IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Cabinet
1 pc.
Hardware List
Hex Wrench
1 pc.
Small
Hex Wrench
1 pc.
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
C.
Side Frame
2 pcs.
M6x12
Head Cap Bolt
8 pcs. (+1 extra)
B.
Stretcher
2 pcs.
D.
Shelf
1 pc.
Spring Washer
8 pcs. (+1 extra )
M4x12
Flat Washer
Wood Screw
8 pcs. (+1 extra )
4 pcs. (+1 extra)
