6.1.7
DMA, INTERRUPT & TRIGGER CONTROL
BASE ADDRESS + 9
7
6
INTE
IR2
A read and write register.
READ
INTE = 1, Interrupts are enabled. An interrupt generated will be placed on the PC bus interrupt level
selected by IR4, IR2 & IR1. INTE = 0, interrupts are disabled.
IR2, IR1, IR0 are bits in a binary number between 0 and 7 which map interrupts onto the PC bus interrupt
levels 2 to 7. Interrupts 0 and 1 cannot be asserted by the CIO-DAS1600.
IR2
0
0
0
0
1
1
1
1
When DMA = 1, DMA transfers are enabled.
When DMA = 0, DMA transfers are disabled.
Note that this bit only allows the CIO-DAS1600 to assert a DMA request to the PC on the DMA request
level selected by the DMA switch on the CIO-DAS1600. Before this bit is set to 1, the PC's 8237 (or
appropriate) DMA controller chip must be set up.
TS1 & TS0 control the source of the A/D start conversion trigger according to Table 6-3 below.
Table 6-3. Source Codes for the A/D Start Conversion Trigger
TS1
TS0
0
X
Software triggered A/D only
1
0
Start on rising edge (Digital input 0, Pin 25)
1
1
Start on Pacer Clock Pulse (CTR 2 OUT, no external access)
6.1.8

PACER CLOCK CONTROL REGISTER

BASE ADDRESS + Ah
7
6
BL3
BL2
Write only
5
IR1
IR0
Table 6-2. Interrupt Program Codes
IR1
IR0
0
0
0
1
1
0
1
1
0
0
0
1
1
0
1
1
5
BL1
BL0
4
3
X
INTERRUPT LEVEL
4
3
X
24
2
1
DMA
TS1
None
None
2
3
4
5
6
7
2
1
X
CTR0
0
TS0
0
TRIG0
