Measurement Computing CIO-DAS1601/12 Manual page 41

Number of channels
Interrupts
Interrupt enable
Interrupt sources
DMA
Trigger sources
A/D conversion time
Throughput
Differential Linearity error (Bipolar)
Integral Linearity error (Bipolar)
No missing codes guaranteed
Gain drift
Zero drift
Input leakage current (@25 Deg C)
Input impedance
Absolute maximum input voltage
Analog Output:
Resolution
Number of channels
D/A type
Voltage Ranges
Offset error
Gain error
Differential nonlinearity
Integral nonlinearity
Monotonicity
D/A pacing
Data transfer
Throughput
Slew Rate
Current Drive (OP07)
Output short-circuit duration
Output coupling
Output impedance
Miscellaneous
8 differential or 16 single-ended, switch-selectable
2 to 7
Programmable
End-of-conversion, terminal count (DMA)
Channel 1 or 3
External hardware/software (DIn0)
10 µs
100 kHz
±1 LSB
±1.5 LSB
16 bits
±7 ppm/°C
±2 ppm/°C
200 nA
10 MegOhms min
±35V
12 bits
2
MX7548
±10V, ±5V, 0 to 5V, 0 to 10V or user-defined range
between 0 and 10V. Each channel independently
configurable by jumpers.
Trimmable to 0 by potentiometer
Trimmable to 0 by potentiometer
±1LSB max
±1LSB max
Guaranteed monotonic
Software paced
Double-buffered software transfer, update on write to MSB
register.
System-dependent, software-paced.
0.3V/µs
±5 mA min
Indefinite
DC
0.1 ohms max
Double-buffered output latches
37
