ii.
iii.
IN THE KIT
i.
Double DIN Fascia
ii.
Brackets & Accessories
iii.
Vehicle Interface & Harness
APPLICATION
Note: Application data is subject to change at any time
Mazda BT-50
Note: vehicle will need modification. Please familiarise yourself with the instructions before undertaking installation.
FEATURES
• Allows for the installation of a double DIN aftermarket stereo
• Comes complete with accessories for fitment of double DIN stereo
• Retains steering wheel control functionality
• Retains time/date setting functionality
• Provides outputs for park brake, reverse gear, antenna remote and speed pulse
• Includes additional accessories including antenna adapter and patch lead
• Finished in black to match the vehicles dashboard
The information provided in this document is subject to change without notice due to manufacturer changes and/or improvements to the product/s. This
instruction manual is based on documented data and research. The manufacturer of this product cannot be held responsible for any changes made to the
vehicle by the manufacturer or damages that may occur through the installation of this product in accordance with the steps outlined herein.
iv.
iv.
Antenna Adapter
v.
Universal Patch Lead
2012 - 2017
DISCLAIMER
Complete Installation Kit
for Mazda vehicles
CTKMZ01
i.
v.
CTKMZ01_IG_v1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Connects2 CTKMZ01
Summary of Contents for Connects2 CTKMZ01
- Page 1 CTKMZ01 Complete Installation Kit for Mazda vehicles iii. IN THE KIT Double DIN Fascia Antenna Adapter Brackets & Accessories Universal Patch Lead iii. Vehicle Interface & Harness APPLICATION Note: Application data is subject to change at any time Mazda BT-50 2012 - 2017 Note: vehicle will need modification.
-
Page 2: Product Information
PRODUCT INFORMATION The CTKMZ01 is a complete installation kit that allows for the fitment of an aftermarket head unit into the OEM dashboard of Mazda BT-50 vehicles. The interface provided helps retain steering wheel control presets. The lead features plug-and-play connectors for an easier installation process. - Page 3 FASCIA DIAGRAM CTKMZ01_IG_v1...
-
Page 4: Wiring Diagram
Connect vehicle display connector on harness to vehicles connection Interface Box Stereo Connection (Patch) Lead Connector [12 Pin] Speaker Module Connect to Interface Box Note: Must be connected first, before power connection is made to the interface Need help? Visit support.connects2.com/tickets/technical CTKMZ01_IG_v1... -
Page 5: Prior To Installation
Please ensure that the correct tools are used during the installation to avoid damage to the vehicle or product. Connects2 can not be held responsible for the installation of this product. - Page 6 When performing any modification to the vehicle, always ensure to measure where the stereo will sit and take due care when performing cuts to the vehicle. Connects2 always promotes the use and expertise of professional installers. Connects2 will not be held responsible for any damage to the vehicle.
- Page 7 INSTALLATION GUIDE - FASCIA DASH ASSEMBLY Once the installation of the head unit and wiring has taken place, take the new fascia plate in hand and transplant the clips from the OEM panel to the back. Once done, simply clip the new fascia over the head unit to complete the installation.
- Page 8 If steering wheel control functions are unresponsive, please uninstall the interface and wiring and reinstall carefully in accordance with the above steps. For further help, please contact and fill out a support ticket with the full details of your issue at: support.connects2.com/tickets/technical NOTES Need help? Visit support.connects2.com/tickets/technical CTKMZ01_IG_v1...
