Coronis Uniti
User Guide
MDMC-12133
ENABLING BRIGHT OUTCOMES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Coronic Uniti and is the answer not in the manual?

Questions and answers

Related Manuals for Barco Coronic Uniti

Summary of Contents for Barco Coronic Uniti

  • Page 1 Coronis Uniti User Guide MDMC-12133 ENABLING BRIGHT OUTCOMES...
  • Page 2 Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com Registered address: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com/en/support www.barco.com...

  • Page 3: Table Of Contents

    Table of contents 1 Welcome! ..........................................5 About the product....................................6 What's in the box....................................6 2 Parts, controls and connectors................................7 Display front view....................................8 Display rear view....................................9 Accessories......................................10 3 Display installation .......................................13 Removing the connector compartment cover........................14 Unlocking the tilt mechanism ..............................14 Unlocking the height mechanism.............................15 Adjusting the display position..............................16 Connecting the signal cables ..............................17 Connecting the power cable ...............................19...
  • Page 4 SoftGlow Task light ..................................35 SoftGlow Wall light ...................................36 DPMS mode......................................36 Hibernate .......................................36 5.10 Delayed power down ..................................37 5.11 I-Luminate default mode ................................37 5.12 I-Luminate film position..................................38 5.13 Luminance target ....................................38 5.14 Color presets .......................................39 5.15 Color temperature.....................................39 5.16 Color coordinates....................................39 5.17 Viewing modes ....................................40 5.18 Display functions ....................................40 5.19 Ambient Light Compensation (ALC) ............................41...

  • Page 5: Welcome

    Welcome! K5902079-07 Coronis Uniti...

  • Page 6: About The Product

    • MultiTouchPad If you ordered a Barco display controller, it's also in the box together with its accessories. A dedicated user guide is available on the system CD. Keep your original packaging. It is designed for this display and is the ideal protection during transport and storage.

  • Page 7: Parts, Controls And Connectors

    Parts, controls and connectors K5902079-07 Coronis Uniti...

  • Page 8: Display Front View

    Parts, controls and connectors 2.1 Display front view Overview Image 2-1: Front view I-Luminate/Left key Right key Menu key Standby key Power status indicator light (Power On) Power status indicator light (Standby) I-Guard Ambient light sensor K5902079-07 Coronis Uniti...

  • Page 9: Display Rear View

    Parts, controls and connectors 2.2 Display rear view Connector compartment cover closed Image 2-2: Rear view with closed connector compartment cover Connector compartment cover Tilt lock pin (only for transportation) Tilt & swivel foot Cable duct Foot lock pin (only for transportation) SoftGlow Task light SoftGlow Wall light Store the foot lock pin and tilt lock pin for possible future transportation of the display.

  • Page 10: Accessories

    Parts, controls and connectors Connector compartment cover open Image 2-3: Rear view with open connector compartment cover Power connector Display port connector Display port connector Not used USB upstream connector USB downstream connector (see tip below) USB downstream connector (see tip below) USB downstream connector (see tip below) Please connect your keyboard or mouse to your PC rather than to the Uniti USB ports when hibernate is enabled (default setting).
  • Page 11 Parts, controls and connectors Image 2-4: Film clip MultiTouchPad The MultiTouchPad enables and controls SpotView. Image 2-5: MultiTouchPad K5902079-07 Coronis Uniti...
  • Page 12 Parts, controls and connectors K5902079-07 Coronis Uniti...

  • Page 13: Display Installation

    Prior to installing your Coronis Uniti and connecting all necessary cables, make sure to have a suitable display controller physically installed in your computer. If you are using a Barco display controller, please consult the user guide delivered with it to do this.

  • Page 14: Removing The Connector Compartment Cover

    Display installation 3.1 Removing the connector compartment cover The connector compartment cover should be removed to get access to the connectors. To remove the connector compartment cover Gently push the two lips on the top of the cover. Pull the top of the cover slightly away from the display and lift the cover upwards. Remove the cover.

  • Page 15: Unlocking The Height Mechanism

    Display installation Keep the pin in case the display needs to be shipped later. WARNING: Before transportation of the display, insert the pin in the lock mechanism so that the grey color of the pin isn't visible anymore. 3.3 Unlocking the height mechanism In the factory, the height-positioning system in the display stand is locked with a red pin to prevent damage during transportation.

  • Page 16: Adjusting The Display Position

    Display installation Keep the pin in the dedicated hole in case the display needs to be shipped later. To retain the pin for possible future transportation, insert the short, red end of the pin back into the stand of your display. 3.4 Adjusting the display position In the factory, the height-positioning and the tilt system in the display stand are locked with red pins to prevent damage during transportation.

  • Page 17: Connecting The Signal Cables

    Display installation CAUTION: Do not try to pivot your display when attached to the stand. Trying to do so could cause serious damage to your display and its stand. 3.5 Connecting the signal cables To get access to the connectors, remove the connector compartment cover. See “Removing the connector compartment cover”, page 14.
  • Page 18 Display installation Connect another head of the display controller to the other DisplayPort connector with one of the supplied DisplayPort cables. Connect a PC USB downstream connector to the display’s USB upstream connector by means of the supplied USB 2.0 cable. K5902079-07 Coronis Uniti...

  • Page 19: Connecting The Power Cable

    Display installation Please connect all your displays to their workstation with a USB cable to ensure undisturbed communication and to make optimal use of MediCal QAWeb and the Barco intuitive workflow tools. 3.6 Connecting the power cable To connect the power cable to the display: Connect the supplied external DC power supply to the +24 VDC power input of your Coronis Uniti display.

  • Page 20: Mounting The Film Clip

    Display installation Warning: Fasten the power connector to your display with the screws provided at the sides of the connector. Plug the other end of the external DC power supply into a grounded power outlet by means of the proper power cord delivered in the packaging.

  • Page 21: Routing The Cables & Reattach The Connector Compartment Cover

    Display installation With the MultiTouchPad attached and the driver installed, simply press on the MultiTouchPad to move the focus on the SpotView around the display(s). The SpotView vanishes when no finger is pressing on the MultiTouchPad, unless the left side of the MultiTouchPad button is held down. 3.9 Routing the cables &...
  • Page 22 Display installation Tip: The cable straps at the inside of the connector compartment allow you to fix the cables for better shielding of the cables. To reattach the connector compartment cover Reattach the connector compartment cover by sliding the cover's top. You'll hear a “click” sound of the cover's clips when the connector compartment cover is in position.

  • Page 23: Fixation Of The Foot On The Desk

    Display installation 3.10 Fixation of the foot on the desk Overview If you would like to attach the Coronis Uniti to a desk, the tilt & swivel foot has 4 screw holes (4x M4) to mount the foot on a desk. Drill four holes in the desk.
  • Page 24 Display installation WARNING: To avoid muscle strain or back injury, use lifting aids and proper lifting techniques when removing or replacing. Overview The panel, standard attached to the tilt & swivel foot, is compatible with the VESA 200 x 100 mm and VESA 100 x100 mm standard.
  • Page 25 Display installation Remove the 9 screws fixing the foot while supporting the foot. Attach the arm stand firmly to the panel using 6 screws M4 x 6 mm for a 200 x 100 mm VESA solution or 4 screws M4 x 6 mm for a 100 x 100 mm VESA solution. WARNING: Never move a display attached to an arm by pulling or pushing the display itself.

  • Page 26: First Time Starting Up

    Your Coronis Uniti display will be running in a basic video mode at a default refresh rate when first time starting up. If you are using a Barco display controller, please consult the dedicated user guide available on the system CD to install the drivers, software and documentation. When this is done, your display will automatically detect the connected video input signal(s) and apply the correct video mode and refresh rate.

  • Page 27: Daily Operation

    Daily operation K5902079-07 Coronis Uniti...

  • Page 28: Recommendations For Daily Operation

    LCD displays use technology based on pixels. As a normal tolerance in the manufacturing of the LCD, a limited number of these pixels may remain either dark or permanently lit, without affecting the diagnostic performance of the product. To ensure optimal product quality, Barco applies strict selection criteria for its LCD panels.

  • Page 29: Standby Switching

    Daily operation illuminated and are now available for further actions. However, if no further actions are taken within the following 5 seconds, the keys will dim again. The I-Luminate/Left key is always lit and available for activation of the I-Luminate feature. Please refer to “I-Luminate”, page 31 for more information.

  • Page 30: Navigating Through The Osd Menus

    Daily operation The OSD menu auto-exit function can be disabled in the OSD menu. Please refer to “OSD menu automatic close function”, page 34 for detailed instructions on how to do this. 4.5 Navigating through the OSD menus How to navigate through the OSD menus Navigating through the OSD menus can be done by: •...

  • Page 31: I-Luminate

    Daily operation Left key Right key Behavior No push Push No menu Cycle I-Luminate modes between text small film, large film, no film Push Push No menu Cycle viewing mode between text and diagnostic, also toggle off I- Luminate No push No push Menu Nothing...

  • Page 32: Viewing Mode

    Daily operation 4.8.2 Viewing mode To quickly change the viewing mode While no OSD menu is on the screen, press the Left key and Right key simultaneously to change the viewing mode. Toggle the available viewing modes (see “Viewing modes”, page 40) by pressing the Left/Right key simultaneously.

  • Page 33: Advanced Operation

    Advanced operation K5902079-07 Coronis Uniti...

  • Page 34: Osd Menu Language

    Advanced operation 5.1 OSD menu language About the OSD menu language By default, the OSD menu comes up in English. However, there’s a wide range of other languages available for the OSD menu of your Coronis Uniti. To change the language of the OSD menu: Bring up the OSD main menu.

  • Page 35: Key Indicator Lights

    Advanced operation Select Enabled/Disabled as desired and confirm. 5.4 Key indicator lights About the key indicator lights By default, after lighting up, the key indicator lights will dim again if no further actions are taken within the following 5 seconds. However, this behavior can be changed so that the key indicator lights are always on or always off.

  • Page 36: Softglow Wall Light

    By default, DPMS mode is enabled on your display, but it also needs to be activated on your workstation. To do this, go to the “Power options properties” window of your workstation. Barco recommends setting DPMS activation after 20 minutes of non-usage. When DPMS mode is enabled on your display, an additional OSD power saving function becomes available: hibernate.

  • Page 37: Delayed Power Down

    Advanced operation Hibernate can only be enabled on your display when the DPMS mode is enabled first. Therefore, please refer to “DPMS mode”, page 36 to do this. Please connect your keyboard or mouse to your PC rather than to the display's USB ports when hibernate is enabled.

  • Page 38: I-Luminate Film Position

    Advanced operation To set the I-Luminate mode: Bring up the OSD main menu. Navigate to the Configuration > I-Luminate menu. Enter the Default mode submenu. Select Screen/Small Film/Large Film as desired and confirm. 5.12 I-Luminate film position About the I-Luminate film position By default, the I-Luminate film rectangle comes up in the left side, top center of the screen.

  • Page 39: Color Presets

    Advanced operation 5.14 Color presets About color presets The available color preset settings for your display are: • Clearbase: Simulation of the clearbase film color temperature. • Bluebase: Simulation of the bluebase film color temperature. • User: When selecting the User color temperature setting, you will be able to manually define the X and Y coordinates or the display color temperature in separate submenus.

  • Page 40: Viewing Modes

    DICOM: DICOM (Digital Imaging and Communications in Medicine) is an international standard that was developed to improve the quality and communication of digital images in radiology. In short, the DICOM display function results in more visible grayscales in the images. Barco recommends selecting the DICOM display function for most medical viewing applications.

  • Page 41: Ambient Light Compensation (Alc)

    Advanced operation To select a display function: Bring up the OSD main menu. Navigate to the Configuration > Calibration menu. Enter the Display Function submenu. Select one of the available display functions and confirm. 5.19 Ambient Light Compensation (ALC) About ALC Ambient Light Compensation (ALC) can only be enabled on your display when the DICOM display function is selected.

  • Page 42: Continuous Alc

    Embedded QA is not a replacement for the Barco MediCal QAWeb solution. Although Embedded QA is a reliable option to perform a simple calibration or compliance test, Barco still highly recommends MediCal QAWeb as the solution of choice for calibration and QA. Medical QAWeb brings...

  • Page 43: Dicom Status Report

    Advanced operation 5.22.2 DICOM status report About DICOM status report Following information is available: DICOM Compliance Status (status since last compliance check): • Compliance status: Shows if the current DICOM curve is compliant or not. • Maximum error: Shows the maximum error of the current DICOM curve. This is the deviation compared to a perfect DICOM.

  • Page 44: Reset Dicom Calibration

    Advanced operation To start DICOM calibration: Bring up the OSD main menu. Navigate to the Configuration > Calibration > Embedded QA menu. Select DICOM calibration to start the calibration. Warning: Pressing a key during calibration will abort the calibration, previous values will be restored. Note: After calibration, the compliance check will start automatically.

  • Page 45: Image Source Selection Modes

    Advanced operation 5.24 Image source selection modes About image source selection modes Your Coronis Uniti automatically detects the number of video input signals connected, attaches them to the correct display side and applies the correct video settings to it (resolution, video encoding mode, refresh rate,...).

  • Page 46: Input Interface Standard Version

    Advanced operation 5.26 Input interface standard version About Input interface standard version The Coronis Uniti supports two input interface standard versions: DPCD V1.1 and DPCD V1.2 To select the EDID format Bring up the OSD main menu. Navigate to the Configuration > Image Sources > Input Settings > DisplayPort1/2 menu. Enter the Input interface standard version submenu.

  • Page 47: Display Info

    Advanced operation 5.29 Display info About display info Your display serial number, native resolution, firmware versions, etc. are available in a dedicated submenu of the OSD menu. To retrieve info about your display: Bring up the OSD main menu. Navigate to the About this Display menu to make the information visible on the screen. 5.30 Display status About display status The Status submenu of the OSD menu provides info on the current status of your display (runtimes,...
  • Page 48 Advanced operation K5902079-07 Coronis Uniti...

  • Page 49: Cleaning Your Display

    Cleaning your display K5902079-07 Coronis Uniti...

  • Page 50: Cleaning Instructions

    Cleaning your display 6.1 Cleaning instructions To clean the display Clean the display using a sponge, cleaning cloth or soft tissue, lightly moistened with a recognized cleaning product for medical equipment. Read and follow all label instructions on the cleaning product. In case of doubt about a certain cleaning product, use plain water.

  • Page 51: Repackaging Instructions

    Repackaging instructions K5902079-07 Coronis Uniti...

  • Page 52: Repacking Your Coronis Uniti System

    Repackaging instructions 7.1 Repacking your Coronis Uniti system How to repack your Coronis Uniti system Insert the connector cover in the small buffer. Image 7-1 Lock the height mechanism at the lowest display position by inserting the hook pin in the back of the stand. Caution: Make sure that the hook pin is inserted deep enough until only the red part of the pin is visible.
  • Page 53 Repackaging instructions Image 7-3 Tilt the display in the most upwards position. Image 7-4 Slide the small buffer between the display and the stand. Image 7-5 Tilt the display back, to the most downward position. K5902079-07 Coronis Uniti...
  • Page 54 Repackaging instructions Image 7-6 Lock the tilt mechanism by inserting the tilt lock pin in the lock hole at the back of the display. Caution: Make sure that the tilt lock pin is inserted deep enough until only the red part of the pin is visible.
  • Page 55 Repackaging instructions Image 7-9 Insert the 2 cardboard compartments in the bottom buffers. Image 7-10 Position the 2 top buffers on the display and cardboard compartments. Image 7-11 Slide the accessory box and the display controller box in the cardboard compartments. K5902079-07 Coronis Uniti...
  • Page 56 Repackaging instructions Image 7-12 Put the touchpad box in the dedicated cutout. Image 7-13 Slide the top box over the display, in the bottom box. Caution: Make sure that the position of the lock cutouts in the bottom box and top box fit together. Image 7-14 Insert the 4 locks in the provided cutouts of the box.
  • Page 57 Repackaging instructions Image 7-15 Turn each lock a quarter turn to the right. Image 7-16 The Coronis Uniti system is ready to be shipped. Image 7-17 K5902079-07 Coronis Uniti...
  • Page 58 Repackaging instructions K5902079-07 Coronis Uniti...

  • Page 59: Important Information

    Important information K5902079-07 Coronis Uniti...

  • Page 60: Safety Information

    Important information 8.1 Safety information General recommendations Read the safety and operating instructions before operating the device. Retain safety and operating instructions for future reference. Adhere to all warnings on the device and in the operating instructions manual. Follow all instructions for operation and use. Electrical Shock or Fire Hazard To prevent electric shock or fire hazard, do not remove cover.

  • Page 61: Environmental Information

    Important information • Mains lead protection (U.S.: Power cord): Power cords should be routed so that they are not likely to be walked upon or pinched by items placed upon or against them, paying particular attention to cords at plugs and receptacles.
  • Page 62 Electronic Products ” (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section “Limit Requirements of toxic substances in Electronic Information Products”.

  • Page 63: Regulatory Compliance Information

    The manufacturing country of the product is indicated on the product label (“Made in …”). Importers contact information To find your local importer, contact one of Barco’s regional offices via the contact information provided on our website (www.barco.com). FCC class B This device complies with Part 15 of the FCC Rules.

  • Page 64: Emc Notice

    Important information in a residential installation. This device generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this device does cause harmful interference to radio or television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the following measures:...
  • Page 65 Important information This Coronis Uniti complies with appropriate medical EMC standards on emissions to, and interference from surrounding equipment. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 66 Important information Electromagnetic Immunity test Compliance level IEC 60601 test levels environment – guidance Conducted RF 3 Vrms (6 Vrms in ISM 3 Vrms (6 Vrms in ISM Portable and mobile RF bands) bands) communications IEC 61000-4-6 equipment should be used 150 kHz to 80 MHz no closer to any part of the Radiated RF...

  • Page 67: Explanation Of Symbols

    Important information maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the Coronis Uniti as recommended below, according to the maximum output power of the communications equipment. Separation distance according to frequency of transmitter (m) Rated maximum output power of transmitter 150 kHz to 80 MHz 80 MHz to 800 MHz...
  • Page 68 Important information Indicates the device is approved according to the KC regulations Indicates the device is approved according to the BSMI regulations Indicates the device is approved according to the PSE regulations Indicates the device is approved according to the EAC regulations Caution: Federal law (United Stated of America) restricts this device to sale by or on the order of a licensed healthcare practitioner.

  • Page 69: Legal Disclaimer

    Barco software products are the property of Barco. They are distributed under copyright by Barco NV or Barco Inc., for use only under the specific terms of a software license agreement between Barco NV or Barco Inc. and the licensee. No other use, duplication, or disclosure of a Barco software product, in any form, is authorized.
  • Page 70 Important information Color imaging Gray imaging Bit depth 30 bit Viewing angle (H, V) 178° Optical glass Uniformity correction SteadyColor I-Luminate Ambient Light Yes, reading room selection Compensation (ALC) Ambient light sensor Backlight Output Stabilization (BLOS) Front sensor Yes, I-Guard Maximum luminance 2100 cd/m²...
  • Page 71 Important information Tilt -5° / +30° Swivel -23° / +23° Pivot Height adjustment range 95 mm Mounting standard VESA (200 x 100 mm & 100 x 100 mm) Screen protection Protective, non-reflective glass cover Recommended modalities Radiology, mammography and digital breast tomosynthesis Certifications FDA 510(K) K133984 for General Radiology CE0120 (MDD 93/42/EEC;...

  • Page 72: Open Source License Information

    Barco whatsoever. You further acknowledge that any such additions, changes or modifications may impair the ability of Barco – at Barco’s sole discretion - to continue to provide service, warranties, software updates, fixes, maintenance, access or such similar abilities, without any recourse or claim towards Barco whatsoever.
  • Page 73 Important information K5902079-07 Coronis Uniti...
  • Page 74 Barco NV President Kennedypark 35 8500 Kortrijk Belgium K5902079-07 | 06/09/2018 Barco NV | Beneluxpark 21, 8500 Kortrijk, Belgium Registered address: Barco NV | President Kennedypark 35, 8500 Kortrijk, Belgium www.barco.com...
