88 5051 601
St. Ives
King Headboard
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A.
Metal Frame
1 pc.
B.
Metal Frame
1 pc.
Hardware List
Small Hex Wrench
Hex Wrench
1 pc.
1 pc.
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
Head Cap Bolt (short)
Head Cap Bolt (middle)
4 pcs. (+1 extra)
8 pcs. (+1 extra)
C.
Post
1 pc.
E.
Stretcher
1 pc.
Head Cap Bolt (long)
6 pcs. (+1 extra)
D.
Post
1 pc.
