Modern Craftsman
Executive Desk
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Cabinet
1 pc.
C.
Side Frame
1 pc.
Hardware List
Hex Wrench
1 pc.
Small
Hex Wrench
1 pc.
Tools required for assembly : Phillips screwdriver
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
D.
Side Frame
1 pc.
Head Cap Bolt
14 pcs. (+1 extra)
Wood Screw
10 pcs. (+1 extra)
B.
Stretcher
2 pcs.
E.
Stretcher
1 pc.
F.
Stretcher
1 pc.
Wood Screw
for Drawer
6 pcs. (+1 extra)
Wood Screw (long)
3 pcs. (+1 extra)
Tools recommended for assembly :Level
G.
Drawer
1 pc.
Spring Washer
14 pcs. (+1 extra )
Flat Washer
14 pcs. (+1 extra )
