Hall Tree Stand
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Top
1 Pc.
B.
Shelf
1 Pc.
C.
Seat
1 Pc.
D.
Shelf
1 Pc.
Hardware List
Hex Wrench
1 Pc.
Small Hex Wrench
1 Pc.
Tools required for assembly : Phillips screwdriver
E.
Side Frame
1 Pc.
M6x16
Head Cap Bolt (short)
15 Pcs.(+1 extra)
M6x16
Tapered Head Cap Bolt
12 Pcs.(+1 extra)
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
G.
Side Frame
1 Pc.
F.
Side Frame
1 Pc.
I.
Front Stretcher
2 Pcs.
M4x13
Wood Screw
Flat Washer
12 Pcs. (+1 extra)
19 Pcs. (+1 extra)
M3x13
Wood Screw
Spring Washer
for Hook
19 Pcs. (+1 extra)
8 Pcs. (+1 extra)
H.
Side Frame
1 Pc.
K.
L.
Back Frame
Back Frame
1 Pc.
1 Pc.
M.
Back Stretcher
1 Pc.
M6x32
Head Cap Bolt
for Seat
2 Pcs.(+1 extra)
M6x57
Head Cap Bolt (long)
2 Pcs.(+1 extra)
Tools recommended for assembly : Level
J.
Back Frame
1 Pc.
Hook
4 Pcs.
