COLOUR VIDEO MONITOR
CVM 2037 & CVM 2051
INSTRUCTION MANUAL
Including PAL, NTSC & PAL/SECAM Decoders
Serial Number :
This manual complies with Software Version 2.X
Edition : 22 September 1993
BARCO n.v.
Th. Sevenslaan 106
FAX 32-56-233.461
Serial NR : 5616090
Part Nr.: V9514210
CVM2037
IH
PAL B
EBU

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CVM 2037 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Barco CVM 2037

Summary of Contents for Barco CVM 2037

  • Page 1 Keys may be protected and only available after input of a suitable password. Information to modify this, is explained in this manual. COLOUR VIDEO MONITOR CVM 2037 & CVM 2051 INSTRUCTION MANUAL Including PAL, NTSC & PAL/SECAM Decoders Serial NR : 5616090 Part Nr.: V9514210...
  • Page 2 This monitor has been manufactured by BARCO n.v. in Belgium. Thematerial contained inthismanual consists of information which is the property of BARCO and is intended solely for use by the purchasers of thetypeof monitordescribed in this manual. The CVM contains material in which BARCO retains proprietary rights.

  • Page 3: Table Of Contents

    INTRODUCTION & CONTENTS Introduction This manual must help you to use and maintain correctly the broadcast monitors CVM 2037 and CVM 2051. Contents Introduction & Contents Specifications 1 Installation 6 Outside terminals and switches 7 Operation 9 Front panel indicators 9...
  • Page 4 SERVICE SAFETY PRECAUTIONS WARNING: SAFETY WARNING: X-RADIATION ELECTRIC SHOCK OR FIRE HAZARD CAN BE X-RADIATION CAN BE CAUSED IF CRITICAL CAUSED IF CRITICAL COMPONENTS ARE REPLACED COMPONENTS ARE REPLACED BY NON-CONFORM BY NON-CONFORM COMPONENTS. THESE COMPONENTS. THESE COMPONENTS ARE MARKED IN COMPONENTS ARE MARKED IN THIS GUIDE BY A ,L SIGN.
  • Page 5 DIESES TECHNISCHE HANDBUCH SO LLTE SORGFALTIG GELESEN WERDEN BEVOR DIE NETZSPANNUNG ANGELEGT WIRD ACHTUNG RONTGENSTRAHLUNG !! ACHTUNG SICHERHEIT !! WERDEN BESTIMMTE BAUTEILE DURCH TEILE ERHOHTE RONTGENSTRAHLUNG KANN VERURSACHT WERDEN, WENN BESTIMMTE ERSETZT, DIE NICHT DER SPEZIFIKATION DES BAUTEILE DURCH TEILE ERSETZT WERDEN DIE HERSTELLERS ENTSPRECHEN, SO KANN EIN NICHT DER SPEZIFIKATION DES HERSTELLERS ELEKTRISCHER SCHLAG ODER BRANDGEFAHR...
  • Page 6 CAUTION : HIGH VACUUM PICTURE TUBE IS DANGEROUS TO HANDLE. EMPLOYS X-RADIATION AND REFER PLACEMENT TO QUALIFIED INTEGRAL IMPLOSION SERVICE PERSONNEL. PROTECTION. REPLACE WITH A TUBE OF THE SAME TYPE NUMBER AND SUFFIX FOR CONTINUED SAFETY. X RADIATION WARNING REPLACEMENT OF CRITICAL COMPONENTS OF THIS APPARATUS (PICTURE TUBE AND OTHERS) CAN RESULT IN EXCESSIVE X RADIATION.

  • Page 7: Specifications

    The CVM20XX is characterized especially by its outstanding raster size and colour temperature stability. Automatic colour temperature alignment is standard equipped (for use with optional THOMA Colour Analyzer and BARCO Light Probe). Special features Easy operation and alignment by help of an on-screen display. The Affordable intelligence CVM20XX has a build-in character generator.
  • Page 8 Digital D1/D2 interfaces for serial (270 Mbit) and parallel inputs THOMA Colour Analyzer for automatic colour temperature align- ment BARCO Light Probe for automatic colour temperature alignment Single Remote Control (simultaneous control of up to 12 monitors) Multi-Monitor Remote Controller (individual or simultaneous control...
  • Page 9 SPECIFICATIONS (continued) Technical specifications Mains power Line voltage (nom.) 117/220 Vac +15%/-20% autoranging Line frequency 48 Hz to 100 Hz Power consumption (typ.) 120 W Scanning Systems 625 lines / 50 fields / interlaced 525 lines / 60 fields / interlaced Color systems PAL B (notch filter decoder) or NTSC 3.58 (Comb filter decoder) or PAL/SECAM decoder...
  • Page 10 SPECIFICATIONS (continued) CVM 2051IM CVM 2037 IH parameters 37cm/14" 51 cm / 20" CRT SIZE dot in-line dot in-line CRT type 0.31 0.43 Pitch EBU / ASP EBU / ASP Phosphors Centre resolution (TV lines) Max. convergence error 0.2 mm 0.2 mm...
  • Page 11 CVM 2037 SPECIFICATIONS (continued) CVM 2051 Dimensions .3E0- =Jig gig: P144 .„- " .../ MINIMUM INTERNAL DEPTH MAXIMUM INTERNAL DEPTH 7:435MigliT5 327.5 327.5 \ MINIMUM INTERNAL DEPTH MAXIMUM INTERNAL DEPTH...

  • Page 12: Installation

    CVM 2037 INSTALLATION CVM 2051 Visual inspection Check for supplied accessories when unpacking the monitor : mains cord and instruction manual. Before installation of the monitor, inspect for damage that may have occurred in transit. If the monitor was damaged in transit, file a claim with the carrier.

  • Page 13: Outside Terminals And Switches

    CVM n3 OUTSIDE TERMINALS & SWITCHES POWER ON / OFF (on front side) Push-push button to turn the monitor on (pushed in) and off (re- leased). LINE Line input. CAUTION : before connection, check for correct line voltage as noted on the rear side of the monitor. FUSE Fuse holder.
  • Page 14 OUTSIDE TERMINALS & SWITCHES (continued) REMOTE 2 REMOTE 1 REMOTE 2 Female and male 9-pins receptacles for remote control. MMRC and CVS compatible. Permits different ways of remote control, using a : SRC (Single Remote Controller) for full remote control of REMOTE 1 one monitor via REMOTE 1 connector —...

  • Page 15: Front Panel Indicators

    FRONT PANEL INDICATORS TALLY LIGHTS Two tally lights, a red one on the left and a green one on the right. The tally lights are controlled via the 9-pin connector named TALLY on the rear side of the CVM. COMP INP (ANALOG COMPONENTor DIGITAL INPUT) which lights up when the component (Optional) input is Green selected.

  • Page 16: Control Function Keys

    CONTROL FUNCTION KEYS CVM 051 There are five pairs of control function keys available: for contrast brightness, saturation, hue and volume adjustment. The controls are monitor related and not input related. Except for the VOL keys, all the control function keys provide the possibility to act on picture contents.

  • Page 18: Command Keys

    COMMAND KEYS SAVE When this key is pressed, all control functions assume calibrated value, and picture will directly modify to calibrated status. Hereby a list of the functions which are set by the CAL command and how : CON, BRI, SAT, HUE, VOL, R (ON), G (ON), B (ON), SYNC (INTERNAL), SL/F (SLOW), MONO (COLOUR/AUTOMATIC), COMB(OFF), APT (OFF), SIZE (UNDER- SCAN), DEL (NO DELAY), SETUP ELIM.
  • Page 19 COMMAND KEYS (continued) COMP INP (ANALOG COMPONENT OR DIGITAL INPUT) .::::. -..: • SL/F SYNC COMP INP Analog Component Input Module INP3 INP2 INP1 Key for the selection of the signals applied to the component DOWN inputs. The component input format can be programmed to one of the three following ones: RGB , Y/R-Y/B-Y or S-VHS .
  • Page 20 COMMAND KEYS (continued) MONO c• MONO COMB Key for the selection between three different colour modes. 1/ 4 ♦ If a colour video signal is displayed in colour, consecutive MONO SIZE DELAY key presses permit the selection of : COLOR OFF / FILTERED COLOR OFF / FULL BANDWIDTH COLOR / AUTOMATIC and so on ...
  • Page 21 COMMAND KEYS (continued) DEG (DEGAUSS) Key to manually degauss the monitor. When turning on the monitor, automatic degaussing is obtained. The DEG key makes immediate degaussing possible, without having to switch off the display. After manual or automatic de- gaussing, please wait a few minutes before reactivating; only in this way effective degaussing is obtained.

  • Page 22: Colour Temperature Selection

    COLOUR TEMPERATURE SELECTION Five colour temperatures can be selected : 3200 K, 6500 K, 9300 K, A and B (A and B are customer defineable colour tempera- tures). There are three ways to select a colour temperature : The colour temperature is always set then to 6500 K. 1 Press CAL.

  • Page 23: Menu

    Configuration setting Status report and Preset programming Colour temperature alignment : Manual with internal signal Automatic with Thoma Automatic with Barco probe Manually via keyboard Display of adjustment values Remote Control settings (address and on/off setting) Geometry alignment via keyboard Privilege setting (password entrance, enabling &...

  • Page 24: Keyboard Extension

    To exit : CLEAR to start automatic colour temperature alignment with Press Thoma or Barco Light Probe as selected before. To know what has been selected or to modify the selection, refer to the description of AUTOMENU. Press for colour temperature selection, setup elimination on/off setting (NTSC) and component or digital input format selection.
  • Page 25 CVM 2 KEYBOARD EXTENSION If an Analog Component Input board is installed and via the Configuration Menu, the input is programmed for "COMPONENT MODULE", you get next Keyboard Extension menu : KEYBOARD EXTENSION Color Temp. I 6500 NTSC setup elim. Sync Fixed Ext.

  • Page 26: Monitor Configuration

    MONITOR CONFIGURATION MONITOR CONFIGURATION PROGRAMMABLE INPUT SELECTION RIS CONFIGURATION To return : CLEAR Press 1 if you want to let the monitor know what input module is in- stalled in the monitor (analog component or digital). Press 2 for programming the RIS (Remote Input Selection) con- figuration.
  • Page 27 CLEAR Press to return with saving. ENTER For "INPUT you get e.g. next menu (setting SWITCHING ONLY", most compatible with all other BARCO monitors) : INPUT SWITCHING MODE SW 1 SELECTED INPUT open closed INP 1 open...
  • Page 28 MONITOR CONFIGURATION (continued) For "FUNCTION SWITCHING", you get e.g. next menu : FUNCTION SWITCHING MODE SW 1 SW 2 SCAN FORMAT To return without saving : CLEAR To return with saving ENTER For each of the two switches SW1 and SW2, you can select using the TOGL key between : INP1-INP2 INP1-INP3...

  • Page 29: Status (Preset Input X)

    STATUS (PRESET INPUT X) STATUS (PRESET INPUT 1) Contrast Brightness Saturation Volume Color Aperture Comb NTSC setup elim. Size UNDERSCAN INTERNAL Sync Source Sync Time Ct SLOW Scan Delay NORMAL 6500 K Color Temp. RGB Drive CLEAR To return without saving : ENTER To return with saving Via this menu, you can program the Preset of an input.

  • Page 30: Alignment

    Press 4 for automatic colour temperature alignment (6500 K, 3200 K, 9300 K, A, B) with an internal or external test pattern, using a Barco Light Probe. Press 5 for manual colour temperature alignment (6500 K, 3200 K, 9300 K, A, B) with a full screen displayed external video signal and a redefined keyboard for control (color temperature overlay).
  • Page 31 ALIGNMENT (continued) Manual with internal signal MANUAL ALIGNMENT MENU COL TEMP A 6500 K 3200 K COL TEMP B 9300 K To return : CLEAR Start with 6500 K, so press 1 Lowlight setting for the three colour temperatures 6500 K, 3200 K and 9300 K is common and is only adjustable in 6500 K.
  • Page 32 ALIGNMENT (continued) Automatic with Thoma The monitor can be aligned automatically using a Thoma TMF-2, TMF-3 or TMF-6 colour analyzer. As reference can be used the monitor's internal White Field or your external White Field. For alignment with an external signal, first apply a 100% White Field to a composite input and select that input.
  • Page 33 ALIGNMENT (continued) Automatic with probe The "Automatic with probe" alignment option is only useful for owners of a Barco Light probe, a probe designed for CVS, AVM, CVM-A and CVM20XX monitors. Refer to the Barco Light Probe manual for more information.
  • Page 34 ALIGNMENT (continued) Manual with live picture MANUAL ALIGNMENT MENU COL TEMP A 6500 K 3200 K COL TEMP B 9300 K internal white field only for character colour temperature alignment with internal potentiometers To return : CLEAR This alignment mode permits manual colour temperature alignment with a full screen displayed external video signal and a redefined keyboard for control (colour temperature overlay).

  • Page 35: Service

    ALIGNMENT (continued) Manual with live picture HIGH LIGHTS RED UP & DOWN Highlight adjustment for red. HIGH LIGHTS GREEN UP & DOWN • • Highlight adjustment for green. HLB 7 HLR l HLG HIGH LIGHTS BLUE UP & DOWN Highlight adjustment for blue. HLR \ HLG 100% / 10 % Two keys to drive the internal attenuator which de-...
  • Page 36 ALIGNMENT (continued) Manual with live picture How to align the different colourtemperatures of the monitor? First adjust the colour temperature 6500 K. Before starting the alignment of another colour temperature, (key always save the previously aligned one. To do so, press SAVE (key marked to get again into the...
  • Page 37 ALIGNMENT (continued) Auto menu AUTOMENU is a feature which facilates the colour temperature alignment of the monitor by decreasing the quantity of menus you have to go through. Via the AUTO MENU SELECTION menu — when in its field for you can determine how the monitor will is entered —...
  • Page 38 ALIGNMENT (continued) Service page SERVICE PAGE 6500 K 3200 K 9300 K COL TEMP A COL TEMP B White uniformity (6) Setup elimination Five Service Pages are available, one for each colour temperature. They give an overview of the inside control codes for Contrast, Lowlights and Highlights.
  • Page 39 ALIGNMENT (continued) Service page (continued) WARNING ! Do you want to save the new values ? NO : Press CLEAR YES : Press 0 followed by ENTER Press 0 if you want to save. In case of a NTSC input signal, it is possible to eliminate and so Setup elimination = 00 compensate the setup of 7.5%.

  • Page 40: Remote Control

    (2) MMRC Multi Monitor Remote Controller, a BARCO full remote controller for up to 48 BARCO monitors as CVM2000, CVS, CVM(A) or AVM, all individually or at the same time (3) BVRS Barco Video Routing Switcher.

  • Page 41: Geometry

    GEOMETRY ( For authorized personnel only When the monitor is set to geometry alignment mode, the keyboard is modified to a "geometry overlay mode" and brightness is increased to make Horizontal Phase easier. A help text is available and can be switched on and off by pressing TOGL.
  • Page 42 GEOMETRY (continued) HORIZONTAL FREQUENCY UP & DOWN Horizontal frequency adjustment. HORIZONTAL PHASE UP & DOWN Horizontal phase adjustment. UP means to the right. PICTURE WIDTH UP & DOWN Picture width or horizontal amplitude adjustment. EAST-WEST PARABOLA UP & DOWN East-West correction setting. EAST-WEST CORNER UP &...
  • Page 43 CVM 2037 GEOMETRY (continued) CVM 2051 Howto adjust geometry? Set the monitor ready for geometry alignment of 4/3 underscan Adjust the monitor for 4/3 underscan. Copy the alignment to overscan (press SIZE). Select 4/3 overscan (press COMB). Align the monitor for 4/3 overscan.

  • Page 44: Privilege Setting

    PRIVILEGE SETTING The Privilage Setting menu allows the control of passwords. It makes them visible and permits modification. On the menu below are shown the factory set passwords. They can have been modified to others in your monitor afterwards. To get into this menu, the highest password (password 4) must be entered first.

  • Page 45: Adjustments

    CVM 2037 ADJUSTMENTS CVM 2051 For authorized personnel only Test equipment required Digital voltmeter. Dual trace oscilloscope. Video sweep generator (up to 10 MHz). Video test generator. EHT voltmeter. Extension board (order number V5627200). ADJUSTMENT PROCEDURE Preliminary WARNING Read the Service Safety Precautions at the front of this manual before starting the adjustments.
  • Page 46 ADJUSTMENTS (continued) For authorized personnel only j 2.3 Horizontal Frequency adjustment Set monitor into Geometry Alignment mode via MENU. Select external synchronization ( key) and use keys to adjust horizontal SYNC CON UP & DOWN free-running frequency (see also page 34 to 35). 2.4 On-board adjustmentsforgeometry Available on-board adjustments for geometry are : P4 HORIZONTAL SHIFT...
  • Page 47 ADJUSTMENTS (continued) For authorized personnel only 3.4 Aperture correction Apply a video sweep signal to INPUT 1. Connect the probe of the oscilloscope to TP20. lights up). Enable the aperture correction by pressing on the keyboard (green Adjust with P12 the aperture correction signal for equal level at the bottom of the sync pulse. 3.5 TDA 4510 adjustments Apply a PAL colour bars signal to INPUT...
  • Page 48 Apply a colour bars signal to input 1 Connect an oscilloscope to the green cathode Adjust P1 on the CRT-socket for 100Vdc ( for CVM 2051 IM ) and 80Vdc ( for CVM 2037 IH between the top of the AKB-pulse and ground.
  • Page 49 ADJUSTMENTS (continued) ( For authorized personnel only 6. Control & Sync board 6.1 CRTC clock generator Apply a frequency counter at TP 6 Set BR3 in Test positie ( near by U47 ) Adjust L1 for 7.5 MHz 6.2 Character generator The characters can be adjusted in highlight ( colour temperature ).
  • Page 50 Component input and audio circuit alignment ( For authorized personnel only This section contains a step by step alignment procedure for the Component Input module as mounted inside the monitor. It is advisable to perform this procedure in the same order as proposed to get optimum results. Only the alignment of the video Output Section is necessary in case of a board installation or replacement.
  • Page 51 Component input and audio circuit alignment (cont.) For authorized personnel only Decoder Section and Lum & Sync Section Factory adjusted, adjustments to be carried out only in case of replacement of compenents in the decoder section and/or Lum & Sync section. 2.1 Sandcastle pulse Program the OPT input for S-VHS format.
  • Page 52 Component input and audio circuit alignment (cont.) For authorized personnel only 2.5 Saturation Connect the oscilloscope to TP23 (red output). Adjust P4 for 100% saturation. Connect the oscilloscope to TP25 (blue output). Adjust P5 for 100% saturation. Factory adjusted, adjustments to be carried out only in Sound section case of replacement of compenents in the sound section.
  • Page 53 V5628329 DEC P/SECAM CVM2037/51 PAL/SECAM Dec. & RGB Ampl. V5628331 BACZBOARD CVM2037/51 Backboard V5628347 CRT SOCKET CVM2037 CRT Socket board CVM 2037 III V5628361 CONTROL CVM2037/51 Control Board V5628391 OPTION MOD CVM2037/51 Analog Component Input Module V5628397 EHT/DEFL IH CVM2037/51 EHT &...
  • Page 54 QTY: V602414 REAR PANEL CVM37/5120 QTY: V6024141 REAR PANEL ISOLATION QTY: V602415 MAINS FILTER SUPPORT QTY: V602455 LOGO CVM 2051-CVM 2037 00 QTY: V602774 SIDE ASSBLY R CVM2051 QTY: V602791 SIDE ASSBLY L CVM2051 QTY: V620052 PCB-HOLDER CVS QTY: V620055...
  • Page 55 CVM 2037 SCHEMATIC DIAGRAMS CVM 2051 List of schematic diagrams on next pages V5628310 Mains Input V5628306 Switched Mode Power Supply V5628397 EHT & Deflection V5628361 Control Decoder & RGB modules : V5628324 PAL Decoder & RGB amplifier NTSC Decoder & RGB amplifier V5628328 PAL/SECAM Decoder &...
  • Page 56 MAINS INPUT V5628310 POOVOCT SAFETY OOTICT COL•POodOcr• Num., Fort,. 601T * Fo0.1 MOAT C.NARAIMITTICII OTWORTANT TO WW1, WOO! 14(K4C140 ANT OF .6114 COMPONI111711 WOO ...TULLY To. VOCE *FM .11.olION• OMIT OF THS nl FUSE &•7112 0vacl 2•T1220V•c/ MAINS POWER INPUT CONNECTOR r‘a to MAINS SWITCH to 1 on...
  • Page 57 "{... T3SS22SLI1 \ — 0211 9011 E:=1920 2111 "`??, tipLI I I 1i It', 1•3 1=1)" .4=8- 2311 NO0 1111910 2011 0111 ( =D 100 SOltiNd 2r 11...
  • Page 58 ▪ 1 f■Vei 104 tilVIV 11 1 '1-'1 11111 6101•1•/ •11 ER` 1 “ entuDI ii;64 GvM1017/1111. 6,1111.*.v001 I al 1..700 " 0 .1011 M .255 Jur 352/ 3501 3'l l6 1.007 012 +1.20V T 31, 8 S 13, 2 35 TO. 0 .1uF C4 54 4701,17 —...
  • Page 59 PARTS LIST SWITCHED MODE POWER SUPPLY Order number of a complete board : V5628306 Order number Description Item V1011008 R CFFH J OW25 V1011179 R CFFH 27E J OW25 V101224 ME' H100E J OWS R51 , R60 V101225 ME' 11120E J OW5 V101230 ME' H330E...
  • Page 60 Order number Description Item C112743 C CE MI 2N2K 63E2 C112745 C CE MI 3N3K 63E2 C112763 C CE MI 10N U 63E2 V1127830 C X7R MU 100N K 50E2 125 C15 ,C32 ,C58 C112837 C CE DI lON S400E3 C42 ,C5 ,C56 ,C6 V1140296 C POMERA...
  • Page 61 EHT & DEFLECTION 1 71MII. 1111 R"2 mil. 1.4 ; R151 10I J R161 6109 "7 — ■I - ■ MIIIII 'lliM il =1.-. 11=11 LEIM "' P2 TP5 ■ • 0204 >.7 —...- ,,s, ..._../ R120 R 27 C1106--..G.J R129 01.0 R124...
  • Page 62 ▪ alai 4..10 Ica9A PIPtit 4163 — •Y 1.13n N• '" >„ 0,10_ R151 0.61014. 9— R124 1-Ak 00.7.0 2 •—• La, C RI59 ;L.311 I 0123 RI49 01•11 Mel an E62 LILNIN 11 . 0139 00,0 JI 11118 MIX SYNC ©...
  • Page 63 ▪ • • 4''/ 30V on C01203//5i CVMSY1/51 +150V in CVM2137 07: A, 1199T /6OLIFf17 49 10411 1).• 11-49401 — mall' 3.e.r _.ERR Al . • -ERR -cL L913 " ourc.-11--ft 2.21 r _423_,-1© ce t 391325C • 177 E2 --, "...
  • Page 64 PARTS LIST EHT & DEFLECTION Order number of a complete board : V5628397 Order nuMber Description Item V1011008 CFFH J ow25 R184,R70 ,R89 V1011998 CFFH El K OW4 V101204 MF H 2E2 J 11110 V101207 MF H 3E9 J 8109 V101208 MF H 4E7 J OW5...
  • Page 65 Order number Description Item V102916 R MF H 22E J 1W6 R193 V102921 R MF H 56E J 1W6 8130 V102933 R MF H560E J 1W6 V102935 R MF H820E J 1W6 V1035224 R WW R 6E8 K 4W R103 V1035483 R WW R 1K K 4W...
  • Page 66 Order nunber Description Item V131622 D BAX16 SW D035 D1 ,D14 ,D16 ,D17 ,D2 ,D3 , D5 ,D6 ,D7 V131627 D BAV21 SW 0035 D20 ,D21 ,D22 ,D23 ,D26 ,D27 , D28 ,D29 ,D34 ,D36 ,D37 ,D40 , D41 ,D45 ,D46 ,D47 V131643 1N4151 SW D035...
  • Page 67 CONTROL —.C5— 7" ()CI() ,,,..021 020 019 \ _,, =U37 141.1. 9181 .1■0.0 A:I = ,•■• 4■44.4, C101 "7 —1=11— —1=0— —CD— . . ■ ■ • ■■■•■••■ IC Oci C o C17 1■ ,■••." CI 0 ItY fin& ""...
  • Page 68 014414 4102011 10 333 10 47460 SPIA2 • LRD3 RES• .0,3AM SCRTC 01339 LRD1 O. • LRO2 V/10 5Proll BOO 01 BACKUPS 801 11 1/433D 03)2) 9013 ) B014) 13015) OD .12 60011:170 1301131 9017 90(12) .111 IRO. 1381133 4 •...
  • Page 69 •3 ...1 BA, 4I 22 BO) 0 1 JI 0)). • 10OCLIt Oa= 21 BEN 1 ) ♦ SLICIA1 =>—= a ca. 20 BC( P) 14.6 SL/F ptz• 1 0 OuriC 9 19 BEN 3/ le BO( 4 ) DCD• °49 SL/F BA( 0 7 11...
  • Page 70 11.1 1P14 451PRI HF LB' A74LsEel ° CR8INT 741 S 4 „ C105 cm, -10.113./ BA)0 151 220." US/CRTC 0, PO =>-••■•■• BA ( ) 0(8) MR( Et) I3 I> BR( 9) A( 9 ) I i2 Sax= DEC/RGE1 (10(9) 4 14 881 10) i 0)10)
  • Page 71 PARTS LIST CONTROL Order number of a complete board : V5628361 Order number Description Item V1011008 R CFFH J OW25 V101212 R MF H 10E J OWS V101224 R MF H100E J OW5 R27 ,R33 ,R40 ,R5 ,R60 ,R61 , R62 ,R63 ,R89 ,R90 V101228 R MF H220E...
  • Page 72 Order number Description Item V114480 1N M100E2 100 C115,C63 ,C64 V114482 C PO 2N2M100E2 100 C106,C108 V114483 C PO 3N3M100E2 100 C113 V131411 Q BC549C N SS TO92 Q10 ,Q11 ,Q12 , Q13 , Q14 , Q15 , Q16 ,Q19 ,Q20 ,Q21 , Q29 , Q3 ,Q5 ,Q6 , Q7 , Q9...
  • Page 73 Order number Description Item V1508101 R AI 4 100E G OW3 SIP8 AR14,AR4 ,AP5 ,AR6 ,AR7 V1508103 R Al 4 G OW3 SIPS ARI1,AR12,AR18,AR19 V1508561 R AI 4 560E G OW3 SIP8 AR10,AR16,A1117,AR9 V306222 CH TOR V V306810 4.915200 MHZ HC43 30 C306846 4.000000 MHZ HC43 V313253...
  • Page 74 area 121M/1 c1la ease 11413■11-- I Coa R390 r eLp 47.114] este - rr7L1- H ream I- 66111 Tail LEEE1 Bata u1.1 — 9103011- —I setal- .171 -1 aortal- R1014 RBI 1.- B6100 310.1.1- 2113 111- • 3 LILCO E.ol 1/111 r oTiT 324 1--...
  • Page 75 1 MR ° COMP. VIDE U ® RIO =ISCP/SDE 13. , CDL.INFO ELI .0 4 Icm tett CC FLL CIO CM IM.) 1.00C 13,86Yaletot. t—ulanzg- 7. 4 510 12,61 035 .E R1111 -11'140. ar.2 • R06 SOE .1.1u. COLOUR ON 403011 <=DNFLO <=1R `1.
  • Page 76 R3-72 —11•11, TP37 TP40 TPB0 8155 HFLB HFLB. 10544 SCP7SCIT Rill ut:Q a .wae —0 40900 rVai 7P31 VF LB JP MB PULS 91742 ?4,?. 6621 11379 SCP/PGB 0330 0111 aeasea 7P30 9041 ° SCP/SDO C2 16 0110 130021 SYNC 2117/EXT 1 = TR W 100,6 R 40993...
  • Page 77 in " 1 0 1 1.16 E:). 10 V — R199 CDT .2 © JR o 0,36C 100E 0125 .■ TPRI loots TLESIC R190 C2CI TP30 DEC .PGE1 TP2.I TP22 1823 • .26 au= 01.j 11100 DAC SRT i,A0111.4,}0 SCP/RGB WU.
  • Page 78 • • • 993 993 — -17C1/1 13 JO CK UK OK 104 0K 104 >94 L5174 3— 6l DREES ON .7=7 BLUE ON UID.1000 02 7 C 1 0 03 -II 010.100 9441413 04 04 DEC/COMP CZ 3 w 144) 1441913 cogs 1/44148...
  • Page 79 PARTS LIST PAL DECODER & RGB AMPLIFIER Order number of a complete board : V5628324 Order number Description Item C1011289 R CFFH220E J OW25 R164,R177,R190 V1011369 R CFFH 1K J OW25 R166,R179,R192 V101200 R MF H lE J OW5 8205 V101212 R MF H 10E J OW5 R141,R207,P42 ,R67 ,273 ,R85 ,...
  • Page 80 Order number Description Item ME' H 1K5 F OW4 E2 V101538 DO' H 10K F 0W4 E2 V101548 RA10 V101560 MF 11100K F OW4 E2 RA09 V102336 H 1K J 2W5 R215,R216 V1023481 MF H 12K J 2W5 R167,R180,R193 V1026006 MF H 1K F OW6 R203 V1026206...
  • Page 81 Order number Description Item V114083 C POMERA 33N K 63E2 V114084 C POMERA 47N K 63E2 C59 ,C60 V114088 C POMERA 100N K 63E2 V114090 C POMERA 220N K 63E2 C21 ,C23 V114091 C POMERA 330N K 63E2 C75 ,C88 ,C89 V114092 C POMERA 470N K 63E2 C26 ,C61...
  • Page 82 Order number Description Item V306100 CH AX NS V3061322 CH AX NS V3061342 CH AX NS Lll ,L12 ,L13 V3061362 CH AX NS R140 V306512 DL 63.943US DL701 V306531 DL 100NS V306538 DL 175NS 0306816 8.867238 MHZ HC43 V313100 J BNC FCT P 1 75E 0003 V3131001...
  • Page 83 NTSC DECODER & RGB AMPLIFIER 0127 11111 .T2. 71037 1-1\,‘„J i claa css t9 „ 17 1 35 R372 otlo 1 ck -E7D- TP31 Zi 0106 T17, R147 2132 'P25 715 R151 1-ri t ' ■ ' 7 212: I- 01.2 °I il, 1 '' 2azszv...
  • Page 84 _Ann, n nut ° 1 :74j1D'".1 a COL .INFO iniv nn• SUB 11141 CO. ON OFT CD r I.; ------ r;.. „, a•le Oul 46 1•■• NTSC DECODER DECODER&RGBAMPLIFIER SHEET 1 OF 4 INPUT AND DECODING V5628326 MODIFICATIONS RESERVED 290591...
  • Page 85 • AA • I. TP23 R155 NOLO JR HEL13 • 1T044 V° I— —1 1.03 13.1 „ 12377 TR 04 4922 SET1 40926 1942.2 TP31 1371 VFLB Jo -41042 : ae 2370 SCP/ SOD Jo leSS „ • STOIC INT/EXT 5 ".
  • Page 86 • TOOn 13193 "31E100 <=3 CA1 .R TP32 —CZ> 11472 10. cloa R203 11.4AC 1201 lOurC123 • TP36 rpr4g DEC .RGB 11, C07 • • • TP45 1P47TP46 .12U TP23 TR24 • UEU'' tun 7r2 420 DUC:1 105143 =9136 < =I SCP/RGB 0162 DAC BAT 9140...
  • Page 87 .1242 • 1544148 nrs; L3 m /OK 1004 >DK L5174 < I GREEN ON DO 00 2 • 194142 ] BLUE ON DI 01 5 „ D2 02 2 1 V1D.100x < 194142 D 0 JO C10 26 04 12 11 50 I DEC/COMP LJ RED ON...
  • Page 88 PARTS LIST NTSC DECODER & RGB AMPLIFIER Order number of a complete board : V5628328 Order nurriber Description Item C1011289 R CFFH220E J OW25 R164,R177,R190 V1011369 R CFFH 1K J 0W25 R166,R179,R192 V101200 R MF H 1E J OW5 R159,11205 V101212 R MF H 10E J OW5 R141,R144,R207,R42 ,R67 ,R73...
  • Page 89 Order number Description Item V101264 J OW5 H220K R168,R181,R194,R364,R57 V101266 MF H330K J OW5 R161,R174,R187,R363 V101282 6M8 J 0W5 MF H V101534 MF H680E F OW4 R407 V101538 1K5 F OW4 ME' H V101544 4K7 F OW4 R412,R413,R414 V101545 ME' H 5K6 F OW4 R405 V101548...
  • Page 90 Order nmdcer Description Item C112747 4N7K 63E2 C25 ,C37 V1127830 X7R MU 100N K 50E2 125 C103,C104,C11 ,C111,C113,C119, C120,C124,C18 ,C29 ,C33 ,C339, C34 ,C340,C343,C35 ,C351,C353, C357,C5 ,C56 ,C61 ,C62 V114080 C POMERA 10N K 63E2 C128,C130,C22 ,C27 ,C30 ,C341, V114082 C POMERA 22N K 63E2 C13 ,C131,C132,C135,C136,C19 ,...
  • Page 91 Order number Description Item V137508 U 7407 DIP14 P U22 ,U23 ,U24 V137513 U 74ALS574 DIP20 P U25 ,U26 C137700 U 4053B DIP16 P Ul ,U11 ,U13 ,U14 ,U17 ,U18 , U28 ,U7 ,U8 ,U9 V137719 U 2595 DIP18 P V137725 U 3507 DIP28 P...
  • Page 92 • — 111•11. =33 AMPLIFIER arrOICIE DECODING =EE-ERVED 290591...
