IN THE KIT
i.
Double DIN Fascia Panel
ii.
Brackets
iii.
Universal Patch Lead
APPLICATION
Note: Application data is subject to change at any time
Iveco Daily
Note: vehicle will need modification. Please familiarise yourself with the instructions before undertaking installation.
FEATURES
• Allows for the installation of a double DIN aftermarket stereo
• Includes mounting brackets and fitting accessories
• Retains factory steering wheel control functionality
• Retains factory phone buttons
• Retains factory reverse camera (if applicable)
• Provides outputs for speed pulse, reverse gear and park brake
The information provided in this document is subject to change without notice due to manufacturer changes and/or improvements to the product/s. This
instruction manual is based on documented data and research. The manufacturer of this product cannot be held responsible for any changes made to the
vehicle by the manufacturer or damages that may occur through the installation of this product in accordance with the steps outlined herein.
iv.
Fakra-DIN Antenna Adapter
v.
SWC Interface/Harness
2020 >
Complete Installation Kit
i.
iii.
DISCLAIMER
CTKIV02
for Iveco Vehicles
ii.
iv.
v.
CTKIV02_IG_v1
Advertisement
Table of Contents
Related Manuals for Connects2 CTKIV02
Summary of Contents for Connects2 CTKIV02
- Page 1 CTKIV02 Complete Installation Kit for Iveco Vehicles iii. IN THE KIT Double DIN Fascia Panel Fakra-DIN Antenna Adapter Brackets SWC Interface/Harness iii. Universal Patch Lead APPLICATION Note: Application data is subject to change at any time Iveco Daily 2020 >...
-
Page 2: Product Information
PRODUCT INFORMATION The CTKIV02 is a complete installation kit that provides a solution for Iveco Daily vehicles when installing an aftermarket head unit. This kit contains a CAN steering wheel interface and harness which helps retain the steering wheel controls and factory phone button functionality of the vehicle (if vehicle is equipped). - Page 3 FASCIA DIAGRAM Need help? Visit support.connects2.com/tickets/technical CTKIV02_IG_v1...
-
Page 4: Wiring Diagram
WIRING DIAGRAM FM/Blue Phantom Power Connections Fakra Antenna Connection Connect to aftermarket stereo Connect to OEM Antenna connector from vehicle Flying Wires Vehicle Specific Connector Pink - Speed Pulse Connect to relevant connector from vehicle ISO Connector Green - Park Brake Connect to aftermarket stereo Purple/White - Reverse Gear Yellow RCA Connector... -
Page 5: Prior To Installation
Please ensure that the correct tools are used during the installation to avoid damage to the vehicle or product. Connects2 can not be held responsible for the installation of this product. - Page 6 When performing any modification to the vehicle, always ensure to measure where the stereo will sit and take due care when performing modifications to the vehicle. Connects2 always promotes the use and expertise of professional installers. Connects2 will not be held responsible for any damage to the vehicle.
-
Page 7: Dash Assembly
Once placed and happy with the fitment, screw into place using a set of screw (not supplied). With the head unit in place, proceed to fit the new fascia panel over the front of the radio to complete the installation. Need help? Visit support.connects2.com/tickets/technical CTKIV02_IG_v1... - Page 8 If steering wheel control functions are unresponsive, please uninstall the interface and wiring and reinstall carefully in accordance with the above steps. For further help, please contact and fill out a support ticket with the full details of your issue at: support.connects2.com/tickets/technical CTKIV02_IG_v1...
