9.1 CIO-DAS1601/12 & CIO-DAS1602/12
Power consumption
+5
Analog input section
A/D converter type
Resolution
Programmable ranges
CIO-DAS1601/12
CIO-DAS1602/12
A/D pacing
Burstmode
Data transfer
Polarity
Number of channels
Interrupts
Interrupt enable
Interrupt sources
DMA
Trigger sources
A/D conversion time
Throughput
DMA
DT-Connect (multi-channel)
DT-Connect (single-channel)
Differential Linearity error
Integral Linearity error
No missing codes guaranteed
Gain drift
Zero drift
Input leakage current (@25 Deg C)
Input impedance
Absolute maximum input voltage
1.4 A typical, 2.1 A max
ADS7800 successive approximation
12 bits
±10V, ±1V, ±0.1V, ±0.01V, 0 to 10V, 0 to 1V, 0 to 0.1V,
0 to 0.01V
±10V, ±5V, ±2.5V, ±1.25V, 0 to 10V, 0 to 5V, 0 to 2.5V,
0 to 1.25V
Programmable: external source (Din0, positive edge) or
internal counter (positive or negative edge, jumper-select
able) or software-polled
4 µs
From 512 sample FIFO via interrupt, DMA, DT-Connect to
external memory board or software polled
Unipolar/Bipolar, switch selectable
8 differential or 16 single-ended, switch selectable
2 to 7
Programmable
End-of-conversion, terminal count (DMA)
Channel 1 or 3
External hardware/software (DIn0)
3.3 µs
160 kHz
250 kHz
330 kHz
±1 LSB
±1 LSB
12 bits
±60 ppm/°C
±160 ppm/°C
200 nA
Min 10 Megohms
±35V
34
