Home Styles 88 5050 76 Quick Start Manual

88 5050 76
Modern Craftsman
Multi Function Shelf

IMPORTANT NOTE

Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damage occuring to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.

Part List

A.
Top
1 Pc.
F.
Front Frame
1 Pc.
G.
Front Rail
4 Pcs.
H.
Back Stretcher
1 Pc.

Hardware List

Hex Wrench
1 Pc.
Small Hex Wrench
1 Pc.
Tools required for assembly : Phillips screwdriver
B.
Side Frame
1 Pc.
I.
Back Stretcher
2 Pcs.
Home Styles Consumer Assistance: www.homestyles-furniture.com,
servicedesk@homestyles-furniture.com, 888-680-7460, 877-831-0319
C.
Side Frame
1 Pc.
J.
Shelf
4 Pcs.
Tapered
Head Cap Bolt
20 Pcs. (+1 extra)
Head Cap Bolt
18 Pcs. (+1 extra)
D.
Side Frame
1 Pc.
K.
Upper
Back Frame
2 Pcs.
Spring Washer
18 Pcs. (+1 extra)
Flat Washer
18 Pcs. (+1 extra)
Tools recommended for assembly : Level
E.
Side Frame
1 Pc.
L.
Lower
Back Frame
2 Pcs.
Wood Screw (short)
8 Pcs. (+1 extra)
Wood Screw (long)
24 Pcs. (+1 extra)
