1-2
Compact™ IO Isolated RTD/Resistance Module
User's Manual Pub. 0300241-01 Rev. A

1.1.1 RTD/Resistance Inputs and Ranges

The table below lists the RTD and resistance types and their associated full-scale ranges,
supported by the IR6I module.
Input Range
˚ Celsius
Input Type
Pt 385
-200 to +850
Pt 3916
-200 to +630
10 Cu 426
-100 to +260
100 Ni 618
-100 to +260
120 Ni 672
-80 to +260
604 NiFe 518
-100 to +200
150 ohm
0 to +1500
500 ohm
0 to +500
1000 ohm
0 to +1000
3000 ohm
0 to +3000

1.1.2 Data Formats

The data can be configured on board each module as:
Engineering units x 1
Engineering units x 10
Scaled-for-PID
Percent of full-scale
Raw/proportional data

1.1.3 Filter Frequencies

The module uses a digital filter that provides high frequency noise rejection for the input
signals. The filter is programmable, allowing you to select from six different filter
frequencies for each channel:
4.17 Hz
10 Hz
16.7 Hz
19.6 Hz
62 Hz
470 Hz
˚ Fahrenheit
-328 to 1562
-328 to 1166
-148 to 500
-148 to 500
-112 to 500
-148 to 392
1
1
1
1
