Analog Output:
Resolution
Number of channels
D/A type
Voltage Ranges
Offset error
Gain error
Differential nonlinearity
Integral nonlinearity
Monotonicity
D/A pacing
Data transfer
Throughput
Slew Rate
Current Drive (OP07)
Output short-circuit duration
Output coupling
Output impedance
Miscellaneous
Digital Input / Output
Digital Type (Digital I/O connector)
Configuration
Number of channels
Output High
Output Low
Input High
Input Low
Digital Type (Main analog connector)
Output
Input
Configuration
Number of channels
Output High
Output Low
Input High
Input Low
12 bits
2
MX7548
±10V, ±5V, 0 to 5V, 0 to 10V or user defined range between
0 and 10V. Each channel independently configurable by
jumpers.
Trimmable to 0 by potentiometer
Trimmable to 0 by potentiometer
±1 LSB max
±1 LSB max
Guaranteed monotonic
Software paced
Double buffered software transfer, update on write to MSB
register.
System dependent, software paced.
0.3V/µs
±5 mA min
Indefinite
DC
0.1 Ohms max
Double-buffered output latches
82C55 (not applicable on -P5 versions)
2 banks of 8, 2 banks of 4, programmable by bank as input
or output
24 I/O
3.0 volts min @ −2.5 mA
0.4 volts max @ 2.5 mA
2.0 volts min, 5.5 volts absolute max
0.8 volts max, −0.5 volts absolute min
74LS197
74LS244
4 fixed input, 4 fixed output
8
2.7 volts min @ −0.4 mA
0.5 volts max @ 8 mA
2.0 volts min, 7 volts absolute max
0.8 volts max, −0.5 volts absolute min
35
