Pedestal Desk
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensur
completed product as it was designed.
Part List
A.
Top
1 pc.
D.
Shelf
2 pcs.
Hardware List
Hex Wrench
1 pc.
Small Wrench
1 pc.
Home Styles Consumer Assistance : www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
e a
E.
Side Frame
2 pcs.
M6x35
M6x16
Tapered Head Cap Bolt
Head Cap Bolt
2 pcs. (+1 extra)
52 pcs. (+8 extra)
B.
Keyboard
1 pc.
F.
G.
Side Frame
Side Frame
1 pc.
1 pc.
Spring Washer
52 pcs. (+8 extra)
Tools recommended for assembly : Level
C.
Shelf
2 pcs.
H.
Stretcher
1 pc.
I.
Stretcher
1 pc.
J.
Stretcher
8 pcs.
Flat Washer
Adjustable Pin
52 pcs. (+8 extra)
8 pcs.
