshooting: Problems And Solutions

    7 Troubleshooting: Problems and Solutions Before cal ling a tech nician, exa mine yo ur m achine and co nsult the tab le b elow to find a solution. Attempt to i solate the problem to find out if it is a hyd raulic or electrical problem by using the manual functions on the hydraulic valve.
  • Page 26 The rubber stopper moves back too far The plastic film cutter clamp does 4. The plastic film cutter on its adjustment bolt. Adjust the bolt. not hold onto the end of the The sto pper sprin g ne eds to be m ore does not work well.

  • Page 27: Optional Equipment

    8 Optional Equipment Front (1) and Rear (2) Stabilizers Activated by hydraulic cylinders and controlled by manual controls at the front of the machine, these two pieces of equipmen t improve the stab ility of the bale wrapper. They a re equi pped with security valves (l ock va lves) to p revent the f eet fr om co llapsing, w hether t he machine i s turned on or no t.
  • Page 29 Parts manual Square bale wrapper 780 SB ALWAYS KEEP THIS MANUAL WITH THE WRAPPER...
  • Page 31 Content 1 – Principal frame 2 – Tow bar 3 – Tandems and axles 4 – Dumping table 5 – Rotary table 6 – Traction tandem 7 – Tandem with ratchet 9 – Plastic cut and hold support 10 – Stretcher support 11 –...
  • Page 32 For any parts order, please use the parts manual to find the item(s) you need and contact your dealer to order it. ANDERSON GROUP 5125 de la Plaisance Chesterville (Québec) CANADA G0P 1J0 Fax : 1-819-382-2218 Email : service@grpanderson.com Visit our website ...

  • Page 34: Principal Frame

    1 - PRINCIPAL FRAME DETAIL A Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...
  • Page 35 6 M.JIC - 6 M.ORB 450913 6 F.JIC - 6 M.JIC 507125 U BOLT 3/8'' X 1 3/4'' 224262 SAFETY STAND 320021 LOCK PIN 5/16 X 2 3/4 Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 36: Tow Bar

    TOW BAR'S HAND 500177 BOLT 501024 FLANGE NUT 465903 HYDRAULIC VALVE 451265 HYDRAULIC FITTING 451179 HYDRAULIC FITTING 500017 BOLT 322457 JACK 224004 HOSE HOLDER 500088 BOLT 501032 NYLON NUT Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 37: Tandems And Axles

    ROLLING BEARING CAGE LM48510 303034 BEARING LM48548 303077 RADIAL SHAFT SEAL 2500-2 1-2 X 1 3-4 -A 481000 DUST CAP 507010 WHEEL BOLT 1/2-20 X 1 1/2 Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 38: Dumping Table

    HEX BOLT GR5 1/2-13 X 2 1/2 500044 HEX BOLT GR5 5/16-18 X 1 224015-2 GEAR 224192 WASHER 224016-1 REAR SHIELD 500084 HEX BOLT GR5 3/8-16 X 1 224017-1 FRONT SHIELD 221020 WASHER Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...
  • Page 39 FLAT WASHER 3/8 Z 485755 HEX NUT 1-14 485756 LOCK WASHER 900655 SPEED SENSOR PARTS LIST ITEM PART DESCRIPTION 322299 GREASE FITTING 467029 HYDRAULIC CYLINDER 451261 HYDRAULIC FITTING Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 40: Rotary Table

    PLASTIQUE CUT AND HOLD 224327-1 TANDEM WITH RATCHET 224328-2 TRACTION TANDEM 224329-2 COMPLETE ROTARY TABLE 224330-1 PLASTIC CUT AND HOLD SUPPORT 304013 SPRING 224331-1 COMPLET SUPPORT ROLLER Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...
  • Page 50 11 - ROLLER SUPPORT PARTS LIST ITEM PART DESCRIPTION NOTE 325107 303045 BEARING 320006 RETAINING RING 486237 PLASTIC CONE 224351-1 ROLLER SUPPORT BASE Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 51: Stretcher Support

    HEX NYLON LOCKNUT GR5 3/8-16 Z 224085-1 SUPPORT PLATE 500189 HEX BOLT GR5 1/2-13 X 4 501034 HEX NYLON LOCKNUT GR5 1/2-13 Z 500099 HEX BOLT GR5 3/8-16 X 3 Groupe Anderson, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 54: Front Guard

    13 - FRONT GUARD DETAIL A DETAIL B Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...
  • Page 55 450196 HYDRAULIC FITTING 502002 FLAT WASHER 1/4 Z 315209 COMPUTER KIT 223241 COMPUTER GUARD 315181 CONTROL 450024 8 M.NPT - 4 F.NPT 450253 8 F.NPT - M.NPT Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 56: Power Unit

    PUMP ADAPTER 451190 HYDRAULIC FITTING 224108 TANK 470990 STRAINER 470117 PLUG 450725 HYDRAULIC FITTING 450717 HYDRAULIC FITTING 500092 BOLT 501022 FLANGE NUT 501020 FLANGE NUT 500004 BOLT Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 57: Stretcher

    HEX FLANGE NUT GR2 3/8-16 Z 303018 BEARING 6203 315007 HEX SENSOR NUT SIF5 502080 LOCK WASHER 224069 ROULEAU D'ALUMINIUM 210589-1 COVER 502002 FLAT WASHER 1/4 Z 279103 GEAR 279104 GEAR Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 58: Stretcher Post

    16 - STRETCHER POST Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...
  • Page 59 HEX NUT 1/4-20 Z 304009 SPRING 502002 FLAT WASHER 1/4 Z 320027 RETAINNING RING INT. 1 3/4 320113 RETAINNING RING EXT. 3/4 B 325181 CABLE 319798 WORK SPOTLIGHT Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 62: Front Stabilizer Support

    501057 HALF NYLON NUT 20 - FRONT STABILIZER PARTS LIST ITEM PART DESCRIPTION 322299 GREASE FITTING 500332 BOLT 501037 NYLON NUT 224104-1 FRONT STABILIZER'S FRAME 224105-1 FOOT Groupe Anderson, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 63: Rear Stabilizer

    21 - REAR STABILIZER PARTS LIST ITEM PART DESCRIPTION 500332 BOLT 322299 GREASE FITTING 224106-1 REAR STABILIZER'S FRAME 501037 NYLON NUT 224105-1 FOOT Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 68: Electrical Diagram

    23 - ELECTRICAL DIAGRAM Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...
  • Page 69 465045 CUT AND HOLD CHECK VALVE 315056 2ND TENSIONNER SENSOR (OPTION) 315060-1 2ND TESNSIONNER SENSOR WIRE HARNESS (OPTION) 465982 MAIN VALVE 465903 PROPORTIONNAL VALVE 315209 COMPUTER KIT Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 70: 2Nd Pole Tensioner

    HEX BOLT GR5 1/2-13 X 4 1/2 500099 HEX BOLT GR5 3/8-16 X 3 466998 HYDRAULIC VALVE 507041-3 PHILLIPS ROUND HEAD MACHINE SCREW 10/24 X 2 Z 501050 HEX NYLON LOCKNUT GR5 #10-24 Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 71: 2Nd Tensioner Assembly

    PIN Ø1 1/2 " X 7 13/16" 224228 STRETCHER DOUBLE PIN 224229 PIN Ø3/4" X 5 3/8" 234020 HOSE CLIP 224230 WASHER 320043 COTTER PIN 5/32 X 1 1/2 320007 LINCHPIN Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 72: Deviator Assembly

    26-DEVIATOR ASSEMBLY DETAIL D DETAIL E Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...
  • Page 73 RETAINNING RING EXT. 3/4 B 507066 EYE BOLT 501000 HEX NUT 1/4-20 Z 500006 HEX BOLT GR5 1/4-20 X 1 325181 CABLE 320027 RETAINNING RING INT. 1 3/4 Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...
  • Page 74 26-DEVIATOR ASSEMBLY Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...
  • Page 75 CARRIAGE BOLT GR5 3/8-16 X 1 1/4 Z 224264 REVOLVING SUPPORT 224217-1 DEVIATOR 224265 TENSIONER 224266 SPACER 224267 STOPPER 304074 SPRING 481016 PLASTIC PLUG 451224 6 M.JIC - 4 M.O-RING Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 76: 2Nd Plastic Cut

    PLASTIC CUT ARM 501024 HEX FLANGE NUT GR2 1/2-13 Z 500501 CARRIAGE BOLT GR5 1/2-13 X 1 1/4 Z 500185-1 HEX BOLT GR5 1/2-13 X 3 FULL THREAD Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...
  • Page 77 HEX BOLT GR5 1/4-20 X 3/4 502044 LOCK WASHER 1/4 Z 224256 SLIDER GUIDE 224257 SLIDER 325204 BLADE 224237 BLADE SUPPORT 507081 PHILLIPS ROUND HEAD MACHINE SCREW10/24 X 1/2 Z Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...
  • Page 78 COTTER PIN 1/8 X 1 1/2 502002 FLAT WASHER 1/4 Z 502044 LOCK WASHER 1/4 Z 224238 BLADE PROTECT 467000 HYDRAULIC CYLINDER 451258 6 M.JIC - 4 M.ORB 90° Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...

  • Page 79: Road Light

    900560 ROAD LIGHT 224251 RIGHT LIGHT PROTECTOR 224252 LEFT LIGHT PROTECTOR 315204 ROAD LIGHT 234221 COMPLETE ROAD LIGHT KIT 900562 CONTOUR LIGHT 315111 PLUG TRAILER 4 PLUG Anderson Group, 5125 de la Plaisance Chesterville (Québec) G0P 1J0 Email : service@grpanderson.com...
