88 5053 42
Night Stand
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occurring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure
a completed product as it was designed.
Part List
Hardware List
Hex Wrench
1 pc.
Small Hex Wrench
1 pc.
Tools required for assembly : Level
Home Styles Consumer Assistance : www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
A.
Top
1 pc.
B.
Shelf
1 pc.
C.
Shelf
1 pc.
M6x19
M6x38
Head Cap Bolt
Head Cap Bolt (long)
4 pcs. (+1 extra)
8 pcs. (+1 extra)
D.
Side Frame
2 pcs.
Spring Washer
Flat Washer
12 pcs. (+1 extra)
12 pcs. (+1 extra)
Adjustable Pin
4 pcs.
