Student Desk
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top
1 Pc.
B.
Keyboard
1 Pc.
C.
Shelf
2 Pcs.
Hardware List
Hex Wrench
1 Pc.
F.
Frame
1 Pc.
M6x13
Small Hex Wrench
Head Cap Bolt
1 Pc.
40 Pcs.(+1 extra)
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
D.
E.
Side Frame
Side Frame
1 Pc.
1 Pc.
G.
Frame
1 Pc.
M6x38
Tapered
Head Cap Bolt
6 Pcs. (+1 extra)
H.
Stretcher
4 Pcs.
I.
Stretcher
1 Pc.
J.
Stretcher
1 Pc.
K.
Stretcher
1 Pc.
Spring Washer
40 Pcs. (+1 extra)
Tools recommended for assembly : Level
Flat Washer
40 Pcs. (+1 extra)
