Specification
Module ID Codes
Configuration
Input Modes
Input Types
Excitation Current
Dimensions
Approximate Shipping Weight
(with carton)
Storage Temperature
Operating Temperature
Operating Humidity
Operating Altitude
Vibration
Shock
Unpackaged (Non-operating)
Unpackaged (Operating)
Agency Certification
Hazardous Environment Class
Radiated and
Conducted Emissions
Electrical /EMC:
ESD Immunity
(IEC61000-4-2)
Radiated Immunity
(IEC61000-4-3)
User's Manual Pub. 0300241-01 Rev. A
Appendix A
Specifications
Vendor ID = 58 (Decimal)
Product Type = 10 (Decimal)
Product Code = 101 (Decimal)
6 isolated channels of RTD/resistance inputs
Temperature or resistance
100 ohm PT 385
200 ohm PT 385
500 ohm PT 385
1000 ohm PT 385
100 ohm PT 3916
200 ohm PT 3916
500 ohm PT 3916
1000 ohm PT 3916
10 ohm Cu 426
120 ohm Ni 618
120 ohm Ni 672
604 ohm NiFe
0 - 150 ohm resistance,
0 - 500 ohm resistance,
0 - 1000 ohm resistance,
0 - 3000 ohm resistance
420uA excitation current used with:
100 ohm PT 385, 500 ohm PT 385, 1000 ohm PT 385, 500 ohm PT 3916, 1000 ohm PT 3916, 604
ohm NiFe 518, 0 - 1000 ohm resistance, 0 - 3000 ohm resistance
1mA excitation current used with:
200 ohm PT 385, 100 ohm PT 3916, 200 ohm PT 3916, 120 ohm Ni 618, 120 ohm Ni 672, 10 ohm Cu
426, 0 - 150 ohm resistance, 0 - 500 ohm resistance
118 mm (height) x 87 mm (depth) x 35 mm (width)height including mounting tabs is 138 mm4.65 in.
(height) x 3.43 in (depth) x 1.38 in (width)height including mounting tabs is 5.43 in.
276g (0.61 lbs.)
-40°C to +85°C (-40°F to +185°F)
0°C to +60°C (32°F to +140°F)
5% to 95% non-condensing
2000 meters (6561 feet)
5g@ 10–500Hz
½ Sine Shock Wave 20g@9ms, 3 shocks/axis
½ Sine shock Wave 30g@11ms, 1 shock/axis
C-UL certified (under CSA C22.2 No. 142)
UL 508 listed
CE compliant for all applicable directives
Class I, Division 2, Hazardous Location, Groups A, B, C, D
(ISA 12.12.01, C-UL under CSA C22.2 No. 213)
Operating Temperature Code T5
IEC61000-6-4 FCC Part 15B Class A
The module has passed testing at the following levels:
4 kV contact, 8 kV air
10 V/m, 80 to 1000 MHz, 80% amplitude modulation, 900 MHz & 1890 MHz 100% amplitude
modulation
